Flowline Starter Body Rig for Camera & Gimbals (B-FLCM-FLN-02)
A s s e m b l y M a n u a l
What's In The Box
Please inspect the contents of your shipped package to ensure you have received everything listed below.
2 x 4mm Knobs
2 x Washers
2 x Velcro
2.5mm L-Type Allen Key
Body Support
Bag Packing
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright
statutes or in writing by the Publisher.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Flycam B-FLCM-FLN-02
Summary of Contents for Flycam B-FLCM-FLN-02
- Page 1 Flowline Starter Body Rig for Camera & Gimbals (B-FLCM-FLN-02) A s s e m b l y M a n u a l What’s In The Box Please inspect the contents of your shipped package to ensure you have received everything listed below.
- Page 2 Camera Hook Support Bar Front Extension Section Release Lever Side Support Adjustment Balance Adjustment Knob Flycam Flowline Starter Body Rig...
- Page 3 INDEX Sr. No Particulars Page No. Flycam Flowline Starter Front Extension Section Assembly Support Bar Assembly Support Bar Height Adjustment Camera Mounting Final Setup...
- Page 4 Flycam Flowline Starter Setup Front Extension Section Assembly • Carefully insert the front extension section on the Support bar. • Now, insert both the side knobs and tighten them securely. • Front section is securely attached to the support bar.
- Page 6 Support Bar Height Adjustment • Loosen all four Adjustment Knobs provided on the back of the Support Jacket. • Then, move the Support Bar upwards or downwards your requirement. • Once the Support bar is at the desired height, re-tighten all four Adjustment Knobs to secure it.
-
Page 7: Camera Mounting
NOTE: It is recommended to attach the minimum required weight (3kg/6.6lb) for pulling down the balancing rope to ensure proper operation of your Flycam Flowline system. • Use the lever at the back of the Body Support to release rope tension as required. - Page 8 YOUR FLYCAM FLOWLINE STARTER BODY RIG FOR CAMERA GIMBALS ALL DRESSED UP AND READY TO GO! (SHOWN WITH OPTIONAL ACCESSORIES) Warranty: We offer a one-year warranty for our products from the date of purchase. Within this period, we will repair it without charge for labor or parts. The warranty doesn’t cover transportation costs, nor does it cover a product subjected to misuse or accidental damage.
