Summary of Contents for Temtop AIRING-2000
- Page 1 AIRING-2000 Handheld particulate matter monitor...
- Page 2 The built-in high-performance lithium battery allows the instrument to run continuously for at least 4 hours. Meanwhile, the AIRING-2000 has 32GB of built-in storage so that test data can be viewed directly on the display or use a USB stick to export to a PC via the USB port for viewing and analysis.
-
Page 3: Specifications
Range: 0-50°C (32-122°F) Temperature Resolution: 0.1°C Accuracy: ±0.5°C (±0.9°F) Range: 0-90%RH Humidity Resolution: 0.1% Accuracy: ±5%RH Note: The above data are from Temtop Laboratory. Operation Warning! ★ Indoor use: Keep the room/area airtight for 10 minutes to obtain more accurate results. ★... -
Page 4: Setting Menu
Press to start detection, and it will display the real-time data of all parameters. The instrument defaults to continuous sampling. During the sampling process, you can press to pause sampling (Fig.3). 04-11-2024 17:20:40 04-11-2024 17:20:40 76.5 °F 54.4%RH 76.5 °F 54.4%RH PM2.5: PM2.5:... - Page 5 2.1 System Setting In the system setting interface MENU->Setting, you can set time, sample, backlight adjustment, and language. Press to switch the options (Fig.6) and press to enter. 04-11-2024 17:20:40 04-11-2024 17:20:40 MENU->Setting: Time Setting Sample Setting Backlight Adjustment Language Setting Fig.6 2.1.1 Time Setting Press the...
- Page 6 Temperature Unit In the system setting interface MENU->Setting->Sample. Press to enter the Temperature Unit interface. Press to select °C or °F. Then press to switch to Save and press to save (Fig.9). 04-11-2024 17:20:40 04-11-2024 17:20:40 MENU->Setting->Sample: MENU->Setting->Sample->Temperature: Temperature Unit Temperature Unit: °F Storage Interval...
-
Page 7: System Calibration
2.1.3 Backlight Adjustment In the system setting interface MENU->Setting. Press to switch to the Backlight Adjustment, and press to enter. Press to select 1, 2 and 3. Then press to switch to Save and press to save (Fig.12). 04-11-2024 17:20:40 04-11-2024 17:20:40 MENU->Setting: MENU->Setting->Backlight:... -
Page 8: Zero Calibration
2.2.1 Zero Calibration Under the Zero Calibration interface, press to start calibrating. It takes about 90 seconds countdown. After the countdown finishes, the display prompts a reminder to confirm the calibration finishes successfully and will return to the MENU-Calibration interface automatically (Fig. 15). 04-11-2024 17:20:40 04-11-2024 17:20:40 MENU->Calibration->Zero:... -
Page 9: Data Query
2.3.1 Data Query In the query interface, you can press month data. Press to enter the month selection interface, by default the system will automatically recommend the current month. If you need data for other months, you can press to increase or decrease the value. - Page 10 2.3.3 History Deletion In the History Deletion interface, data can be deleted by month or all. Press to switch options and press to enter (Fig. 21). 04-11-2024 17:20:40 04-11-2024 17:20:40 MENU->History: MENU->History->Delete: Data Query By Month History Download All Data History Deletion Fig.21 By Month...
-
Page 11: System Infomation
2.4 System Infomation The System Infomation interface shows the following information (Fig.24) 04-11-2024 17:20:40 04-11-2024 17:20:40 MENU->Information: Model: AIRING-2000 Serial Number:TT1246070001 Firmware Version: V1.00 Brand: Temtop TEL: (+1)408-898-2866 Fig.24 3. Power OFF Press and hold for 2 seconds to turn o the monitor (Fig.25). -
Page 12: Troubleshooting
Example: 1. Installation Snap Switch 2. Removal OPEN LOCK 1. Installation: Hold the "Snap Switch" in your left hand and turn it in the " " direction with your right hand. 2. Removal: Hold the "Snap Switch" in your left hand and turn it in the " "... -
Page 13: Warranty
Warranty Temtop warrants the included detector for 1 year from the date of original purchase. The item can be exchanged or returned within 30 days if the defect is not caused by artificial damage. Item Warranty Period Detector 1 year included Accessories Before return or delivery for repair, please check if the following √... - Page 14 53 Norman Road,London, SE10 9QF Tel: (+1) 408-898-2866 Tel: (+44)208-858-1888 Facebook: www.facebook.com/temtopus Youtube: @elitech_uk Instagram: www.instagram.com/temtopaqm/ Instagram: @elitechuk_ youtube: www.youtube.com/@Temtopus Facebook: @hvaccontrol linkedin: www.linkedin.com/company/temtop-us/ Sales: sales@elitecheu.com X: x.com/temtopus48285 Website: www.temtop.co.uk Sales: sales@temtopus.com Website: www.temtopus.com Elitech Brazil Ltda R.Dona Rosalina,90-Lgara, Canoas-RS 92410-695,Brazil Tel: (+55)51-3939-8634 V1.0...
