Compaq ProLiant DL320 Service Update

Compaq ProLiant DL320 Service Update

Hide thumbs Also See for ProLiant DL320:

Advertisement

Quick Links

Download this manual
White Paper
January 2002
Prepared by Customer Service
Training and Development
Compaq Computer Corporation
Contents
....................3
Features.....................................3
...........................4
Procedures..................8
Processor...................................8
...................13
Considerations.............16
.................................17
Compaq ProLiant DL320
Service Update
Abstract: This service update white paper describes updates to the
Compaq ProLiant DL320 Server. It provides option part numbers for
the DVD/diskette combination assembly, spares part numbers for the
1.13 Ghz processor and service procedures for removing or replacing
the DVD/diskette combination assembly and processor.
Help us improve our technical communication. Let us know what you think
about the technical information in this document. Your feedback is
valuable and will help us structure future communications. Please send
your comments to: customerservicestdfeedback@compaq.com.

Advertisement

loading
Need help?

Need help?

Do you have a question about the ProLiant DL320 and is the answer not in the manual?

Questions and answers

Related Manuals for Compaq ProLiant DL320

Summary of Contents for Compaq ProLiant DL320

  • Page 1: Table Of Contents

    Contents Abstract: This service update white paper describes updates to the Product Description ....3 Compaq ProLiant DL320 Server. It provides option part numbers for Features........3 System and Mechanical the DVD/diskette combination assembly, spares part numbers for the Spare Parts List ......4...
  • Page 2 Compaq ProLiant DL320 Service Update© 2002 Compaq Computer Corporation Compaq and the Compaq logo are registered in the U.S. Patent and Trademark Office. Microsoft and Windows are trademarks of Microsoft Corporation in the United States and other countries. All other product names mentioned herein may be trademarks of their respective companies.

  • Page 3: Product Description

    Compaq ProLiant DL320 Service Update Product Description The ProLiant DL320 Server has a new option, a DVD/diskette combination drive and a new processor speed, 1.13Ghz. This document lists the new option and spares part numbers and reviews the corresponding procedures to service.

  • Page 4: System And Mechanical Spare Parts List

    Compaq ProLiant DL320 Service Update System and Mechanical Spare Parts List As a review, Figure 1 and 2 illustrate an exploded views of the mechanical and system spare component parts. Table 1 lists the option and spare part numbers. Part numbers for new processor and DVD/diskette combination assembly are highlighted in yellow.
  • Page 5 Compaq ProLiant DL320 Service Update Figure 2. System components exploded view Table 1: System and Mechanical Spare Parts List Item Description Spare Parts List Mechanical Components Chassis 207735-001 Access panel Fixed cable tray 173839-001 PCI riser board assembly 207727-001 207729-001...
  • Page 6 Compaq ProLiant DL320 Service Update Item Description Spare Parts List Boards User interface board 207725-001 CD-ROM (DVD-ROM)/diskette drive assembly 207726-001 backplane System board 207723-001 System board for 1.13-Ghz processors or greater 260142-001 Single Channel Wide Ultra2 SCSI controller module 207724-001...
  • Page 7 Compaq ProLiant DL320 Service Update CD-ROM (DVD-ROM)/diskette drive assembly cable * ATA hard drive cables (2) * Two-device terminated SCSI cable (Ultra3) * 207730-001 Note: * Not shown Refer to the QuickSpecs for a more complete list of options. (See References.) Rev.

  • Page 8: Servicing Procedures

    Compaq ProLiant DL320 Service Update Servicing Procedures Processor Power down the server Step Action Press the server Power On/Off switch to power down the server. When the server is off, the power LED deactivates. Verify that the fan is off by listening for the fan noise to stop.
  • Page 9 Compaq ProLiant DL320 Service Update Remove and replace the access panel Step Action Press and hold down the locking latches Slide the access panel approximately 1.25 cm (0.5 inch) toward the rear of the unit and lift the panel to remove it Reverse steps 1 through 2 to replace the access panel.
  • Page 10 Compaq ProLiant DL320 Service Update Rev. 1.0 Page 10 of 17...
  • Page 11 Compaq ProLiant DL320 Service Update Remove and replace the processor CAUTION: Always use a new thermal pad and a new heatsink when replacing processors. Failure to use new components can cause damage to the processor. Step Action Locate the processor on the system board.
  • Page 12 Compaq ProLiant DL320 Service Update Step Action CAUTION: Scrape thermal interface material off of the processor carefully to avoid damaging the processor. Store the processor in a static-free environment after removing it from the server. CAUTION: Remove the plastic cover to expose the adhesive side of the thermal pad on the new heatsink before placing the heatsink on the processor.

  • Page 13: Dvd-Rom/Diskette Combination Drive

    Compaq ProLiant DL320 Service Update DVD-ROM/Diskette Combination Drive Power down the server Step Action Press the server Power On/Off switch to power down the server. When the server is off, the power LED deactivates. Verify that the fan is off by listening for the fan noise to stop.
  • Page 14 Compaq ProLiant DL320 Service Update Shipping/ejector key Compaq ProLiant DL320 servers include a shipping/ejector key that secures the DVD- ROM/diskette drive assembly or the bezel blank during shipping. This key should be removed before server deployment. The key is also used to eject an assembly or the blank.
  • Page 15 Compaq ProLiant DL320 Service Update Remove and replace the DVD-ROM/combination drive Step Action Remove the shipping/ejector key from the chassis if you have not already done so. Insert the shipping/ejector key approximately 1.25 cm (0.5 inch) into the DVD- ROM/diskette drive assembly ejector port on the lower right corner of the server front...

  • Page 16: Service Considerations

    Compaq ProLiant DL320 Service Update Service Considerations As with the CD-ROM/diskette combination assembly, the DVD-ROM/diskette combination assembly is a one-piece unit. Item Description Bay 1 DVD-ROM and Diskette drive assembly Note: Expansion Bays are not available in this server. The DVD-ROM and Diskette drive are a single assembly Rev.

  • Page 17: References

    Compaq ProLiant DL320 Service Update References For information on servicing and troubleshooting the Compaq ProLiant DL320 Server refer to the: Install Guide Compaq ProLiant DL320 Setup and Installation Guide This guide is designed to be used as step-by-step instructions for installation and as a reference for operation, troubleshooting, and future upgrades.
