stellar.heatnglo.com
Custom Fireplace Program
Co-linear Direct Vent
Powervented Gas Fireplaces
Installation and Operating Manual
Round Models:
3-RD-24-G & 3-RD-36-G
Installer: Leave this manual with the appliance.
Consumer: Retain this manual for future reference.
WARNING:
FIRE OR EXPLOSION HAZARD.
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch;
do not use any phone in your
building.
•
Leave the building immediately.
•
Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
•
If you cannot reach your gas
supplier, call the fire department.
— Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
Stellar by Heat & Glo, a division of Hearth & Home Technologies
IMPORTANT:
DANGER
®
· 22160 Cedar Avenue Suite 200, Lakeville, MN 55044 · (952) 224 - 4072
This appliance is only for
use with Natural Gas
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
Page 1
Advertisement
Table of Contents
Related Manuals for Heat & Glo STELLAR 3-RD-24-G
Summary of Contents for Heat & Glo STELLAR 3-RD-24-G
- Page 1 stellar.heatnglo.com Custom Fireplace Program Co-linear Direct Vent Powervented Gas Fireplaces Installation and Operating Manual Round Models: 3-RD-24-G & 3-RD-36-G Installer: Leave this manual with the appliance. Consumer: Retain this manual for future reference. WARNING: FIRE OR EXPLOSION HAZARD. Failure to follow safety warnings exactly This appliance is only for IMPORTANT: could result in serious injury, death, or...
-
Page 2: Introduction & Homeowner Reference
Read this manual before installing or operating this appliance. Please retain this owner’s manual for future reference. As the owner of a new fireplace, you’ll want to read Congratulations on selecting a and carefully follow all of the instructions contained in this Stellar by Heat &... -
Page 3: Model Number Identification
UL RATING PLATE LOCATION & MODEL NUMBER IDENTIFICATION The rating plate is used for multiple designs and multiple collections, and custom fireplaces. The generic nomenclature listed on the rating plate will not identically match the model of custom fireplace you have. The rating plate must stay with the fireplace and is located below the burner in an area that will only be reachable while servicing. - Page 4 Page 4...
-
Page 5: Table Of Contents
TABLE OF CONTENTS Section Description Page Introduction & Homeowner Reference Venting - Continued UL Rating Place & Fireplace Model Identification K. Vertical Terminations Table Of Contents L. Horizontal Cap Location & Clearances M. Horizontal Termination Safety Information N. Powervent & Air-intake Placement Clearances A. -
Page 6: Safety Information
1 - SAFETY INFORMATION This fireplace complies with ANSI Z21.50-2019 / CSA 2.22-2019 “VENTED GAS FIREPLACE” and CAN/CSA P.4.1-15 Installation must conform with local building codes or in the absence of local building codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54 - Current Edition, or the Natural or Propane Installation Code, CSAB149.1 A. -
Page 7: Commonwealth Of Massachusetts Requirements
2 - COMMONWEALTH OF MASSACHUSETTS REQUIREMENTS NOTE: THE FOLLOWING REQUIREMENTS REFERENCE VARIOUS MASSACHUSETTS AND NATIONAL CODES NOT CONTAINED IN THIS MANUAL. For all sidewall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purpos- es, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied: INSTALLATION OF CARBON MONOXIDE DETECTORS... -
Page 8: Specifications
3 - SPECIFICATIONS A. FIREPLACE DIMENSIONS TOP VIEW 3X .375-16 UNC THREADED ROD 1 1/2 [38] 37" 23 15/16 10" FLUE B-VENT 1 1/2 13 1/2 10" INTAKE [38] COLLAR 31 7/16 31 7/16 [798] [798] BOTTOM VIEW 34 1/32 [864] The dimensions in green are the allowable finishing dimensions. -
Page 9: B Gas & Electric Access Locations
3 - SPECIFICATIONS B. GAS & ELECTRICAL ACCESS LOCATIONS 6 1/2" 5 3/4" Top View 5" 4" BY 3" GAS KNOCK OUT 3X 7/8" ELECTRICAL KNOCK OUT 13 11/32" 3X 1 3/32" 10 11/32" ELECTRICAL KNOCK OUT 3" GAS KNOCK OUT 2 1/16"... - Page 10 3 - SPECIFICATIONS WARNING: NON-COMBUSTIBLE ZONE: USE ONLY NON-COMBUSTIBLE MATERIAL IN THIS AREA FOR ENTIRE WIDTH OF FIREPLACE. DO NOT USE WOOD, SHEETROCK, ETC., IN THIS ZONE. NOTE: OTHER CLEARANCES APPLY. ALL CLEARANCES MUST BE MAINTAINED. REFER TO SPECIFICATIONS 3C FOR MORE INFORMATION. 12”...
-
Page 11: Clearances
3 - SPECIFICATIONS NOTE: The qualified installer should follow the procedure best suited for the installation. C. CLEARANCES TO COMBUSTIBLES From unit left & right sides 1" 25.4mm To flooring under fireplace Unit top to ceiling 48" 121.9cm Unit side to adjacent sidewall 1"... -
Page 12: Prepare The Fireplace
4 - PREPARE THE FIREPLACE CAUTION: FIREPLACE IS NOT LOAD-BEARING. NOTE: OTHER CLEARANCES APPLY. ALL CLEARANCES MUST BE MAINTAINED. Page 12... -
Page 13: Orientation Of Fireplace
4 - PREPARE THE FIREPLACE A. ORIENTATION OF FIREPLACE Outer Circle Threaded Rod TEMPORARY SUPPORT BRACKETS The four (4) temporary support brackets are not shipped in place on the Inner Circle fireplace. You will be required to assemble them at the jobsite to support the hood Threaded Rod prior to installing the required threaded rods that support the hood. -
Page 14: Support Bracket Installation
4 - PREPARE THE FIREPLACE B. SUPPORT BRACKET INSTALLATION The hood must be supported at specific locations using 3/8-16 UNC threaded rods. Temporary support brackets are put in place for shipping and installation support and must stay in place until fireplace hood is fully supported. Top Brackets (4) Bottom Brackets (4) Figure... - Page 15 4 - PREPARE THE FIREPLACE B. SUPPORT BRACKET INSTALLATION Figure 4B.4 Figure 4B.5 Attach top brackets to bottom as shown with screws. Carefully place hood on top of the brackets. Figure 4B.6 Attach screws in this area on all four brackets. Page 15 INS_16400-7807 Rev C CUSTOM 3' ROUND...
-
Page 16: Threaded Rods
4 - PREPARE THE FIREPLACE C. THREADED ROD REQUIREMENTS The fireplace requires 3 threaded rods to be placed at certain locations to support the hood (3/8-16 UNC) You can choose to use all three outer circle threaded rod locations or all three inner circle threaded rod locations shown below. DO NOT USE a mix of outer and inner locations. -
Page 17: Threaded Rod Installation (Example)
4 - PREPARE THE FIREPLACE D. THREADED RODS INSTALLATION (EXAMPLE) There are several different ways to support the fireplace top and one option is to use a Uni-strut installed over the fireplace that is secured to structurally sound framing. For each threaded rod installation you may need: Qty 1 Qty 1... -
Page 18: Framing
5 - FRAMING WALL ENCLOSURE ROUGH OPENING NOTE: Framing dimensions should allow for wall covering thickness and fireplace facing materials. When using a hearth, adjust rough opening size as necessary to maintain at least minimum clearance requirements. Model # THESE DIMENSIONS REPRESENT THE FRAMING DIMENSIONS FOR COMBUSTIBLE MATERIAL. 48-1/8"... -
Page 19: Mantel Requirements
6 - MANTEL REQUIREMENTS NON-COMBUSTIBLE ZONE & FINISHING SCHEMATIC WARNING! Risk of Fire Notes About TV Placement: Comply with all the minimum clearances as specified in A mantel is not required if you are Specifications - Clearances section. placing a TV above the opening. No minimum clearance requirement for placement of TV if using a mantel. -
Page 20: Glass Frame Assembly & Installation
7 - GLASS FRAME ASSEMBLY CAUTION: TO PREVENT GLASS FRAME ASSEMBLY FROM FALLING FROM FIREPLACE AND BECOMING DAMAGED, FOLLOW THE INSTRUCTIONS EXACTLY WHEN REMOVING AND INSTALLING GLASS FRAME ASSEMBLY. STOP: DO NOT OPERATE THIS FIREPLACE WITH THE GLASS REMOVED, CRACKED OR BROKEN. REPLACEMENT OF GLASS ASSEMBLY SHOULD BE DONE BY A LICENSED OR QUALIFIED SERVICE PERSON. - Page 21 7 - GLASS FRAME ASSEMBLY ROUND GLASS INSTALLATION Align top and base using a plumb bob to line the bolts on top and the bolts on the bottom up with each other. Top must be exactly above the base in order for the glass to fit properly.
- Page 22 7 - GLASS FRAME ASSEMBLY ROUND GLASS INSTALLATION Inside Glass & Clip View - Top Clip Figure 7.3 Inside Glass & Clip View - Bottom Clip Figure 7.4 Page 22...
- Page 23 7 - GLASS FRAME ASSEMBLY ROUND GLASS INSTALLATION Install the lower and upper glass clips with a #8 pan head. NOTE: On most models these clips are built into the fireplace. You can skip to the trim ring step. Clip Attach with #8 pan head through this...
- Page 24 7 - GLASS FRAME ASSEMBLY ROUND GLASS INSTALLATION Place trim rings between glass on glass supports. Trim Rings Glass Support Figure 7.7 Outer Glass - Bottom Install the outer glass by placing evenly across half of the support with rubber pads.
- Page 25 7 - GLASS FRAME ASSEMBLY ROUND GLASS INSTALLATION Outer Glass - Top Figure 7.9 Top and Bottom 3” Trim Install trim bands. Start by attaching one band across the center of a magnet. Continue around and you will end up at a center of a magnet.
-
Page 26: Gas Line Specifications & Connection
8 - GAS LINE SPECIFICATIONS This fireplace is manufactured for use with Natural or Propane Gas. CAUTION: Installation of the gas line must only be done by a qualified person in accordance with local building codes, if any. If not, follow ANSI 223.1. NOTE: The appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at pressures in excess of ½... -
Page 27: Venting
9 - VENTING CAUTION: Consult the local and national installation codes to assure adequate combustion and ventilation air is available. NOTE: Flame height and appearance will vary depending upon venting configuration and type of fuel used. Venting requirements apply to both Natural and Propane gas. STOP: MAINTAIN ALL CLEARANCES AS STATED IN THIS INSTALLATION MANUAL. -
Page 28: Rs Series Powervent Specifications
9 - VENTING D. RS SERIES POWERVENT SPECIFICATIONS Available Power Venting A power vent (RS12 & RS14) is approved for use with this appliance. It is crucial that all B-Vent pipe and elbow joints, and the longitudinal seam are sealed using a high temperature RTV Silicone and/or foil tape. MODEL RS12 RS14... -
Page 29: Rsif Series Powervent Specifications
9 - VENTING F. RSIF SERIES POWERVENT SPECIFICATIONS Available In-Line Power Venting An in-line power vent (RSIF180 only for the Round) is approved for use with this appliance. It is crucial that all B-Vent pipe and elbow joints, and the longitudinal seam are sealed using a high temperature RTV Silicone and/or foil tape. -
Page 30: In-Line Powervent Preparations - Rsif 180
D. IN-LINE POWERVENT PREPARATIONS G. IN-LINE POWERVENT PREPARATIONS- RSIF 180 Perform the following steps when installing the RSIF180. Attach the provided 10 inch B-Vent collar to the intake side of the powervent. The intake side is located opposite the fan motor as shown in Figure 9G.1. The 10 inch B-Vent collar is packaged separately from the powervent. -
Page 31: Horizontal Vent System Clearance
9 - VENTING H. HORIZONTAL VENT SYSTEM CLEARANCES ALL APPROVED VENTING BOTTOM SIDES HORIZONTAL 1 inch [25mm] 1 inch [25mm] 1 inch [25mm] I. WALL PASS-THROUGH - Follow all local codes for requirement of firestops. 8 - VENTING J. PITOT TUBE INFORMATION (NA for Round) Page 31 INS_16400-7807 Rev C CUSTOM 3' ROUND... -
Page 32: Vertical Terminations
9 - VENTING K. VERTICAL TERMINATIONS • The fireplace must terminate with the included approved powered termination cap. • NO SUBSTITUTION IS ACCEPTABLE. Carefully follow the instructions included with the approved powered termination cap. • • DO NOT use an additional speed control on this powervent. •... - Page 33 9 - VENTING M. HORIZONTAL TERMINATION VENT CAP LOCATION & CLEARANCES Inside Corner Outside Corner Recessed Location A = Combustible 24” (609.6mm) F = Combustible 6” (152mm) = Non-combustible 6” (152mm) = Non-combustible 12” (304.8mm) Balcony Balcony with perpendicular side wall with no side wall C = Clearance from corner in recessed location...
- Page 34 9 - VENTING N. POWERVENT AND AIR-INTAKE PLACEMENT CLEARANCES RS SERIES POWERVENT IN-LINE POWERVENT (LOUVER 8/10) X = Intake X = Intake PV = Vent PV = Vent 0” P.V. 0” 0” 36” 24” 9” 9” 9” Minimum Clearance Using an In-Line Powevent Minimum Clearance Using a RS Series Powervent Intake Placed Below Vent = 24”...
- Page 35 9 - VENTING O. VERTICAL VENT CAP LOCATION AND CLEARANCES ROOF PITCH H (Min.) Ft. H (Min.) M. FLAT TO 6/12 1.0* 0.30 OVER 6/12 TO 7/12 1.25* 0.38 OVER 7/12 TO 8/12 1.5* 0.46 OVER 8/12 TO 9/12 2.0* 0.61 OVER 9/12 TO 10/12 2.5*...
- Page 36 9 - VENTING P. ROOF TERMINATION CAP INSTALLATION - WITH AND WITHOUT DAMPER Roof Termination Without Optional Mechanical Damper POWERVENT MOUNTING BRACKETS OR DRILL MOUNTING HOLES TO MATCH BASE INSULATION PAD MUST BE CUT IN CENTER TO ACCOMMODATE VENT SIZE STEEL CHIMNEY ADAPTER Figure 9P.1 Roof Termination With...
- Page 37 9 - VENTING Q. WALL TERMINATION - WITH AND WITHOUT DAMPER Wall Termination Without Optional Mechanical Damper FRAMING: 8" = 11-3/4" W X 11-3/4" H 10" = 13-1/4"" W X 13-1/4" H DRILL 1/4” HOLES TO MATCH POWER VENT BASE INSULATION PAD MUST BE CUT IN CENTER TO ACCOMMODATE VENT SIZE...
-
Page 38: Outdoor Air Intake
9 - VENTING R. OUTDOOR AIR INTAKE This fireplace has an air intake at the bottom of the fireplace. The collar is not shipped in place. See assembly instructions below. This fireplace is approved for use with 10 inch rigid metal pipe or UL approved 10 inch Class 0 or Class 1 flex for intake air. Use Table 9R.1 for venting requirements if using UL approved 10 inch flex for intake air. -
Page 39: Optional Universal Exhaust & Intake Louver
9 - VENTING S. OUTDOOR AIR INTAKE COLLAR ASSEMBLY Carefully tip the base over and attach the collar to the bottom of the fireplace. Use two people to lift the base up and into place. Do not sit base down on the collar. Figure 9S T. - Page 40 10 - ELECTRIC A. PDS-1 INSTALLATION - MUST BE INSTALLED NOTE: The four sided fireplace utilizes an external draft switch (PDS-1). This needs to be installed at the time the venting is installed. The installation instructions are included in the box with the PDS-1 kit. Please read fully prior to installation. Additional wiring information can be found on Page 38-39.
- Page 41 10 - ELECTRIC GENERAL The PDS 1 is for indoor installation only. The PDS 1 must be installed in a vertical position with the pressure connection pointing down. Secure the switch by using the mounting holes as shown on the figure. After installation connect the tubing from the probe onto the port marked accessible through the small of the plastic enclosure.
- Page 42 10 - ELECTRIC B. 1 TETHERED CONTROL PANEL INSTALLATION OVERVIEW POWERVENT ENERVEX RS09- RS16 WHIP INCLUDED POWERVENT CAP SERVICE DISCONNECT MAY BE REQUIRED BY CODE IF USING IN-LINE INSULATION PAD PDS-01 GOES BETWEEN FAN CUT HOLE IN PAD EQUAL TO AND FIREPLACE OR GREATER THAN THE FLUE DIAMETER ADAPTER PLATE...
-
Page 43: Electrical
10 - ELECTRICAL B.2 ELECTRICAL WIRING SCHEMATIC- AT INSTALL Figure 10B.1 Powervent Voltage Chart Supply Voltage Chart (N/L1) FUNCTION NOTES: 120 VAC SW2 LIGHTS 120 VOLT LOOP 120VAC SW2 LIGHTS 120 VOLT LOOP 120VAC SW1 MAIN FLAME 120 VOLT LOOP 120 VAC SW1 MAIN FLAME 120 VOLT LOOP 120 VAC SUPPLY... - Page 44 10 - ELECTRICAL B.3 ELECTRICAL WIRING SCHEMATIC- FOR SERVICE AND TROUBLESHOOTING NOTE: The appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, Part 1, CSA C22.1. Figure 10B.2 SYSTEM: TB1P111SYS DENOTES LOW VOLTAGE...
-
Page 45: Junction Box & Capacitor
10 - ELECTRIC B.4 JUNCTION BOX & CAPACITOR C.1 TERMINALS 1 & 2 - LED LIGHTING DO NOT DISCARD TERMINAL 1 & 2: LED LIGHTING JUNCTION BOX - CAPACITOR INSIDE HAS 120VAC POWER TO SUPPLY A SWITCH, RELAY, TIMER, TERMINAL #2 REMOTE, ETC. -
Page 46: Terminals 3 & 4 - Main Flame
10 - ELECTRIC C.2 TERMINALS 3 & 4 - MAIN FLAME TERMINAL 3 & 4 : MAIN FLAME TERMINAL #4 HAS 120VAC POWER TO SUPPLY A SWITCH, RELAY, TIMER, TERMINAL #4 REMOTE, ETC. TERMINAL #3 RETURNS 120VAC POWER TO ACTIVATE TO MAIN FLAMES. TERMINAL #3 IF USING STANDARD ROMEX, CONNECT BLACK TO TERMINAL #4 AND WHITE TO TERMINAL #3. - Page 47 10 - ELECTRIC C.3 - TERMINALS 5 & 6 C. 4 - TERMINALS 7 & 8 FIREPLACE POWER POWERVENT MOTOR TERMINAL 5 & 6: FIREPLACE POWER TERMINAL 7 & 8: POWERVENT CONNECTION POWERVENT POWER MUST COME FROM THE TERMINAL BLOCK AND GROUND - LOCATE THE GREEN WIRE CLUSTER NOT ANY OTHER POWER SOURCE.
-
Page 48: Terminals 9 & 10: Flue Damper Connection
10 - ELECTRIC C.5 - TERMINALS 9 & 10 C. 6 - TERMINALS 11 & 12 FLUE DAMPER CONNECTION FLUE DAMPER PROVE TERMINALS 11 & 12: FLUE DAMPER PROVE TERMINALS 9 & 10: FLUE DAMPER CONNECTION THIS IS LOW VOLTAGE AND EXTERNAL POWER MUST NOT BE APPLIED THIS IS LOW VOLTAGE AND EXTERNAL POWER MUST NOT BE APPLIED S THE NEUTRAL CONNECTION FOR THE DAMPER MOTOR. - Page 49 10 - ELECTRIC C. 7 - TERMINALS 13 & 14 INSTALLATION INSTRUCITONS OF FLUE PRESSURE SWITCH PDS-01 SWITCH CAN BE FOUND ON PAGE 44 & 45 TERMINALS 13 & 14: PRESSURE SWITCH FOUR SIDED UNITS ONLY. FACTORY WIRED FOR ALL OTHERS. CONNECTS TO THE “COM”...
-
Page 50: Finishing
11 - FINISHING REFER TO SECTION 6 - MANTEL REQUIREMENTS 12 - LIGHTING & SHUTDOWN FOR YOUR SAFETY - READ BEFORE LIGHTING STOP: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. UE TO HIGH SURFACE TEMPERATURES, KEEP CHILDREN, CLOTHING AND FURNITURE AWAY. -
Page 51: If The Fireplace Does Not Light
12 - LIGHTING & SHUTDOWN A. LIGHTING THE FIREPLACE - SEQUENCE OF EVENTS To light the fireplace: Activate the switch. The fireplace has a pre and post timer, set at the factory for 30 seconds. The power-vent and flame will not turn on for 30-60 seconds after the switch is activated and the power-vent will run for 30 seconds after the switch is shut off. -
Page 52: Pressure Testing
13 - PRESSURE TESTING NOTE: The appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at pressures in excess of ½ psi. (3.5kPs) NOTE: The appliance must be isolated from the gas supply piping system by closing its individual manual shut-off valve during any pressure testing of the gas line at test pressures equal to or less than ½... -
Page 53: Maintenance
15 - MAINTENANCE A. VALVE AND ELECTRICAL ACCESS The appliance is required to be inspected at least once a year by a professional service person. The compartment below firebox (behind lower access panel) must be cleaned at least once a year, more frequent cleaning may be required due to excessive lint from carpeting, bedding materials, or other fibrous materials. -
Page 54: Replacement Parts
16 - REPLACEMENT PARTS ROUND REPLACEMENT PARTS LIST PART PART NUMBER PART PART NUMBER Enervex External Chimney Fan RS12 Gas Valve SV9501 Pilot 112-5000 Replacement Capacitor - RS12 601.0400.0064 Vacuum Switch 112-5003 Enervex In-line Chimney Fan RSIF160 Transformer, 24 VAC 112-5002 Replacement Capacitor - RSIF160 601.0800.0064... - Page 55 Page 55 INS_16400-7807 Rev C CUSTOM 3' ROUND...
- Page 56 Page 56...
