Summary of Contents for Ocular IQ WALLBOX IOCAH13-7S
- Page 1 IQ WALLBOX INSTALLATION GUIDE IOCAH13-7S / IOCAH13-7T ocularcharging.com.au IOCAH13-22S / IOCAH13-22T sales@ocularcharging.com.au 1300 912 650 Version 2.0...
-
Page 2: Table Of Contents
CONTENTS Specifications ......................3 Product Overview ......................4 Safety Instructions .......................5 Installation Notes and Box Contents ................6 Wall Mounting ......................7 Internet Connection and Charger Mounting ...............8 Pre and Post-Energise Testing ..................9 Web-Interface Access and WIFI Setup ..............10 Installation Verification ....................11 Appendix A - Troubleshooting ...................12 Appendix B - Charger Screen Details ..............13 Appendix C - Change the Charger to ‘Start Charging on Plug‘... -
Page 3: Specifications
Ethernet, Wi-Fi Communication Type Modbus (TCP/IP) Energy Meter MID Meter Load Control Compatible with Ocular Load Controller or OCPP smart profiles General Data -30°C to +50°C Ambient Air Temperature for Operation -40°C to +70°C Ambient Air Temperature for Storage Working Humidity... -
Page 4: Product Overview
PRODUCT OVERVIEW Item LED indicator 2.8’’ LCD screen Status indicator, Fault, Online, Charging RFID card reader Physical button Type-2 Socket or plug storage (Tethered model) -
Page 5: Safety Instructions
SAFETY INSTRUCTIONS This document contains important instructions and warnings that must be followed when installing and maintaining the Ocular IQ Wallbox. WARNINGS Installation and maintenance of the charger should only be conducted by a qualified and licensed electrician. Make sure that materials used, and installation procedures follow local building codes and safety standards, including AS/NZS 3000:2018. -
Page 6: Tools Required
NOTES BEFORE INSTALLATION The charger should be protected by an external Residual Current Device (RCD) to be installed in the upstream circuit which complies with the following: • Type-A Rated residual operating current not exceeding 30 mA • Required as per Appendix P, AS/NZS 3000:2018 Australian and New Zealand Standards for EV charging stations. -
Page 7: Wall Mounting
WALL MOUNTING AND WIRING 1. Remove the backplate from the charger by sliding it down. Mount the backplate to the wall with the included screws. 2. Connect the cable through the bottom of the junction box. Ensure conduit is connected to the bottom of the power box. -
Page 8: Internet Connection And Charger Mounting
INTERNET CONNECTION AND CHARGER MOUNTING 1. Internet Connection. The charger must be successfully connected to the internet during the installation process to ensure proper operation. There are two options for internet connectivity: Ethernet (recommended for maximum internet stability) Connect the ethernet cable to the WAN port on the backplate. -
Page 9: Pre And Post-Energise Testing
PRE- AND POST-ENERGISE TESTING 1. Pre-energising • Ensure connections are secure and power on the system. • Verify all cabling is wired properly. • Energise the charger. • LED Lights and Screen should turn on. • If the LED flashes red please refer to the Troubleshooting page. 2. -
Page 10: Web-Interface Access And Wifi Setup
Please hand this book to the user after the installation so that they can keep track of the new password. After entering the username and password, the Ocular web-interface will load. 3. (Optional): Set up WIFI configuration (not needed if ethernet is used) •... -
Page 11: Installation Verification
See Appendix B for more information. If the charger is showing (Server Error) then the charger will not function and this will likely require a return to site. Check the WiFi/ethernet connection. If problem persists, contact Ocular support on 1300 912 650. Connected to Ethernet... -
Page 12: Appendix A - Troubleshooting
It usually takes less than 10 seconds. If the status indicator doesn’t return to blue, turn OFF the charger and then back ON. If the situation persists, contact Ocular Charging for Technical Support. There is a critical error. Status indicator is solid Unplug the charging plug from the EV immediately. -
Page 13: Appendix B - Charger Screen Details
APPENDIX B – CHARGER SCREEN DETAILS LCD DISPLAY DETAILS This page contains icons displayed on the top left of the charger that may help diagnose or verify the operation of the charger. Active - Charger component/feature is enabled and operating effectively. Inactive - Charger component/feature has been disabled in the configuration settings for the charger. - Page 14 APPENDIX B – CHARGER SCREEN DETAILS Connect the charging plug Remove the charging plug Scan the QR code or swipe the Charging in process - Shows RFID card to start charging Session Duration, Total power used, charging current and voltage per phase Suspended by EV - Indicator that Suspended by EVSE - Indicator that...
-
Page 15: Appendix C - Change The Charger To 'Start Charging On Plug'
If the charger does not automatically start charging while testing, then it may not be set to charge on plug. Follow the steps below to change it. The user will be able to change this setting in the Ocular App later. • Follow the instructions on Page 9 to log into the charger web-interface. - Page 16 IQ WALLBOX ocularcharging.com.au sales@ocularcharging.com.au 1300 912 650...
