TP-Link NX511v Quick Start Manual page 2

Interface
Description
LED indicator
SIM Card
Power
ON/OFF
LAN1, LAN2,
LAN3/WAN Ports
WPS
Reset
The indicators will turn on when the router has sucessfully connected to a network.
Router LED Status
LED
(Signal
Strength)
(Wi-Fi)
Definition
Router LEDs
SIM card slot
Power
ON/OFF switch
LAN / WAN
WPS
Reset
Status
Solid white
Solid green
Solid orange
Off
Flashing
Description
To display the signal strength. Refer to LEDs
status table.
Use to insert the SIM card.
Power socket via the provided power adapter.
The switch for the power. Press it to power on or
off the router.
For connecting the router to your PC or other
Ethernet network devices. In wireless router
mode, the WAN port is used for connecting to a
Cable/FTTH/VDSL/ADSL device.
Press the button to start a WPS synchronization.
Press and hold this button for at least 5
seconds until all LEDs blink to reset the
router to its factory default settings. The
RESET button is a shared RESET/Wi-Fi
button (short press for 5 seconds or less is
for Wi-Fi function, long press for 5 seconds
or more is for RESET function). A short
press will cause the Wi-Fi in use to turn off.
Indication
The signal strength is above 75%.
The signal strength is between 50% and 75%.
The signal strength is below 50%.
No mobile network signal.
The WPS pairing is ongoing.
If the connection is established successfully, it will return
to solid white. If it is not successfully established, it will
continue to flash for 2 minutes and then return to solid
white. If Wi-Fi is turned off during WPS pairing, the Wi-Fi
light will be off.
2
