requirements in the event of database corruption or failure. Assuming an average mailbox size of
. .
50 MB and a target database size of 35 to 50 GB, the average number of users on an Exchange 5.5
. .
. .
server would be between 700 and 1000.
. .
. .
Exchange 2000 addresses the single instance of ESE by allowing up to four instances of ESE per
. .
server (still governed by a single instance of store.exe), known as storage groups. Each storage
. .
. .
group has its own transactional logs, thereby making it the unit of backup. Also, each storage
. .
group can contain as many as five databases, which become the unit of restore. Partitioning the
. .
. .
information store into more manageable sizes (for backup and restore) provides the basis for
. .
consolidating larger numbers of users onto a single server.
. .
. .
. .
Exchange 2000 also features improved SMP scalability over its predecessor to take better
. .
advantage of multi-processor servers. Vying for system resources on Exchange 2000 deployment
. .
. . servers, however, are additional applications and services, including:
. .
. .
Anti-Virus agents. The primary entry point for viruses into organizations has migrated from
. .
floppy disks and internet downloads, to the outward-facing email environment. Many third
. .
. .
parties offer Exchange-specific anti-virus solutions, which may integrate directly with ESE
. .
through the virus-scanning API 2.0 to scan email and attachments. These agents have a
. .
. .
resource cost in real-time monitoring mode, and they may have an additional impact when
. .
performing a scan of the information store.
. .
. .
. . Management agents. In addition to server management agents such as Insight Manager,
. .
third party vendors such as NetIQ and BMC provide enhanced management capabilities for
. .
applications such as Exchange. While designed to be unobtrusive to the environment, these
. .
. .
agents may also require additional server resources, depending upon their level of activity.
. .
. .
Backup/Restore agents. Most organizations will leverage a third-party backup vendor to
. .
. .
take advantage of such Exchange-specific capabilities as storage group and individual
. .
database recovery, parallel backup of storage groups, and backup/recovery of key Exchange
. .
. .
services, such as site replication services and the key management service. Like anti-virus
. .
agents, these agents have may have additional resource impact during the backup or restore.
. .
. .
Other Exchange services. New to Exchange 2000, the full-text indexing service can place a
. .
. .
CPU-intensive load during its crawl and rebuild operation. These types of services are often
. .
scheduled for after-hours operation, due to the load placed on the server and the potential
. .
. .
impact to the core messaging services.
. .
. .
Other applications. Exchange 2000 scales well through four processors, and initial testing
. .
. .
indicates some potential benefits with as many as six processors. However, the resources of
. .
an 8-way server, such as the ProLiant DL760 server, may be better utilized through the
. .
. .
partitioning of services, specifically by limiting the Exchange STORE process to four or six
. .
processors, and granting other agents or processes access to the remaining physical
. .
. .
processors. These applications could include Active Directory, Collaborative Applications,
. .
and even file/print services. Our testing was designed to prove that the Exchange
. .
. .
environment would function similarly when limited to six processors, thereby freeing up
. .
additional resources for other supporting or even unrelated applications.
. .
. .
Our testing focused on using RPM to better manage the supporting agents partitioning the
. .
. .
workload on the Exchange 2000 server, while experiencing the same or better overall Exchange
. .
performance (measured through lower CPU consumption).
. .
. .
. . NOTE: It is important to mention that CPU utilization is only one resource consumed by
. .
Exchange. Before consolidating unrelated applications on the same box, consider the additional
. .
. . resource constraints of these applications and factor these requirements, such as storage I/O,
. .
memory, network, etc., into your configuration.
. .
. .
. .
