Summary of Contents for Icom BC-121N
- Page 1 INSTRUCTION MANUAL MULTI-CHARGER BC-121N...
- Page 2 To reduce the risk of injury, charge only spec- Appropriate desktop charger adapters MUST be purchased ified Icom Ni-Cd, Ni-MH and/or Li-Ion rechargeable batteries. separately to charge your Icom battery packs. See your trans- Other types of batteries may burst, causing damage and per- sonal injury.
- Page 3 An appropriate desktop charger adapter must be purchased DO NOT place liquids on or near the battery charger. separately to charge your Icom battery packs. AVOID charging in extreme cold (under +10°C; +50°F) or If your batteries seem to have no capacity even after being extreme heat (over +40°C;...
- Page 4 Install six appropriate desktop charger adapters into the ï ï For types requiring the AD-75/AD-88 spaces of the BC-121N. Several adapters are available as Install the optional AD-75 or AD-88 to the BC-121N with 4 described in the table at right to accommodate various Icom screws...
- Page 5 BP-211 and BP-215, respectively. IC-F30G/F40G, IC-F3G/F4G, AD-94* BP-209/210*/222 IC-F11/F21/F12/F22, The BC-121N may be able to be used with future transceivers not IC-V8, IC-T3H listed above. See the transceiver instruction manual for the appropri- ate adapter information. IC-F30G/F40G, † IC-F3G/F4G, BP-209/210*/211 †...
- Page 6 Connect the optional OPC-656 DC power cable or the For Ni-Cd/Ni-MH battery packs: The BC-121N rapidly charges a battery pack to a specified BC-124 AC adapter to the BC-121N as illustrated in the level, not a completed level, to prevent over-charging.
- Page 7 WALL ATTACHMENT AND SPECIFICATIONS WALL ATTACHMENT ï ï SPECIFICATIONS ï ï The multi-charger has holes in the rear panel allowing it to be • Input voltage : 12 to 16 V DC or the specified AC hanged from a wall. Use appropriate screws (6 mm; ⁄...
- Page 8 A-6133H-1G Printed in Japan 1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003 Japan 2002 Icom Inc. ©...
