Summary of Contents for Temtop S1
- Page 1 User Manual...
- Page 2 0 to 500, where higher index values indicate higher levels of air pollution and higher risks to health. There are six pollutants for AQI in US standard: PM2.5/10, O3, SO2, NO2, CO, where Temtop only focus on PM2.5/10 and follows the US EPA Standards to compute AQI.
- Page 3 Important ★ Do not place detector in heavily polluted environments for a long time; or it may cause damages to the sensor. ★ Do not use the detector in a humid environment for a long time to ensure the measurement accuracy. ★...
- Page 4 Overview ④ ① ⑧ ⑤ ② ⑥ ③ ⑦ ① Work mode ② PM2.5 & AQI level ③ Temperature & Humidity level ④ Battery level & Charging status ⑤ Health level display area ⑥ Built-in magnet ⑦ Vents ⑧ Air inlet...
- Page 5 Overview ⑫ ⑨ ⑩ ⑬ ⑪ ⑭ ⑨ Power button ⑩ air outlet ⑪ USB port ⑫ Mode button ⑬ Temperature and humidity detection port ⑭ Bracket (Optional)
-
Page 6: Specifications
Specifications Model Sensor: Laser PM sensor Measuring range: 0-999 µg/m³ Resolution: 0.1 µg/m³ Accuracy: ±5 µg/m³ (0-50 µg/m³) PM2.5 ±10 µg/m³ (50-100 µg/m³) ±10% (100-500 µg/m³) Measuring range: -10-60°C Temperature* Resolution: 0.1°C, Accuracy: ±0.5°C Measuring range: 0-99.9% RH Humidity Resolution: 0.1% RH, Accuracy: ±3% RH Dimension 3.5*2.7*0.7 (inches) Battery Capacity... - Page 7 Weight Operation Environment -10-60°C/0-99.9% Note: The above data are from Temtop Laboratory. *1) When the product is charged, the temperature will have an error of ±0.5°C, and it will recover in about 10 minutes after full change. 2) When the temperature measurement environment suddenly changes, and the temperature di erence...
-
Page 8: Operation
Operation Warning ! Indoor use: Keep the room/area airtight for 10 minutes to obtain more accurate results. ● If battery level shows , please charge the detector promptly to avoid e ects during use ● (also chargeable when turned o ). - Page 9 1. On/O Press 3s to turn ON/OFF the S1 monitor. Long press 3S...
- Page 10 2.Display ① The S1 has four working modes, and you can switch the working mode by pressing the Mode button after power on. Mode Button: 1.Short press to switch between the work mode (4 di erent types) Mode display 2.Long press to switch between the °F...
- Page 11 Power-saving Mode (30min) 1) PM2.5 Sensor works every 30 minutes; 2) The temperature and humidity are still maintained for 1 minute to refresh. ② S1 monitoring function Power display 1) When the battery is displayed as empty, please charge it in time, and...
- Page 12 Air Quality Parameter for Reference Status GOOD FAIR POOR Pollutant PM2.5(µg/m³) ＞55.4 0-12 12.1-55.4 AQI* ＞150 0-50 51-150 *Refers to EPA Standards.
- Page 13 Place The Scene ① Directly place ② Bracket placement ③ Magnetic placement...
- Page 14 FAQ (frequently asked questions) Q: Why is the PM2.5 reading constantly changing? A: As PM2.5 concentration in the environment is changing all the time not only due to environment factors like changes in airfow, humidity, wind direction and etc. but also due to common pollutant sources like smoking, cooking;...
-
Page 15: What's Included
What's Included Detector x 1 ● USB Cable x 1 ● User Manual x 1 ● Bracket or accessories set x1 (Optional) ●... -
Page 16: Warranty
Warranty Temtop warrants the included detector for 1 year from the date of original purchase. The item can be exchanged or returned within 30 days if the defect is not caused by artificial damage. Before return or delivery for repair, please check if the following items are ready: Detector &... - Page 17 Elitech Technology, Inc. Elitech (UK) Limited 2528 Qume Dr, Ste 2 Unit 13, Greenwich Centre Business Park San Jose, CA 95131 USA 53 Norman Road, London, SE10 9QF UK Tel: +1 408-898-2866 Tel: +44 (0)208-858-1888 Sales: sales@temtopus.com Sales: sales@elitech.uk.com Website: www.temtopus.com Website: www.elitecheu.com Elitech Brasil Ltda R.
