- Page 1 BELLE 870/10029/2 03/25 PCLX 32E+, 32SE+ & 40E+ Operators Manual UKCA Declaration of Conformity EC/EU Declaration of Conformity...
-
Page 2: Ukca Declaration Of Conformity
M14 4PN, UK carried out Internal Control of Production with Assessment of Technical Documentation and Periodical Checking as per Schedule 9 of SI 2001 1701 Technical Files are held by Ray Neilson at the Altrad Belle address stated above:- Place of Declaration:-... -
Page 3: Ec Declaration Of Conformity (Doc)
EC Declaration Of Conformity (DOC) We, Altrad Belle, Sheen, Nr. Buxton, Derbyshire, SK17 0EU, GB declare that the DoC is issued under our sole responsibility and belongs to the followings product(s): PRODUCT TYPE ..... Signed by: MODEL........Ray Neilson SERIAL No....... -
Page 4: Table Of Contents
Contents CONTENTS PAGE NUMBER UKCA DECLARATION OF CONFORMITY .............................. 2 EC/EU DECLARATION OF CONFORMITY ............................. 3 INTRODUCTION ....................................... 5 WARNING ...................................... 5 Serial Numbers....................................6 MACHINE DESCRIPTION General......................................6 Standard Operation ..................................6 Danger Zone ....................................6 Main Components Locations ................................7 Power Unit Components ................................ -
Page 5: Introduction
When replacements are required, insist on genuine Altrad Belle parts, as extensive damage is liable to result from the use of inferior quality parts. -
Page 6: Serial Numbers
The machine is intended to be used for the following, in safe environmental conditions as described in this manual. Any other use is not deemed suitable for this machine. Altrad Belle will not liable for any damage or injury resulting from any use other than outlined above. -
Page 7: Main Components Locations
Machine Description MAIN COMPONENT LOCATIONS A. Power Unit. D. Vibrator / Vibrator Housing. E. Vibrator Oil Check Plug. F. Control Handle. G. Lifting Eye. H. Belt Guard J. Motor Housing K. Baseplate L. Serial Plate... -
Page 8: Power Unit Components
Machine Description POWER UNIT COMPONENTS A. Battery Pack Compartment. B. Battery Pack Compartment Lid. C. Battery Retaining Latch. D. Serial Label E. Air Vent Intake BATTERY PACK COMPONENTS A. Battery Charge Level Button. B. Battery Charge Level Display. C. Serial Label. D. -
Page 9: Battery Charger
Machine Description BATTERY CHARGER A. Battery Pack Charging Dock B. AC Power Cable Socket C. Dock Indicator 1 D. Dock Indicator 2 J. Serial Label... -
Page 10: Technical Data
Technical Data STATIC DIMENSIONS Model PCLX 32E+ PCLX 32SE+ PCLX 40E+ A - Operating Length (mm) 1055 1055 1055 B - Storage Length (mm) C - Width (mm) D - Operating Height (mm) 1036 1036 1036 E - Storage Height (mm) F - Plate Contact Width (mm) G - Plate Contact Length (mm) -
Page 11: General Data
Technical Data GENERAL DATA Model PCLX 32E+ PCLX 32SE+ PCLX 40E+ Motor (Hp / kW) 2.0 / 1.5 2.0 / 1.5 2.0 / 1.5 Motor Type Brushless Brushless Brushless Motor RPM 2600 2600 2600 Vibrator Force (KN) Frequency (Hz) Static Pressure (kg/m²) 1800 Max. -
Page 12: Safety Instructions
It is the responsibility of the operator to ensure that he/she fully understands how to operate this equipment safely. If you are unsure about the safe and correct use of the machine, consult your supervisor or Altrad Belle. -
Page 13: Battery Park
Safety Instructions OPERATING THE MACHINE CONT. • The compacting process will occasionally produce dust, which may be hazardous to your health. Always wear a mask that is suited to the type of dust being produced. • Check for visible damage to the ON/OFF button and housing. If damaged DO NOT operate the machine and arrange for repair. •... -
Page 14: Battery Charger
Safety Instructions BATTERY CHARGER • To reduce risk of injury, charge ONLY DP72104Z type rechargeable batteries. Other types of batteries may burst causing personal injury and damage. • This Battery Charger is not intended for use by children or persons with physical, sensory or mental limitations or a lack of experience or knowledge. -
Page 15: Weather Conditions
ENSURE that all consumables and replaced parts are disposed of safely and with minimum environmental impact. MODIFICATIONS & REPLACEMENT PARTS • NEVER • ALWAYS safety of the machine. This may also voide the Warranty. Genuine Altrad Belle replacement parts can be purchased online at www.Altrad-Belle247.com... -
Page 16: Safety Decals
Safety Instructions SAFETY DECALS A. Branding Decals B. Lifting Point Decal C. Safety Decal. D. Noise Decal. E. No Jetwash Decal. F. Battery Removal Decal. G. Cover Removal Decal. H. Motor Rating Deca. - Page 17 Safety Instructions SAFETY DECALS A - Branding Decals B - Lifting Point Decal Lifting point for use with a Sling or Mechanical Hoist. C. Safety Decal. Read the Wear Ear Wear Eye Wear Protective Operators Protection Protection Footwear Manual D - Noise Decal Indicates the Noise Level of the maxchine during operation.
-
Page 18: Reasons For Compaction
2. Over 1800kg/m² Force’ plate compactor. DUAL FORCE Altrad Belle studied the act then developed equipment to enable contractors to comply with the act’s requirements. The NRSWA Force’ base plates are divided into two areas providing two stages of compaction. -
Page 19: Charging The Battery Pack
Operating Instructions Stage 2 Stage 1 Stage 1: The full base area compacts the material like a standard machine. Stage 2: Refer to the Machine Description section to identify all components mentioned in this section. CHARGING THE BATTERY PACK The battery pack is not shipped fully charged. It is recommended to fully charge before use to ensure that CAUTION maximum run time can be achieved. -
Page 20: Removing The Battery Pack
Operating Instructions REMOVING THE BATTERY PACK CAUTION ENSURE the machine is switched OFF before removing the battery. 1. Stop the machine using the stop button. 2. Open the battery cover. 3. Push down lightly onto the top of the battery, at the same time press and release the battery retaining latch. Remove your hand from the top of the battery and it should rise slightly. -
Page 21: Transportation
Operating Instructions TRANSPORTATION CAUTION We RECOMMEND removing the battery pack from the power unit before transporting the machine. DO NOT use a Mechanical Hoist on the Hand Lifting Points. Where it is necessary to use lifting equipment to transport the machine, make sure the lifting equipment has a WLL (Working ONLY to the lifting point on the top of the machine. -
Page 22: Storage
Storage If the machine is not to be used for an long period of time it must be stored correctly to prevent deterioration or damage occuring during this period. Store the machine in a clean dry building with plenty of ventilation if possible. If you can only store outdoors, cover with a waterproof sheet / tarpaulin. -
Page 23: Service And Maintenance
A poorly maintained machine could be a danger to the operator and the other personnel on the worksite. ENSURE that the regular ALWAYS use genuine Altrad Belle replacement parts, the use of spurious parts may void your warranty. ALWAYS set the machine on stable, level ground. -
Page 24: Troubleshooting Guide
Remove some of the material. Low travel speed (plate sinking). Moisture content too high or too low. Remove material and adjust. Items marked with * should only be carried out by a competent electrician or Altrad Belle dealer. BATTERY PACK & CHARGER Problem Cause... -
Page 25: Dual Force' / Hauc / Nrswa Certificate
2. Alterations, additions or repairs carried out by persons other than Altrad Belle or their recognised agents. 3. Transportation or shipment costs to and from Altrad Belle or their recognised agents, for repair or assessment against a warranty claim, on any machine. - Page 26 ALTRAD BELLE Sheen, Nr. Buxton, Derbyshire, SK17 0EU, GB Tel. +44 (0)1298 84606 - Fax +44 (0)1298 84722 - Email: sales@altrad-belle.com www.Altrad-Belle.com BELLE EU IMPORTER ADDRESS LIGHT ADRESSE DE L'IMPORTATEUR - DIRECCIÓN DEL IMPORTADOR - ENDEREÇO DO IMPORTADOR - ADRES IMPORTEUR CONSTRUCTION IMPORTØRENS ADRESSE - IMPORTEUR ADRESSE - INDIRIZZO DELL'IMPORTATORE - IMPORTÖRENS ADRESS - IMPORTØRADRESSE...
