Summary of Contents for Temtop M2000 Series
- Page 1 M2000 Series Air Quality Monitor User Manual...
- Page 2 ★ Do not place detector in heavily polluted environments for a long time; or it may cause damages to the sensor. ★ Do not use the detector in a humid environment to maintain detection accuracy. ★ Do not use the detector for a long time in a strong irritating odor environment to ensure measurement accuracy.
- Page 3 fig.1 Display Buzzer Status Measuring Status Menu Button Date & Time Increase/Up Button USB Port Power Level Decrease/Down/Switch(Start/Pause) Button Back Button Power/OK Button Indicator Light Particle Count Histogram...
- Page 4 M2000 Series 228g @M2000/M2000 2nd 221g @M2000C/M2000C 2nd For M2000/M2000 2nd Note: The above data are from Temtop Laboratory.
- Page 5 Indoor use:Keep the room/area airtight for 10 minutes to obtain more accurate results. When charging, the indicator light is red and full of green. If battery level shows, please charge the detector promptly to avoid e ects during use (also chargeable when turned o ). ON/OFF Press and hold for 2 seconds to turn on/o the detector.
- Page 6 c. Display CO curve fig.4 d. Alarm value setting: Set high alarm limit. Operation: Press button to adjust the value and press to switch digits. Then press Save and to save the setting and exit the interface, or press Exit and to exit without saving the setting (fig.5).
- Page 7 2.3 History (For M2000C 2nd/M2000 2nd) (fig.7). fig.7 History Press the Up or Down button to set the current value, press the menu button to switch to the next item. fig.8 History fig.9...
- Page 8 (fig.11). (fig.10); History History BACK fig.10 fig.11 (fig.12) fig.12 *For M2000 2nd (fig.13). History wait! fig.13...
-
Page 9: Operation
2.4 Settings Settings interface displays 6 options below ( fig.14 Operation: Press to select the desired option; press to enter the interface. Settings Calibration fig.14 Date and time (Example Of Button Operation) Operation: Press to adjust time and press to switch to next digit. Then press to switch to Save or Exit. - Page 10 Calibration interface displays 4 options below (fig.17). Calibration PM2.5 TEMP & HUM Zero HCHO Zero fig.17 Press to adjust number and press to switch to next digit. Then press to switch Save or Exit. Press to finish the calibration and exit the interface (fig.18 & fig.19). 1.
- Page 11 2. TEMP & HUM Calibration: You can calibrate the PM2.5 value by adjusting the "K" factor. Calibration Calibration 23.0 25.0 TEMP ℃ TEMP ℃ +1.8 ℃ ℃ 33.0 36.0 +1.5 +4.5 Press the Up or Down button Press the Up or Down button to set the current value, to set the current value, Increase "OFF(TEMP)"...
-
Page 12: Alarm Value
Alarm value: Set alarm limit for PM2.5, CO2 or HCHO concentration (fig.22). Alarm value Alarm value 012.0 012.0 Restore factory settings as default Switch on the menu button Press the Up or Down button Press the ‘Up’ or ‘Down’ and press OK button to button to set the current to set the current value, make a confirmation. - Page 13 FAQ: Q: Why is the PM2.5 reading constantly changing? A: As PM2.5 concentration in the environment is changing all the time not only due to environmental factors like changes in airflow, humidity, wind direction and etc. but also due to common pollutant sources like smoking, cooking; exhaust emissions from vehicles, smoke from burning coal/chimneys/furnaces and etc.
- Page 14 Q: Why is the test result abnormal or below normal? A: ① Please check whether the air inlet or outlet is covered or liquid has entered. ② Gently shake the detector during detection to increase the interaction with surrounding air. ③...
- Page 15 Q: Which the HCHO reading inaccurate or overestimated at some points? A: As Temtop uses a high-precision electrochemical HCHO sensor, its electrochemical reaction characteristics could also respond to other gases besides formaldehyde.This table lists the most common gases that interfere with relative sensitivities of HCHO sensor.
- Page 16 V2.2...
