YUKA mini Disassembly & Assembly SOP
Version
Author
Date
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
V1.0
Luke
2025.1.22
Item
Cover & Decoration & Lampshade
4G Module
Battery
Security Key
Stop Button
Vision Module
Mid-Frame
USB Module & X3 Board & X3 Fan
Side Lights
Button Board
RTK Antenna
LoRa Antenna
Charging Cable & Plate
Mainboard
Battery Indicator
Front Wheels
Protective Cover
Knob & Lifting Shaft
Charging Socket & Battery Cable
Infrared Module
Hall Sensor Board
Drive Board
Wheel Motors
Cutting Motors
Lifting Module
