- Page 1 OFT10W-ADLN Intel® Processor N50 User’s Manual Edition 0.1 – February, 2025...
-
Page 2: Fcc Statement
Copyright Notice Copyright 2025 BCM Advanced Research, ALL RIGHTS RESERVED. No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. -
Page 3: Life Support Policy
Disclaimer BCM Advanced Research reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. BCM Advanced Research assumes no responsibility or liability for the use of the described product(s),... - Page 4 Our dealers are well trained and ready to give you the support you need to get the most from your BCM products. In fact, most problems reported are minor and are able to be easily solved over the phone.
- Page 5 Because of BCM high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If any of BCM products is defective, it will be repaired or replaced at no charge during the warranty period. For out-of-warranty repairs, you will be billed according to the cost of replacement materials, service time, and freight.
-
Page 6: Manual Objectives
We strongly recommend that you study this manual carefully before attempting to interface with OFT10W-ADLN or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance. -
Page 7: Table Of Contents
Content Getting Started ......................8 1.1 Safety Precautions ....................8 1.2 Packing List ....................... 8 1.3 System Specifications ..................... 10 1.4 System Overview ....................12 1.4.1 Top View ..........................12 1.4.2 Bottom View ........................... 12 1.4.3 Left View ..........................12 1.4.4 Right View .......................... -
Page 8: Getting Started
OFT10W-ADLN 1. Getting Started 1.1 Safety Precautions Warning! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. - Page 9 Purposes and Applications OFT10W-ADLN is used the Intel® IOTG Alder Lake-N Processor, which has stronger performance and lower power consumption. it also inherits from OFT-series strength, Modularized, Flexible Expansion, Reliability and Stability. OFT series have been passed stricter vibration and shock testing. It can be used on extreme environment like manufacture or factory.
-
Page 10: System Specifications
OFT10W-ADLN 1.3 System Specifications System Information JRX12 Motherboard Processor Intel® IOTG Alder Lake-N Processor 6W N50 CPU Cooler (Type) Passive System Memory Onboard 8GB LPDDR5 Microphone A-MIC in (1x3P, pitch 2.0 wafer ; 90D) Speaker 1x4P, pitch 2.0 wafer; 90D Camera 2x5P, pitch 2.0 wafer ;... - Page 11 Touch Panel i2C, FFC type; 90D 1xUSB, FFC type; 90D 1 x RS-485/232(Default) – 2wires with 5V ; 2x5P pitch 2.0 wafer COM port (RS232/485 by BIOS setting and connector) Speaker stereo 2Wx2/4ohm ; 1x4P, pitch 2.0 wafer; 90D 1 x CR-2032 w/ cable 107mm (220mAh/3.0V) -20°C~70°C 1x2P, pitch 1.25 pin wafer;...
-
Page 12: System Overview
OFT10W-ADLN 1.4 System Overview 1.4.1 Top View 1.4.2 Bottom View 1.4.3 Left View 1.4.4 Right View... -
Page 13: System Dimensions
1.4 System Dimensions (Unit: mm) -
Page 14: Hardware Configuration
OFT10W-ADLN 2 Hardware Configuration For advanced information, please refer to: 1- JRX12 Motherboard included in this manual. Note: If you need more information, please visit our website: www.bcmcom.com... -
Page 15: Powering On The System
2.1 Powering On the System To power on the system, follow the steps below. Step 1: Connect the power cord to the power adapter. Connect the other end of the power cord to a power source. Ensure to connect the power cord to a socket-outlet with earthing connection. -
Page 16: Jrx12 Overview
OFT10W-ADLN 2.2 JRX12 Motherboard Overview... -
Page 17: Jrx12 Jumper And Connector List
2.3 JRX12 Jumper and Connector List You can configure your board to match the needs of your application by setting jumpers. A jumper is the simplest kind of electric switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them. - Page 18 OFT10W-ADLN JSD1 Micro SD card slot 1 x Micro SD slot JNGFF2 M.2 E-Key 1 x M.2 2230 Key E JUC1 BIOS ROM Socket JMIPI MIPI Port 40 x 1 FPC, pitch 0.30 mm JDCIN2 DC Power-in connector 2 x 2P pitch wafer 1 x 12V~24V wide range x 5A ;...
-
Page 19: Jrx12 Jumpers & Connectors Settings
2.4 JRX12 Jumpers & Connectors settings 2.4.1 A-MIC connector (JAMIC1) Signal MIC_JD# AMIC_IN GNDA 2.4.2 General purpose I/O connector (JDIO1) Signal PIN PIN Signal DIO_GP20 DIO_GP10 DIO_GP21 DIO_GP11 DIO_GP22 DIO_GP12 DIO_GP23 DIO_GP13 DIO_GP24 DIO_GP14 DIO_GP25 DIO_GP15 DIO_GP26 DIO_GP16 DIO_GP27 DIO_GP17 I2C_1_LV_SCL 18 I2C_1_LV_SDA +V5S_DIO... -
Page 20: Rtc Battery Connector (Jrtc)
OFT10W-ADLN 2.4.3 RTC Battery connector (JRTC1) Signal +RTCBATT 2.4.4 Speaker connector (JSPK1) Signal SPK_L+ SPK_L- SPK_R+ SPK_R-... -
Page 21: Rs232/Rs-485 Connector (Jrs485)
2.4.5 RS232/RS-485 connector (JRS485) Signal PIN PIN Signal +3.3V 485TX+ 232-RXD 485TX- 232-TXD 2.4.6 I2C connector (JI2CTP) Signal TOUCH_RST#_R I2C_5_SDA_R I2C_5_SCL_R TOUCH_INT#_R +3.3VA_I2CTP... -
Page 22: Usb Touch Connector (Jusbtp)
OFT10W-ADLN 2.4.7 USB Touch connector (JUSBTP) Signal +5V_TOUCH USB2_P5_N_L USB2_P5_P_L 2.4.8 Touch button board connector (JTB1) Signal PIN PIN Signal +PWR_JTB1 (5V) BU1_TV_3V RSTBTN VOL_DOWN_3V VOL_UP_3V BU_BR+_3V PWRBTN_3V BU7_3V BU_BR-_3V LED_ORANGE_R 12 LED_GREEN_R... -
Page 23: Sensor Connector (Jsense)
2.4.9 Sensor connector (JSENSE) Signal PIN PIN Signal +3VS_SEN_CONN +3VS_SEN_CONN I2C_1_SCL_3.3V_CONN I2C_0_SCL_3.3V_CONN I2C_1_SDA_3.3V_CONN I2C_0_SDA_3.3V_CONN SENSE1_IRQ SENSE0_IRQ 2.4.10 Camera connector (JCAM1) Signal PIN PIN Signal +CAM_VCC +DMIC_VCC USB2_P6_N_R CAM_DMIC_CLK_R USB2_P6_P_R CAM_DMIC_DAT_R... -
Page 24: Usb Touch Connector (Jusb20)
OFT10W-ADLN 2.4.11 USB Touch connector (JUSB20) Signal +5V_USB USB2_P4_N_R USB2_P4_P_R... -
Page 25: Drivers Installation
3. Drivers Installation All the drivers are available on BCM website (https://www.bcmcom.com). Type the model name and press Enter to find all the relevant software, utilities, and documentation. Note: The panel PC with projected capacitive type touchscreen and Windows 10 (or later) OS does not require touch driver installation. -
Page 26: Install Chipset Driver
OFT10W-ADLN 4.1 Install Chipset Driver All drivers can be found on the BCM Website: www.bcmcom.com. Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. If the warning message appears while the installation process, click Continue to go on. -
Page 27: Install Vga Driver
4.2 Install VGA Driver Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. If the warning message appears while the installation process, click Continue to go on. Step 3. Click Start. Step 1. Click Begin installation. Step 4. -
Page 28: Install Me Driver
OFT10W-ADLN 4.3 Install ME Driver Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. If the warning message appears while the installation process, click Continue to go on. Step 3. Click Next. -
Page 29: Install Audio Driver
4.4 Install Audio Driver Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 3. Installing. Step 1. Click YES. Step 2. Click OK. -
Page 30: Install Lan Driver
OFT10W-ADLN 4.5 Install LAN Driver Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. If the warning message appears while the installation process, click Continue to go on. Step 3. Click Finish to complete setup. -
Page 31: Install Bluetooth Driver
4.6 Install Bluetooth Driver Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. If the warning message appears while the installation process, click Continue to go on. Step 1. Click InstallDriver Step 3. Installing will auto start and complete in background. -
Page 32: Install Gpio Driver
OFT10W-ADLN 4.7 Install GPIO Driver Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. If the warning message appears while the installation Step 3. Click OK. process, click Continue to go on. -
Page 33: Install Hid Driver
4.8 Install HID Driver Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. If the warning message appears while the installation process, click Continue to go on. Step 3. Click Next. Step 1. Click Next. Step 4. -
Page 34: Install Sio Driver
OFT10W-ADLN 4.9 Install SIO Driver Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. If the warning message appears while the installation process, click Continue to go on. Step 3. Click Next. -
Page 35: Install Wifi Driver
4.10 Install wifi Driver Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. If the warning message appears while the installation process, click Continue to go on. Step 1. Click Next. Step 2. Click Finish to complete setup.
