C>Tec=-0
Is a product of
Energy Recovery Ventilator
v Read this Manual before the operation
and keep it for reference.
v Read all safety precautions on the
manual, improper use can cause
serious injury.
AIR CONDITIONING
OMEC5/.\{)
AIR CONDITIONING
ERVD-F Series
Installation MANUAL
ENGLISH
Environment a 1 Te ch no 1 o g i e s LLC.
Specification and performance data listed herein are subject to change without notice
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Omega OTEC ERVD-F Series
Summary of Contents for Omega OTEC ERVD-F Series
- Page 1 C>Tec=-0 Is a product of Environment a 1 Te ch no 1 o g i e s LLC. OMEC5/.\{) AIR CONDITIONING ERVD-F Series Energy Recovery Ventilator Installation MANUAL ENGLISH v Read this Manual before the operation and keep it for reference. v Read all safety precautions on the manual, improper use can cause serious injury.
- Page 2 Energy Recovery Ventilator ERVD015A3N-FCN030 ERVD020A3N-FCN040 ERVD030A3N-FCN050 ERVD040A3N-FCN060 ERVD050A3N-FCN080 ERVD060A3N-FCN100 ERVD080A3N-FCN130 ERVD090A3N-FCN150 ERVD120A3N-FCN200 Thank you for choosing OMEGA ERV Products. Please read this USER MANUAL carefully prior to using and keep it for further reference.
-
Page 3: Table Of Contents
TA B L E OF CONTENTS Product Overview Usage Guide Installation Instruction Maintenance and Service Unit Dimension Technical Specifications... -
Page 4: Product Overview
PRODUCT OVERVIEW ERV is energy-saving equipment used for the recovery of exhaust air energy from air- conditioner.Such device does not require the master air conditioner to provided cold and heat source but exchanger heat by means of directly recovery of the air in air-conditioner room. Therefore, it is the standard configuration of energy-saving and environmental-friendly, healthy buildings,and an ideal partner of air-conditioning. - Page 5 Sketch Diagram Bypass air-duct reserve Exhaust air inlet Unit core Fresh air outlet ERVD015-090 Fresh air inlet Electric control box Maintenance doo Exhaust air outlet Polluted air inlet Unit core Fresh air outlet Fresh air inlet Electric control box ERVD120 Maintenance doo Exhaust air outlet Sel ec t i o n G u i d e...
-
Page 6: Usage Guide
USAGE GUIDE Model:ERVD015A3N-FCN030～ERVD120A3N-FCN200 ON/ OFF: Press “1”button once to turn on the unit,press it again to turn off the unit. ON: the unit is running. OFF: the unit stops ,but the settings will save. Fan motor control: Press “ ”button to choose fan speed. “... -
Page 7: Installation Instruction
INSTALLA TION INSTRUCTIONS Safety Precautions Do not install the unit at the place where have heat resource or fire. Do not install the unit at the place where may have flammable gas leakage Do not install the unit at the lampblack place such as kitchen. Do not install the unit at the humid place such as bathroom. -
Page 8: Installation Check
Installation Check First check whether the unit is complete and non-destructive before installation , and then open the panel, turn the fan by hand, check whether has the metal friction sound, if has, adjust the wheel to make sure it does not touch the unit. - Page 9 Installation of Drain Pipe Avoid pipe over bending\repeated bending and reducing the diameter of connecting pipe When installing , outdoor pipes should slope downward to prevent water immersion. Insulating layer should be made to prevent condensation in outdoor pipe (if necessary, including the indoor pipe) .
-
Page 10: Unit Wiring Diagram
Unit Wiring Diagram Single Phase: AC 220V~50Hz ERVD015A3N-FCN030 ERVD090A3N-FCN150 exhaust air supply air motor motor B L K B L K back of operat ion Hi Mi Lo Hi Mi Lo M4 M3 M2 M1 L ERVD120A3N-FCN200 supply air exhaust air motor motor BL K... -
Page 11: Maintenance And Service
MAINTENANCE AND SERVICE Turn off the operation switch/special circuit breaker before maintenance and service. If the total heat exchanger is used for a long time, the performance of ventilation will decrease due to dirty or blocked filter. Clean the filter periodically as the accumulation of dust or debris on the heat exchange core. Pay special attention in April to May if there are a lot of willow catkins flying in the sky, and they are more likely to attach with the filter, which will decrease the ventilation effect, so clean the filter 2 times every month during such period. -
Page 12: Unit Dimensions
UNIT DIMENSIONS ERVD015A3N-FCN030 ERVD090A3N-FCN150 Fresh air Exhaust inlet air inlet Fresh air Exhaust outlet air outlet ERVD120A3N-FCN200 Exhaust air inlet Fresh air inlet Exhaust Fresh air outlet air outlet Model E R V D 0 1 5A 3 N -F C N 0 3 0 E R V D 0 2 0A 3 N -F C N 0 4 0 1026 E R V D 0 3 0A 3 N -F C N 0 5 0... -
Page 13: Technical Specifications
TECHNICA L SPECIFICATIONS Static Air flow Power Unit dimension Model weight pressure volume supply (mm) (kg) (Pa) (m3/h) ERVD015A3N-FCN030 934×635×270 ERVD020A3N-FCN040 934×840×270 ERVD030A3N-FCN050 1026×940×270 ERVD040A3N-FCN060 1026×940×270 ERVD050A3N-FCN080 220V/50Hz 1282×918×388 1 Phase ERVD060A3N-FCN100 1282×918×388 1000 ERVD080A3N-FCN130 1282×1168×388 1300 ERVD090A3N-FCN150 1282×1168×388 1500 ERVD120A3N-FCN200 1600×1250×525 2000... - Page 14 FAN DATA...
- Page 15 FAN DATA...
- Page 16 ENVIRONMENTAL TECHNOLOGIES LLC. & 11380 Interchange Circle North Miramar,FL 33025 .USA Tel: 305 901 1270 Fax: 954 212 8280 OMEGA ERVD Installation & Owner's Manual o,ec CONDITIONING Showroom Technolo gy Center 1031 Ives Dairy Road,# 228 Miami, Fla. 33179. USA...
