SKU 55264
Neptune Max Stand
Accessory
Parts List:
Part
SKU
1
FW12
2
SW12
3
C12035
4
C06016
5
FW06
6
SW06
7
BHC06012
8
5519016
9
5519015
10
5519018
11
5519017
12
24161
Specifications:
Overall Size
Net Weight
For all worldwide Inquiries, Repairs or Services
https://www.teknatool.com/support/
1
133-01-2303
For safety reasons, please read
carefully read amd understand
these instructions.
The NOVA Neptune Max Stand is
designed to fit and be used with
the Neptune, Neptune Max, DVR
XP and 1624-44 woodlathes.
Use of the Neptune Max Stand on
other lathes could cause a
malfunction and risk of serious
injury, if you are unsure of the use
or the application of this
accessory, contact the technical
support department of Teknatool
International or your reseller.
Further information can also be
found in your lathe manual.
Description
Flat Washer M12 ZP
Spring Washer M12 ZP
M12x35mm Cap Screw ZP
M6x16mm Cap Screw ZP
Flat Washer M6 ZP
Spring Washer M6 ZP
M6x12mm Button Head Cap Screw
Stand Cross Plate
Stand Legs
Stand Cover
Tool Tray
Foot Assembly
Metric
Imperial
1292mm (L) x 490mm
50.9" (L) x 19.3" (w) x
(w) x 818mm(H)
25.5 Kg ± 0.5 Kg
56.2 Lb ± 1.1 lb
(issues must be in writing)
Contact us at:
Qty
8
8
8
4
16
16
8
2
4
2
2
4
32.2" (H)
