Icom BC-119N Service Manual page 8

SECTION 4 PARTS LIST
[MAIN UNIT]
REF ORDER
NO. NO.
IC1 1110005350 S.IC
IC2 1140010280 S.IC
IC3 1110004700 S.IC
IC4 1110005330 S.IC
IC5 1110003070 S.IC
Q1 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q3 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q4 1510000510 S.TRANSISTOR 2SA1576A T106R
Q5 1590003070 S.FET
Q6 1510000510 S.TRANSISTOR 2SA1576A T106R
Q7 1510000510 S.TRANSISTOR 2SA1576A T106R
Q8 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q9 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q10 1590000430 S.TRANSISTOR DTC144EUA T106
Q11 1590000430 S.TRANSISTOR DTC144EUA T106
Q12 1590001190 S.TRANSISTOR XP6501-(TX) .AB
D2 1160000070 S.DIODE
D3 1160000070 S.DIODE
D4 1750000550 S.DIODE
D5 1750000550 S.DIODE
D6 1790000680 S.DIODE
D7 1790000680 S.DIODE
D8 1750000550 S.DIODE
X1 6060000790 S.CERAMIC
L1 6200007660 S.COIL
L2 6190001150 COIL
R1 7030000380 S.RESISTOR
R2 7030000380 S.RESISTOR
R3 7030003520 S.RESISTOR
R4 7030003320 S.RESISTOR
R5 7030003320 S.RESISTOR
R6 7030003520 S.RESISTOR
R7 7030003410 S.RESISTOR
R8 7030003410 S.RESISTOR
R9 7030003200 S.RESISTOR
R10 7030003410 S.RESISTOR
R11 7030005501 S.RESISTOR
R12 7030003560 S.RESISTOR
R14 7030005981 S.RESISTOR
R15 7030007230 S.RESISTOR
R16 7030003560 S.RESISTOR
R17 7030003800 S.RESISTOR
R18 7030003440 S.RESISTOR
R19 7030005671 S.RESISTOR
R20 7030005501 S.RESISTOR
R21 7410000950 S.ARRAY
R22 7410000950 S.ARRAY
R23 7030005321 S.RESISTOR
R24 7030009580 S.RESISTOR
R25 7310002630 S.TRIMMER
R26 7030003460 S.RESISTOR
R27 7030005671 S.RESISTOR
R28 7030005981 S.RESISTOR
R29 7030006091 S.RESISTOR
R30 7030003800 S.RESISTOR
R31 7030003800 S.RESISTOR
R32 7030003600 S.RESISTOR
R33 7030003440 S.RESISTOR
R34 7030003600 S.RESISTOR
R35 7030003520 S.RESISTOR
R36 7030003600 S.RESISTOR
R37 7030003650 S.RESISTOR
R38 7030003600 S.RESISTOR
R39 7030003770 S.RESISTOR
R40 7030003650 S.RESISTOR
R41 7030003770 S.RESISTOR
[BC-121N ONLY]: MAIN-A–MAIN-F units are same parts as this parts list.
DESCRIPTION
NJM2870F05-TE1
µPD789112AMC-512-5A4
S-80847ALNP-EEB-T2
NJM12904V-TE1
µPC494GS-E1
UPA1890GR-9JG-E1
DAN202K T146
DAN202K T146
1SS355 TE-17
1SS355 TE-17
SB20-03P-TD
SB20-03P-TD
1SS355 TE-17
CSTCR4M91G
LL1608-FHR10J
HK-08S050-2010
MCR10EZHJ 1 kΩ
MCR10EZHJ 1 kΩ
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 561 V (560 Ω)
ERJ3GEYJ 561 V (560 Ω)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 561 V (560 Ω)
ERA3YKD 124V
ERJ3GEYJ 103 V (10 kΩ)
ERA3YED 333V
ERA3YED 102V
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERA3YKD 393V
ERA3YKD 124V
EXB-V8V 102JV
EXB-V8V 102JV
ERA3YED 103V
ERJ8RSJ R12V
RV-139 (RH03A3A12) 101
ERJ3GEYJ 152 V (1.5 kΩ)
ERA3YKD 393V
ERA3YED 333V
ERA3YED 822V
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 563 V (56 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 564 V (560 kΩ)
ERJ3GEYJ 563 V (56 kΩ)
ERJ3GEYJ 564 V (560 kΩ)
[MAIN UNIT]
REF ORDER
NO. NO.
R42 7030003560 S.RESISTOR
R43 7030003690 S.RESISTOR
R44 7030005501 S.RESISTOR
R45 7030005981 S.RESISTOR
R46 7030003440 S.RESISTOR
R47 7030003520 S.RESISTOR
R48 7030003360 S.RESISTOR
R49 7030000380 S.RESISTOR
R50 7030003640 S.RESISTOR
R51 7030003570 S.RESISTOR
R52 7030003580 S.RESISTOR
R53 7030003760 S.RESISTOR
C1 4030006900 S.CERAMIC
C3 4030006900 S.CERAMIC
C4 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C5 4030006900 S.CERAMIC
C6 4030011600 S.CERAMIC
C7 4030006900 S.CERAMIC
C8 4030006900 S.CERAMIC
C9 4510005430 S.ELECTROLYTIC ECEV0JA220SR
C10 4510007920 ELECTROLYTIC 25 MV 470 CA
C11 4030006900 S.CERAMIC
C12 4030006900 S.CERAMIC
C13 4030011600 S.CERAMIC
C14 4030006900 S.CERAMIC
C15 4030006900 S.CERAMIC
C16 4030006900 S.CERAMIC
C17 4030006900 S.CERAMIC
C18 4030006900 S.CERAMIC
C19 4030006900 S.CERAMIC
C20 4030006900 S.CERAMIC
C21 4030006900 S.CERAMIC
C22 4030006900 S.CERAMIC
C23 4030011600 S.CERAMIC
C25 4030006900 S.CERAMIC
C26 4510007920 ELECTROLYTIC 25 MV 470 CA
C27 4030006900 S.CERAMIC
C28 4030006900 S.CERAMIC
C29 4030006900 S.CERAMIC
C30 4030006900 S.CERAMIC
C31 4030011600 S.CERAMIC
C32 4030006900 S.CERAMIC
C33 4030006860 S.CERAMIC
C34 4030006900 S.CERAMIC
C35 4510005430 S.ELECTROLYTIC ECEV0JA220SR
C36 4510005430 S.ELECTROLYTIC ECEV0JA220SR
C37 4030006860 S.CERAMIC
C38 4030011600 S.CERAMIC
C39 4030006900 S.CERAMIC
C40 4030006900 S.CERAMIC
C41 4030011600 S.CERAMIC
C42 4030006900 S.CERAMIC
C43 4030006900 S.CERAMIC
C44 4030006900 S.CERAMIC
C45 4030006900 S.CERAMIC
J1 6450000410 CONNECTOR
F1 5210000040 FUSE
F2 5220000020 HOLDER
F3 5220000020 HOLDER
DS1 5040002150 LED
W1 8900010880 CABLE
EP1 0910054243 PCB
4 - 1
DESCRIPTION
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 124 V (120 kΩ)
ERA3YKD 124V
ERA3YED 333V
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 221 V (220 Ω)
MCR10EZHJ 1 kΩ
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 123 V (12 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1E 104K-T-N
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1E 104K-T-N
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1E 104K-T-N
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1E 104K-T-N
C1608 JB 1H 103K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1E 104K-T-N
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1E 104K-T-N
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
C1608 JB 1H 103K-T-A
HEC0470-01-630
FGB 2A
S-N5051
S-N5051
VRPG3349S-734
OPC-1103
B 5712C
S.=Surface mount
