- Page 1 Huawei OptiXstar EG8141XR-10 Quick Start for QR code Issue Date 2022-09-20 HUAWEI TECHNOLOGIES CO., LTD.
- Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...
-
Page 3: Table Of Contents
Huawei OptiXstar EG8141XR-10 Quick Start for QR code Contents Contents 1 Placing the Device........................1 2 Connecting Cables........................3 3 Indicator Description......................5 4 Technical Specifications......................7 5 FAQs............................8 Issue 01 (2022-09-20) Copyright © Huawei Technologies Co., Ltd. -
Page 4: Placing The Device
● It is recommended that the computer and ONT be put far away from electric appliances that generate strong magnetic or electric fields, such as microwave ovens. Mounting an ONT on the desk The figure below shows an ONT that is horizontally placed on a desk. Issue 01 (2022-09-20) Copyright © Huawei Technologies Co., Ltd. - Page 5 ONT onto the screws. NO TE It is recommended that the screw be about 4 mm in diameter and longer than 20 mm. The screw head should be between 6mm and 9mm in diameter. Issue 01 (2022-09-20) Copyright © Huawei Technologies Co., Ltd.
-
Page 6: Connecting Cables
Huawei OptiXstar EG8141XR-10 Quick Start for QR code 2 Connecting Cables Connecting Cables Issue 01 (2022-09-20) Copyright © Huawei Technologies Co., Ltd. - Page 7 NOTE Reset Huawei ONTs with caution. Otherwise, the ONTs may fail to access the Internet. If an ONT cannot access the Internet after a reset, contact your Internet service provider.
-
Page 8: Indicator Description
No optical fiber is connected or there is no optical signal. WLAN Steady on The WLAN function is enabled. Blinking Data is being transmitted over the WLAN port. The WLAN function is disabled. Steady on The WPS function is enabled. Issue 01 (2022-09-20) Copyright © Huawei Technologies Co., Ltd. - Page 9 Blinks once The hardware is faulty. every 2 every 2 seconds seconds NO TE If the ONT is not powered on or the power switch is turned off, all indicators are off. Issue 01 (2022-09-20) Copyright © Huawei Technologies Co., Ltd.
-
Page 10: Technical Specifications
Dimensions (H x W x D): 40 mm x 240 mm x 151 mm (without external antenna and pads) ● Weight: Less than 700 g ● Maximum system power consumption: 16.6 W Issue 01 (2022-09-20) Copyright © Huawei Technologies Co., Ltd. -
Page 11: Faqs
How do I log in to the Huawei ONT web page? ● Wireless login Connect your mobile phone, pad, or PC to the Wi-Fi network of the Huawei ONT. Enter the IP address in the address box of a browser and press Enter. On the displayed login page, enter the username and password. - Page 12 ● Change the initial password after logging in to the web page for the first time. How do I change the Wi-Fi password? Log in to the Huawei ONT web page using your mobile phone, pad, or PC. For details, see "How do I log in to the Huawei ONT web page?"...
- Page 13 5 FAQs What can I do if I forget the Wi-Fi password? Log in to the Huawei ONT web page using your PC by wired login. For details, see "How do I log in to the Huawei ONT web page?"...
- Page 14 How do I restore the Huawei ONT to factory setting? Press Reset by using a needle-type object for longer than 10s to restore factory defaults and reset the Huawei ONT. If the indicator is off and then is lit, the system restarts successfully.
