Chapter 1. ESP32-C5-DevKitC-1
Key Component
ESP32-C5-WROOM-1
Pin Header
5 V to 3.3 V DC/DC
3.3 V Power On LED
USB-to-UART Bridge
ESP32-C5 USB Type-C Port
Boot Button
Reset Button
USB Type-C to UART Port
RGB LED
J5
Start Application Development
Before powering up your ESP32-C5-DevKitC-1, please make sure that it is in good condition with no obvious sign
of damage.
Required Hardware
• ESP32-C5-DevKitC-1
• USB-A to USB-C cable
• Computer running Windows, Linux, or macOS
Note: Be sure to use a good quality USB cable. Some cables are for charging only and do not provide the needed
data lines nor work for programming the boards.
Software Setup Please proceed to
quickly and then flash an application example onto your board.
Contents and Packaging
Retail orders If you order a few samples, each ESP32-C5-DevKitC-1 comes in an individual package in either an
antistatic bag or any other packaging depending on your retailer.
For retail orders, please go to https://www.espressif.com/en/company/contact/buy-a-sample.
Wholesale Orders If you order in bulk, the boards come in large cardboard boxes.
For wholesale orders, please go to https://www.espressif.com/en/contact-us/sales-questions.
Espressif Systems
Description
ESP32-C5-WROOM-1 is a general-purpose module supporting Wi-Fi 6 in
2.4 & 5 GHz dual-band (802.11ax), Bluetooth® 5 (LE), Zigbee, and Thread
(802.15.4) with on-board PCB antenna.
All available GPIO pins (except for the SPI bus for flash) are broken out to the
pin headers on the board.
Power regulator that converts a 5 V supply into a 3.3 V output.
Turns on when the the board is connected to USB power.
Single-chip USB-to-UART bridge offering transfer rate up to 3 Mbps.
The USB Type-C port on the ESP32-C5 chip supports USB 2.0 full speed,
with a data transfer rate of up to 12 Mbps. Note that this port does not support
the 480 Mbps high-speed transfer mode. This port is used for power supply to
the board, flashing applications to the chip, and communication with the chip
via USB protocols, as well as for JTAG debugging.
Download button. Holding down Boot and then pressing Reset initiates
Firmware Download mode for downloading firmware through the serial port.
Press this button to restart the system.
Used for power supply to the board, flashing applications to the chip, as well as
communication with chip ESP32-C5 via the on-board USB-to-UART bridge.
Addressable RGB LED, driven by GPIO27.
Used for current measurement. See details in Section
ESP-IDF Get Started, which will help you set up the development environment
5
Submit Document Feedback
Current Measurement.
