- Page 1 Ordering Contact: EG8145V5 www.baudcom.com.cn Quick Start info@baudcom.com.cn +862137709251 Issue Date 2020-02-26 HUAWEI TECHNOLOGIES CO., LTD.
- Page 2 Notice The purchased products, services and features are stipulated by the contract made between Huawei and the customer. All or part of the products, services and features described in this document may not be within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information, and recommendations in this document are provided "AS IS"...
-
Page 3: Table Of Contents
EG8145V5 Quick Start Contents Contents 1 Placing the Device........................1 2 Connecting Cables........................3 3 Indicator Description......................5 4 Technical Specifications......................7 5 FAQs............................8 Issue 03 (2020-02-26) Copyright © Huawei Technologies Co., Ltd. -
Page 4: Placing The Device
The actual product prevails. Mounting an ONT onto a Wall Mark two positions with the same spacing as that between the two mounting holes of the ONT using a marker on a wall. Issue 03 (2020-02-26) Copyright © Huawei Technologies Co., Ltd. - Page 5 Use a screwdriver to fasten the screws into the expansion bolts, reserving 3 mm ends out of the wall, and mount the ONT onto the screws. It is recommended that the screw be about 4 mm in diameter and longer than 20 mm. Issue 03 (2020-02-26) Copyright © Huawei Technologies Co., Ltd.
-
Page 6: Connecting Cables
● To ensure normal use of fibers, make sure that the fiber bending radius is larger than 30 Item Description On/Off Powers the ONT on or off. Power Connects to a power adapter. Issue 03 (2020-02-26) Copyright © Huawei Technologies Co., Ltd. - Page 7 NOTE Reset Huawei ONTs with caution. Otherwise, the ONTs may fail to access the Internet. If an ONT cannot access the Internet after a reset, contact your Internet service provider.
-
Page 8: Indicator Description
Data is being transmitted on the USB port. The system is not powered on or the USB port is not connected. WLAN Steady on The WLAN function is enabled. Blinking Data is being transmitted over the WLAN port. Issue 03 (2020-02-26) Copyright © Huawei Technologies Co., Ltd. - Page 9 Blinks once The ONT is not connected to fibers or every 2 does not receive optical signals. seconds Blinks once Blinks once The hardware is faulty. every 2 every 2 seconds seconds Issue 03 (2020-02-26) Copyright © Huawei Technologies Co., Ltd.
-
Page 10: Technical Specifications
● Dimensions (H x W x D): 30 mm x 173 mm x 120 mm (without external antenna and pads) ● Weight: About 250g ● Maximum system power consumption: 18 W Issue 03 (2020-02-26) Copyright © Huawei Technologies Co., Ltd. -
Page 11: Faqs
How do I log in to the Huawei ONT web page? ● Wireless login Connect your mobile phone, pad, or PC to the Wi-Fi network of the Huawei ONT. Enter the IP address in the address box of a browser and press Enter. On the displayed login page, enter the username and password. - Page 12 ● Wired login Use a network cable to connect a PC to the Huawei ONT. Set the IP address of the PC in the same subnet as the web address of the For example, if the web address of the Huawei ONT is Huawei ONT.
- Page 13 ● Change the initial password after logging in to the web page for the first time. How do I change the Wi-Fi password? Log in to the Huawei ONT web page using your mobile phone, pad, or PC. For details, see "How do I log in to the Huawei ONT web page?"...
- Page 14 2. Wi-Fi speed is affected by the Wi-Fi signal strength and quality. Ensure that the Huawei ONT is far away from interference sources such as TVs, microwave ovens, refrigerators, cordless phones, and Bluetooth devices, and reduce the number of obstacles between the Huawei ONT and Wi-Fi devices (such as pads, mobile phones, and laptops).
- Page 15 How do I restore the Huawei ONT to factory setting? Press Reset by using a needle-type object for longer than 10s to restore factory defaults and reset the Huawei ONT. If the indicator is off and then is lit, the system restarts successfully.
