- Page 1 BELLE 870/40001/2 01/18 BHB BREAKERS Operators Manual Operators Manual Manuel De L'Opérateur Manual del Operador Manual de Operação Bedienungshandbuch Instrukcja Obsługi Рyкoвoдcтвo для oпepaтopa Oпepaтop Pъчeн Na’vod K Obzluze • Spare Parts Book • Pièces Détachées Manual de Utilizare • Libro Despiece Kezelõk Kézi •...
-
Page 2: Declaration Of Conformity
EC DECLARATION OF CONFORMITY / DECLARATION CE DE CONFORMITE / DECLARACIÓN DE CONFORMIDAD CE / DECLARAÇÃO CE DE CONFORMIDADE / EG-VERKLARING VAN OVEREENSTEMMING / EF OVERENSSTEMMELSESERKLÆRING We, Belle Group Sheen UK, Sheen, Nr. Buxton, Derbyshire, SK17 0EU, GB, hereby certify that if the product described within this certificate is bought from an authorised Belle Group dealer within the EEC, it conforms to the following EEC directives: 2006/42/CE (This directive replaces directive 98/37/EC), Electromagnetic Compatibility Directive 2004/108/CE (as amended by 89/336/EEC, 92/31/EEC &... - Page 3 EGKONFORMITÄTSERKLÄRUNG / DICHIARAZIONE CE DI CONFORMITÁ / EG-VERKLARING VAN OVEREENSTEMMING / EC SAMSVARSERKLÆRING / EY-YHDENMUKAISUUSILMOITUS / DEKLARACJA ZGODNOSCI Z PRZEPISAMI UE Wir, Belle Group Sheen UK, Sheen, Nr. Buxton, Derbyshire, SK17 0EU, GB, bestätige hiermit, dass, wenn das Produkt innerhalb dieser Bescheinigung ist von einem gekauft zugelassen Belle Group-Händler innerhalb der EWG, so entspricht sie den folgenden EG-Richtlinien: 2006/42/CE (Diese Richtlinie ersetzt die Richtlinie 98/37/EG), elektromagnetische Kompatibilität Richtlinie 2004/108/EG (geändert durch 89/336/EWG, 92/31/EWG und 93/68 EWG).
- Page 4 / EÜ VASTAVUSDEKLARATSIOON / ATBILSTĪBAS DEKLARĀCIJA / ES ATITIKTIES DEKLARACIJA / AVT Reliability Unit 2 Easter Court, Europa Boulevard, Warrington, Cheshire, WA5 7ZB, GB Belle Group Sheen UK, Sheen, Nr Buxton, Derbyshire, SK17 0EU, GB AVT Reliability Unit 2 Easter Court, Europa Boulevard, Warrington, Cheshire, WA5 7ZB, GB Dokumendid tehnilise müra kohta arhiveeritakse Belle Group peakontoris eelpoolmainitud aadressil.
- Page 5 My, Belle Group Sheen UK, Sheen, Nr. Buxton, Derbyshire, SK 17 0EU, Velké Británie AVT Reliability Unit 2 Easter Court, Europa Boulevard, Warrington, Cheshire, WA5 7ZB, Velká Británie. Belle Group Sheen UK, Sheen, Nr. Buxton, Derbyshire, SK17 0EU, GB, AVT Reliability Unit 2 Easter Court, Europa Boulevard, Warrington, Cheshire, WA5 7ZB, GB Belle Group Sheen UK, Sheen, Nr.
-
Page 6: Table Of Contents
(Be sure that you know how to switch the machine off before you switch on, in case you get into dif culty.) ALWAYS wear or use the proper safety items required for your personal protection. If you have ANY QUESTIONS about the safe use or maintenance of this unit, ASK YOUR SUPERVISOR OR CONTACT THE Altrad Belle +44 (0)1298 84606 Contents How to use this manual ..................................... -
Page 7: Machine Description
Machine Description Serial Plate +44 (0)1298 84606 +44 (0)1298 84722 A. Maximum permitted Hydraulic Oil Flow. sales@belle-group.co.uk www.Altrad-Belle.com B. Breaker Model. C. Maximum permitted Hydraulic Pressure. MODEL YEAR D. Serial Number. FLOW MAX. E. Year of Manufacture. PRESS. Decals A. Model Decal This Decal shows the Model Name of the Breaker. -
Page 8: Technical Data
Technical Data Model BHB12 BHB19 BHB19 USA BHB23 BHB23 UC BHB25X Hydraulic Flowrate (Ltrs/Min) Restrictor Open Open Open Open Open Open Weight (Kg) Working Pressure (Bar) 70 - 90 90 - 110 90 - 110 90 - 110 90 - 110 90 - 110 Max Pressure (Bar) Max. -
Page 9: Matching The Breaker To The Power Source
Matching The Breaker To The Power Pack Restrictor / Fitting Identi cation The tank Restrictors / Fittings can be identi ed by using this simple procedure. Check your Breaker and identify the P and T side of the body by looking for a letter stamp on the large bung. -
Page 10: Safety Instructions
Safety Instructions To reduce risk of serious injury or death to yourself or others, read these safety instructions before operating the machine. Post these safety instructions at work locations, provide copies to employees, and make sure that everyone reads the safety instructions before operating or servicing the machine. WARNING Follow all safety instructions given in this manual. - Page 11 Safety Instructions Hydraulic Oil and Lubrication Hazards Thin jets of hydraulic oil under high pressure can penetrate the skin and cause permanent damage. • Never use your hands when searching for oil leaks. • Keep your face away from any possible leaks. •...
- Page 12 Machine Modi cation Hazard Any machine modi cation not approved by Altrad Belle may result in serious injuries to yourself or others. • The machine must not be modi ed without Altrad Belles permission.
-
Page 13: General Safety
Wear clothing suitable for the work you are doing. Tie back long hair and remove any jewellery which may catch in the equipment’s moving parts. Recommended Hydraulic Oil In order to protect the environment, Altrad Belle recommends the use of biologically degradable hydraulic oil. • Viscosity (preferred) 20-40 cSt. -
Page 14: Environment
Ensure that any power source you plan to use is compatible with the breaker model used (see the “Technical data” section). Altrad Belle recommends using an LFD oil ow divider, if the ow from the power source can exceed the maximum allowed oil ow. -
Page 15: Operating Instructions
Quick-release couplings The original Altrad Belle hydraulic hoses are tted with Flat-Face quick-release couplings that are strong and easy to clean. The quick- release couplings are tted so that the male connection supplies oil and the female connection receives oil. - Page 16 Operating Instructions Choosing working tool A correct working tool is a prerequisite for good operation. To avoid unnecessary machine damage, it is important to choose working tools of a high quality. The narrow chisel should be used for demolition and cutting work in concrete and other types of hard material. The moil point should only be used for creating holes in concrete and other types of hard material.
-
Page 17: Ehtma - Code Of Practice
Operating Instructions STARTING A CUT 1) Stand steady and make sure that your feet and hands are at a safe distance from the working Breaker. 2) Press the machine against the surface of the workpiece before starting. 3) Adjust the breaking distance (A) so that the working Breaker does not get stuck. 4) Do not try to cut too big a bite. -
Page 18: Service & Maintenance
Inspection and service on the accumulator must only be done by a certi ed person. • For major service to the machine, contact the Altrad Belle or your nearest authorised dealer. NOTE!:- Maintenance must only be done by suitably quali ed and competent persons. Before doing any maintenance, make sure that the machine is safe and correctly sited on the ground. -
Page 19: Trouble Shooting Guide
Replace bushing or ‘Steel’. Warranty Your new Altrad Belle BHB Hydraulic Breaker is warranted to the original purchaser for a period of one-year (12 months) from the original date of purchase. The Altrad Belle warranty is against defects in design, materials and workmanship.
