Avalue ECM-5612 Single Board Computer In Stock Used and in Excellent Condition Buy Today! https://www.artisantg.com/67101-1 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s .
Page 2
Quick Installation Guide ECM-5612/5613 Series All-in-One Tualatin Pentium III/Celeron Single Board with LCD, LVDS, AC97 Audio, IEEE-1394, Dual 10/100Base-Tx Ethernet Interfaces, & 4COMs Ed – 24 March 2003 Part No. 2017561203R...
INTERFERENCE TO RADIO COMMUNICATIONS. OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO CORRECT THE INTERFERENCE AT HIS OWN EXPENSE. 2 ECM-5612/5613 Series Quick Installation Guide...
Page 4
Applications that are described in this manual are for illustration purposes only. Evalue Technology Inc. makes no representation or warranty that such application will be suitable for the specified use without further testing or modification. ECM-5612/5613 Series Quick Installation Guide 3...
Evalue has come to be known. Your satisfaction is our primary concern. Here is a guide to Evalue’s customer services. To ensure you get the full benefit of our services, please follow the instructions below carefully. 4 ECM-5612/5613 Series Quick Installation Guide...
Page 6
Room 909, 9F, Section B, No.900, Suite 210, 200 Tornillo Way, Yisan Road, Caohejing Hi-tech Park, Tinton Falls, NJ 07712 Shanghai 200233, China Tel : +86-21-5423-4170 Tel: +1-732-578-0200 Fax : +86-21-5423-4171 Fax: +1-732-578-0250 http://www.evalue-tech.com http://www.evalue-tech.com E-mail: service.china@evalue-tech.com E-mail: service.usa@evalue-tech.com ECM-5612/5613 Series Quick Installation Guide 5...
Page 7
A product returned without proof of the purchase date is not eligible for warranty service. 5. Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer. 6 ECM-5612/5613 Series Quick Installation Guide...
Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 ECM-5612/5613 series All-in-One Tualatin Pentium III/Celeron Computing Module 1 Quick Installation Guide 1 CD-ROM or DVD-ROM contains the followings: — User’s Manual (this manual in PDF file) —...
Page 9
ECM-5612/5613 Series 2. Jumper & Connector Jumper & Connector Layout 8 ECM-5612/5613 Series Quick Installation Guide...
Page 10
3 x 1 header, pitch 2.54mm COM3 pin 9 signal select 3 x 2 header, pitch 2.0mm COM4 pin 9 signal select 3 x 2 header, pitch 2.0mm AT / ATX power select 3 x 1 header, pitch 2.0mm ECM-5612/5613 Series Quick Installation Guide 9...
Page 11
5 x 2 header, pitch 2.54mm USB1 CRT connector 8 x 2 header, pitch 2.54mm VGA1 STN LCD contrast adjustment connector 3 x 1 header, pitch 2.54mm LCD Backlight brightness adjustment 3 x 1 header, pitch 2.54mm connector 10 ECM-5612/5613 Series Quick Installation Guide...
Page 12
Quick Installation Guide 3. Hardware Configuration Setting Jumpers 3.1.1 COM2 RS-232/422/485 Select (J1, J3) The ECM-5612/5613 series COM2 serial port can be selected as RS-232, RS-422, or RS-485 by setting J1 & J3. COM2 Select (J1, J3) RS-232* RS-422 RS-485...
Page 13
ECM-5612/5613 Series 3.1.3 COM3 / 4 Pin 9 Signal Select (J6, J7) The ECM-5612/5613 series COM3 / 4 pin 9 signal can be selected as +12V, +5V, or Ring by setting J6 / J7. COM3 Select (J6) +12V Ring* 6 4 2...
Page 14
J9 to 1-2 closed. Set J9 to 2-3 closed, if ATX power supply is to be used. AT/ATX Power Select (J9) AT P/S* ATX P/S * default Note: Set J4 to 2-3 closed. If AT power supply is to be used. ECM-5612/5613 Series Quick Installation Guide 13...
Page 15
ECM-5612/5613 Series Connector Definitions 3.2.1 Keyboard and PS/2 Mouse Connector (CN1) Signal Signal KDAT KCLK MDAT MCLK 3.2.2 Front Panel Connector (CN6) Signal Signal HD_LED PWBTI RSTIN 14 ECM-5612/5613 Series Quick Installation Guide...
Page 16
Pin Header Serial Port 1 / 2 / 3 / 4 Connector in RS-232 Mode (CN7) Signal Signal DCD1 DSR1 RxD1 RTS1 TxD1 CTS1 DTR1 DCD2 DSR2 RxD2 RTS2 TxD2 CTS2 DTR2 DCD3 DSR3 RxD3 RTS3 TxD3 CTS3 DTR3 RI3/5V/12V DCD4 DSR4 RxD4 RTS4 TxD4 CTS4 DTR4 RI4/5V/12V ECM-5612/5613 Series Quick Installation Guide 15...
Page 17
3.2.5 Pin Header Serial Port 2 Connector in RS-422 Mode (CN7 / Pin 11~20) Signal Signal 3.2.6 Pin Header Serial Port 2 Connector in RS-485 Mode (CN7 / Pin 11~20) Signal Signal DATA- DATA+ 16 ECM-5612/5613 Series Quick Installation Guide...
Page 18
Signal CD_GND CD_L CD_GND CD_R 3.2.8 Audio / TV Output Connector (CN9) Signal Signal Mic Bias AGND AGND Line-Out L Line-Out R SPK L SPK R Line-In L Line-In R AGND Yout Cout COMP ECM-5612/5613 Series Quick Installation Guide 17...
Page 19
ECM-5612/5613 Series 3.2.8.1 Primary LCD Panel Connector (CN11) Signal Signal 3.3V 3.3V Vcon SHFCLK ENVEE ENBKL 18 ECM-5612/5613 Series Quick Installation Guide...
Page 20
Quick Installation Guide 3.2.9 Secondary LCD Panel Connector (CN12) Signal Signal 3.3V 3.3V Vcon ECM-5612/5613 Series Quick Installation Guide 19...
Page 22
Quick Installation Guide 3.2.11 Signal Configuration – DSTN Displays DSTN Pin name 8-bit 16-bit 24-bit 8-bit 16-bit 24-bit 16-bit 24-bit ECM-5612/5613 Series Quick Installation Guide 21...
Page 23
The principle of attachment of TFT panels is that the bits for red, green, and blue use the most significant bits and skip the least significant bits if the display interface width of the TFT panel is insufficient. 22 ECM-5612/5613 Series Quick Installation Guide...
Page 24
ZV13 ZV12 ZV15 ZV14 ZV-VS ZV-HREF ZV-LCLK 3.2.14 Signal Description – Zoom Video Port Connector (CN14) ZV [15:0] ZV-port data bus. Video input ZV-LCLK ZV-port clock ZV-HREF ZV-Port Horizontal Sync. ZV-VS ZV-Port Vertical Sync. ECM-5612/5613 Series Quick Installation Guide 23...
Page 25
+12V Note: For inverters with adjustable Backlight function, it is possible to control the LCD brightness through the VR signal (pin 4) controlled by VR1. Please see the VR1 section for detailed circuitry information. 24 ECM-5612/5613 Series Quick Installation Guide...
Page 26
Port 3 Twisted Pair A Positive. XTPA2P XTPA2M Port 3 Twisted Pair A Negative. XTPB2P Port 3 Twisted Pair B Positive. XTPB2M Port 3 Twisted Pair B Negative. 3.2.20 Power Connector (PWR1) Signal +12V -12V ECM-5612/5613 Series Quick Installation Guide 25...
Page 27
ECM-5612/5613 Series 3.2.21 USB Connector (USB1) Signal CH1 CH2 Signal VCC1 VCC2 3.2.22 CRT Connector (VGA1) Signal Signal GREEN BLUE HSYNC VSYNC DCLK 26 ECM-5612/5613 Series Quick Installation Guide...
