- Page 1 NOTICE D’UTILISATION ECS31.2Z ECS51.2Z ECS81.2Z FR – MANUEL D’UTILISATION EN – USE INSTRUCTIONS p. 2 p. 36 DE – GEBRAUCHSANWEISUNG p. 67 NL – HANDLEIDING p. 100 IT – MANUAL D ‘USO ESP – MANUAL INSTRUCCIONES p.164 p. 132...
-
Page 2: General Safety Instructions
Firstly, we would like to thank you for purchasing a LA SOMMELIERE product and hope that this appliance fully lives up to your expectations. This appliance enables you to bring your bottles at room temperature or bring them to service temperature (depending on the bottles) thanks to its wide adjustment range. - Page 3 Have your electrical installation checked by a professional, if you are in any doubt. This unit must be correctly connected to an earthed socket for your protection. Do not cut off or remove the earth wire on the mains cable supplied. For safety reasons, do not use an electrical extension cable.
- Page 4 Do not pull on the mains cable - take hold of the plug to disconnect the appliance. Ensure that the area where your appliance is positioned can support its weight when loaded (a 75 cl bottle weighs approximately 1.3 kg). Your cellar must be placed on a flat surface.
- Page 5 • Before you throw away your old wine cooler: take off the door. Leave the shelves in place so that children may not easily climb inside. • NOTE: children between 3 and 8 can load and unload the appliance. Plastic bags can be dangerous. To avoid danger of suffocation, keep this wrapper away from children General safety WARNING —...
-
Page 6: Electrical Safety
the manufacturer. WARNING — The refrigerant and insulation blowing gas are flammable. When disposing of the appliance, do so only at an authorized waste disposal center. Do not expose to flame. WARNING — The refrigerant of these appliances is R600a, flammable and explosive articles should not be put in or near the cabinet, to avoid the fire or explode caused. -
Page 7: Daily Use
• Do not pull the main cable. • Ensure that the appliance is always electrically earthed. • If the power plug socket is loose, do not insert the power plug. There is a risk of electric shock or fire. • You must not operate the appliance without the interior lighting lamp cover. •... - Page 8 to facilitate minor movements. Do not move the appliance over long distances. • Never use the base, drawers, doors etc. to stand on or as supports. • To avoid items falling and causing injury or damage to the appliance, do not overload the door racks or put food into the appliance.
- Page 9 • It is recommended that the appliance be allowed to settle for at least 24 hours before connecting the electrical power supply, so that the compressor fluid feed is correct. • Proper air circulation is necessary to avoid overheating. To ensure sufficient ventilation, observe the installation recommendations provided.
- Page 10 ECS31.2Z ECS51.2Z...
- Page 11 ECS81.2Z Trouble shooting • Any electrical work should be carried out by a qualified and skilled technician. • The appliance should be repaired by an accredited repair center, using only manufacturer’s original spare parts.
-
Page 12: Safety Instructions
The appliance is designed for home use only. The manufacturer declines any liability whatsoever in the case of other use. R600a Safety instructions • Caution — Do not obstruct the ventilation grills on the appliance. Keep ventilation openings in the appliance enclosure or in the structure for building-in clear of obstruction. -
Page 13: Technical Data
2. TECHNICAL DATA Below is an example of the nameplate: The nameplate attached to the inside or rear of the appliance (depending on the model) includes the entire information specific to your appliance. We recommend that you make a note of its serial number in this booklet prior to installation, so that you can refer to it later (technical work, request for assistance, etc.). -
Page 14: Product Description
3. PRODUCT DESCRIPTION Cabinet Shelf Control board Adjustable feet Sensor Lower hinge Door seal Handle Glass door with anti-UV Upper hinge treatment Note: The appliance you buy might not be exactly the same as shown here. To find out more about your product, consult the online EPREL database. As defined in Commission Delegated Regulation (EU) 2019/2016, all information relating to this refrigeration appliance is available on the EPREL Base (European Product Database for energy labeling). - Page 15 • This wine cellar is designed for free-standing , in no case it must be installed in a built-in or integrable only . For a good operation of the device it is imperative to leave a good air circulation all around the device. We do not accept any liability for failure to comply with the installation instructions.
- Page 16 5. OPERATING INSTRUCTIONS 1. Press and hold the button for 3 seconds to turn the device off or on. 2. Press the button to turn your cave interior light on or off. A “bulb” icon appears on the screen when the lighting function is functional;...
- Page 17 2. Indicates that the compressor is running to cool the cellar. The icon disappears when the compressor stops. 3. Winter function: When the heating element works to warn the temperature, the icon will light up; When the heating element stops working, the icon disappears from the LCD screen. 4.
- Page 18 The “6” icon of the cellar is displayed fixed indicating that the WIFI function is on and the cellar is connected to WIFI. If the “6” icon is flashing, it means the WIFI function is on but the cellar cannot connect to the WIFI network, please reset the wifi of the cellar.
- Page 19 VINOTAG® Menus When the application is open, the following menu is visible: My cellar My wines Alerts Profile • MY CELLAR: Allows you to view your wine cellar (s). • MY WINES: Allows you to consult your wine library. • ALERTS: Allows you to consult your cellar's alerts.
- Page 20 List mode: • Simplified display mode. A list allows you to consult the wines kept in your cellar. The wines are listed in alphabetical order. • List mode indicates for each wine: the name of the wine, its domain, its date, its color, its type and finally the picture of the bottle.
- Page 21 This page allows you to view the alerts related to your cellar; a red dot next to the icon indicates an unread alert. The alerts are classified chronologically. When you have several cellars, it is possible to filter by cellar (filter icon located at the top left of your screen).
- Page 22 Add a « Connected wine cellar» • Define the type of cellar “connected cellar” or “not connected cellar”. ECS models are part of the "connected cellar" category. Click on “connected cellar”. • The application asks you to activate Bluetooth; its activation is necessary to configure the cellar. •...
- Page 23 Managing my cellar In “Settings” mode you can control your cellar • Adjust the temperature of your cellar • Change measurement from Celsius to Fahrenheit • Turn the lighting on/off • Stop or start operation your cellar • Reset the WiFi in your cellar •...
- Page 24 • Repeat the operation on all the cellars you wish to delete. Attention ! if the cellar has at least one bottle, a pop-up will appear asking you to confirm this action. Once the cellar is deleted, it is no longer possible to recover the related information. Attention ! you cannot delete a cellar that does not belong to you.
- Page 25 Country / region Color Quantity of bottles An "advanced" mode allows you to provide additional information such as; Minimum guard (years) Maximum guard (years) Comment Switch to favorites Rate the bottle (0 to 5) Buying price Link to VIVINO® to find the complete sheet (Premium Option) Link to VIVINO®...
- Page 26 complete your wine sheet. A real time saver to fill your cellar and access a lot of information on your favorite wines. In the event that all of the scans offered have been used; it is possible to continue to add bottles by manually completing their wine sheet or to subscribe to the premium option to benefit from a refill of scans.
- Page 27 Create stock alerts To better manage your cellar and your wines, VINOTAG® offers you to set up stock alerts: • Via the view of your cellar on the application, click on the desired bottle to access the associated wine sheet •...
- Page 28 Enhanced safety Since this range of appliances is intended for storing items of value, we have been careful to select quality components and to design suitable manufacturing techniques to ensure optimum safety in operation. Installing the handle Your appliance has a stainless steel handle. To fit it, simply screw it onto the door with the screws supplied as per the diagram below, having first removed the seal.
-
Page 29: Care And Maintenance
Note the difference in depth! Top-to-bottom neck between bottle bodies: Increased loading. Examples of serving temperatures Opinions vary, and the ambient temperature too, but many people agree on the following: Prestigious Bordeaux wines – Reds 16 – 17°C Prestigious Burgundy wines – Reds 15 –... -
Page 30: In The Event Of A Breakdown
• Long vacations: if the appliance will not be used for several months, remove all items and turn off the appliance. Clean and dry the interior thoroughly. To prevent odor and mold growth, leave the door open slightly: blocking it open if necessary. Moving your wine cooler •... -
Page 31: Troubleshooting
10. TROUBLE SHOOTING You can solve many common Wine cooler problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. PROBLEM POSSIBLE CAUSE •... - Page 32 As we continuously improve our products for the benefit of our customers, we reserve the right to modify technical characteristics without notice. Warranties for LA SOMMELIERE brand products are offered exclusively by selected retailers. No part of these instructions may be considered as a supplementary guarantee.
