- Page 1 SMA-X8I, REV-SA03 NXP IMX8M Mini, SMARC V2.1 RISC Module User’s Manual Ed – 27 May 2021 Part No. E2047SX8I00R...
- Page 2 SMA-X8I, REV-SA03 User’s Manual FCC Statement THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE. (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
-
Page 3: Table Of Contents
CAN Bus connector (J12) ......................23 2.6.12 MIPI LCD connector (J8) ......................24 2.6.13 RTC connector (JRTC1) ......................25 3. Mechanical Drawing ....................26 4. Linux User Guide ......................29 4.1 Flash Yocto 2.5 to SMA-X8I ..................30 SMA-X8I, REV-SA03 User’s Manual 3... -
Page 4: Getting Started
1.2 Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x SMA-X8I Risc Module 1 x REV-SA03 Carrier board 4 SMA- X8I, REV-SA03 User’s Manual... -
Page 5: Document Amendment History
User’s Manual 1.3 Document Amendment History Revision Date Comment May 2021 Initial Release SMA-X8I, REV-SA03 User’s Manual 5... -
Page 6: Manual Objectives
We strongly recommend that you study this manual carefully before attempting to set up SMA-X8I series or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance. -
Page 7: System Specifications
4. Test Axis : X,Y and Z axis Operation 5. 30 minutes per each axis 6. IEC 60068-2-64 Test:Fh 7. Storage : CF or SSD Random 1 Test Acceleration : 3G Vibration 2 Test frequency : 5~500 Hz SMA-X8I, REV-SA03 User’s Manual 7... - Page 8 SMA-X8I, REV-SA03 User’s Manual Non-Operation 3 Sweep：1 Oct/ per one minute. (logarithmic) 4 Test Axis : X,Y and Z axis 5 Test time :30 min. each axis 6 System condition : Non-Operating mode 7. Reference IEC 60068-2-64 Testing procedures 1. Wave form：Half Sine wave 2.
- Page 9 4 Test Axis : X,Y and Z axis Non-Operation 5 Test time :30 min. each axis 6 System condition : Non-Operating mode 7. Reference IEC 60068-2-64 Testing procedures Bump Test 1. Wave form：Half Sine wave SMA-X8I, REV-SA03 User’s Manual 9...
- Page 10 SMA-X8I, REV-SA03 User’s Manual 2. Acceleration Rate：10g for operation mode 3. Duration Time：11ms 4. No. of Shock：Z axis 1000 times 5. Test Axis: Z axis 6. Operation mode 7. Reference IEC 60068-2-29 Testing procedures Test Eb : Bump Test Note: Specifications are subject to change without notice.
-
Page 11: Architecture Overview-Block Diagram
User’s Manual 1.6 Architecture Overview—Block Diagram The following block diagram shows the architecture and main components of SMA-X8I. SMA-X8I, REV-SA03 User’s Manual 11... - Page 12 SMA-X8I, REV-SA03 User’s Manual The following block diagram shows the architecture and main components of REV-SA03. 12 SMA- X8I, REV-SA03 User’s Manual...
-
Page 13: Hardware Configuration
User’s Manual 2. Hardware Configuration SMA-X8I, REV-SA03 User’s Manual 13... -
Page 14: Sma-X8I Product Overview
SMA-X8I, REV-SA03 User’s Manual 2.1 SMA-X8I Product Overview 2.2 SMA-X8I Jumper List The following tables list the function of each of the board’s connectors. Jumpers Label Function Note Boot Mode selector 1 DIP switch 8pin Boot Mode selector 2 DIP switch 4pin... -
Page 15: Sma-X8I Setting Jumpers
User’s Manual 2.3 SMA-X8I Setting Jumpers 2.3.1 Boot Mode selector 1/2 (S1/S2) Programming mode S1: 10XXXXXX S2: XXXX X=don’t care eMMC boot SPI boot SD boot SMA-X8I, REV-SA03 User’s Manual 15... -
Page 16: Rev-Sa03 Product Overview
SMA-X8I, REV-SA03 User’s Manual 2.4 REV-SA03 Product Overview 16 SMA- X8I, REV-SA03 User’s Manual... -
Page 17: Rev-Sa03 Connector List
2 x 1 wafer, pitch 1.25mm JRTC1 RESET KEY POWER KEY DC Jack connector Micro SD slot USB3.0-Type A connector USB2.0-Type A connector USB2.0-Type C connector RJ-45 Ethernet HP Jack connector SMARC connector SIM Card slot SMA-X8I, REV-SA03 User’s Manual 17... -
Page 18: Rev-Sa03 Setting Connectors
SMA-X8I, REV-SA03 User’s Manual 2.6 REV-SA03 Setting Connectors 2.6.1 Speaker L connector (CN1) Signal SPK_L+ SPK_L- 2.6.2 Speaker R connector (CN2) Signal SPK_R+ SPK_R- 18 SMA- X8I, REV-SA03 User’s Manual... -
Page 19: Mipi Csi Screen Connector (J6)
2.6.3 MIPI CSI Screen connector (J6) Signal PIN PIN Signal 30 MIPI_CSI_CLKN MIPI_CSI_D0P MIPI_CSI_CLKP MIPI_CSI_D0N MIPI_CSI_D1P MIPI_CSI_D2P MIPI_CSI_D1N MIPI_CSI_D2N VCC18_DVP MIPI_CSI_D3P MIPI_CSI_D3N VCC1.5_DVP CSI_SDA CSI_MCLK0 CSI_SCL CSI_RST VCC28_DVP CSI_PWDN AVDD28_DVP 2.6.4 LCD Backlight connector (J10) Signal LCD_5V LCD0_BL_PWM LCD0_BL_EN LCD_12V SMA-X8I, REV-SA03 User’s Manual 19... -
Page 20: General Purpose I/O Connector (J15)
SMA-X8I, REV-SA03 User’s Manual 2.6.5 General purpose I/O connector (J15) Signal PIN PIN Signal VIO_3V3 DIO_I2C_SDA 17 DIO_I2C_SCL DO_7 DI_7 DO_6 DI_6 DO_5 DI_5 DO_4 DI_4 DO_3 DI_3 DO_2 DI_2 DO_1 DI_1 DO_0 DI_0 2.6.6 Touch Panel connector (J7) Signal... -
Page 21: Lvds Connector (J9)
User’s Manual 2.6.7 LVDS connector (J9) Signal PIN PIN Signal +12V +12V LBCN_D8 D_LACN_D17 LBCP_D7 D_LACP_D16 LB3N_D6 LB2N_D9 LB3P_D5 LB2P_DCK LB1N_D11 LB0N_D13 LB1P_D10 LB0P_D12 D_LA3N_D15 D_LA2N_D19 D_LA3P_D14 D_LA2P_D18 D_LA1N_D21 D_LA0N_D23 D_LA1P_D20 D_LA0P_D22 LVDS_DDC_CLK LVDS_DDC_DAT +3.3V +3.3V SMA-X8I, REV-SA03 User’s Manual 21... -
Page 22: A53 Core Debug Connector (Uart) (J13)
SMA-X8I, REV-SA03 User’s Manual 2.6.8 A53 Core Debug connector (UART) (J13) Signal UART2_RS232_RX UART2_RS232_TX VCC_3V3 2.6.9 M4 Core Debug connector (UART) (J14) Signal UART4_RS232_RX UART4_RS232_TX VCC_3V3 22 SMA- X8I, REV-SA03 User’s Manual... -
Page 23: Uart3 Connector (J17)
User’s Manual 2.6.10 UART3 connector (J17) Signal VCC_3V3 UART3_RS232_TX UART3_RS232_RX 2.6.11 CAN Bus connector (J12) Signal CAN_L CAN_H SMA-X8I, REV-SA03 User’s Manual 23... -
Page 24: Mipi Lcd Connector (J8)
SMA-X8I, REV-SA03 User’s Manual 2.6.12 MIPI LCD connector (J8) Signal LEDA LEDA LEDK LEDK LEDK LA3N_D15 LA0N_D23 LA3P_D14 LA0P_D22 LACN_D17 LA1N_D21 LACP_D16 LA1P_D20 LA2N_D19 LA2P_D18 C_GPIO8 LCD_1V8 LCD_1V8 LCD_3V3 LCD_3V3 LCD_3V3 24 SMA- X8I, REV-SA03 User’s Manual... -
Page 25: Rtc Connector (Jrtc1)
User’s Manual 2.6.13 RTC connector (JRTC1) Signal VDD_RTC SMA-X8I, REV-SA03 User’s Manual 25... -
Page 26: Mechanical Drawing
SMA-X8I, REV-SA03 User’s Manual 3. Mechanical Drawing 26 SMA- X8I, REV-SA03 User’s Manual... - Page 27 User’s Manual SMA-X8I Unit: mm SMA-X8I, REV-SA03 User’s Manual 27...
- Page 28 SMA-X8I, REV-SA03 User’s Manual REV-SA03 Unit: mm 28 SMA- X8I, REV-SA03 User’s Manual...
-
Page 29: Linux User Guide
User’s Manual 4. Linux User Guide (Using with carrier board REV-SA03) SMA-X8I, REV-SA03 User’s Manual 29... -
Page 30: Flash Yocto 2.5 To Sma-X8I
SMA-X8I, REV-SA03 User’s Manual 4.1 Flash Yocto 2.5 to SMA-X8I 1. Connect your SMA-X8I with REV-SA03 to computer via type C USB cable. 30 SMA- X8I, REV-SA03 User’s Manual... - Page 31 User’s Manual 2. Download Yocto 2.5 image. For the download link, please contact our support team. 3. Set the jumper to OTG mode. SMA-X8I, REV-SA03 User’s Manual 31...
- Page 32 SMA-X8I, REV-SA03 User’s Manual S1: Set to 10101010 S2: Set to 0100 32 SMA- X8I, REV-SA03 User’s Manual...
- Page 33 5. In case that the following situation happens, it needs to install the drvier to SMA-I8X in Windows 7. (skip step 5 if this pronlem does not occur in your device) Download this package. Unzip the directory downloaded. Run “install.bat” as Administrator. SMA-X8I, REV-SA03 User’s Manual 33...
- Page 34 SMA-X8I, REV-SA03 User’s Manual 6. After flash image finish, disable power supplier. 7. Set the jumper to boot mode. S1:01101010 S2:0100 8. Power on and start to boot to Yocto 2.5. 34 SMA- X8I, REV-SA03 User’s Manual...
