Planet WSG-404 Manual

Hide thumbs Also See for WSG-404:
Table of Contents

Advertisement

Quick Links

Download this manual
Requirements
• Cable modem or DSL/ADSL modem.
• Network cables.
Use standard 10/100Base-TX network (UTP) cables with RJ45 connectors.
• Subscriber PC installed with Wireless adapter that complied with 802.11b, or
802.11g.
• Workstations of subscribers running Windows 95/98/ME, NT4.0, 2000/XP, MAC
OS9 or later, Linux, UNIX or other platform compatible with TCP/IP protocols.
• <Optional> Account generator (Model No.: WSG-ACG4).
Mac platform should be OS9 or later in order to have DHCP client
Hint:
support.
Package Contents
• 1x WSG-404 unit
• 1x Power Adaptor
• 1x User's Manual CD
• 1x Quick Installation Guide
• 1x RJ-45 Cable
• 1x RS-232
• 2x Antenna
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WSG-404 and is the answer not in the manual?

Questions and answers

Related Manuals for Planet WSG-404

Summary of Contents for Planet WSG-404

  • Page 1 • <Optional> Account generator (Model No.: WSG-ACG4). Mac platform should be OS9 or later in order to have DHCP client Hint: support. Package Contents • 1x WSG-404 unit • 1x Power Adaptor • 1x User’s Manual CD • 1x Quick Installation Guide • 1x RJ-45 Cable •...

  • Page 2: Top Panel

    WSG-404 Overview Top Panel The top panel of PLANET WSG-404 is shown below. LEDs Indication Color Status Description Green The device is turned off The device is turned on WLAN Green The wireless is not ready The wireless is ready...
  • Page 3 Rear Panel The rear panel of PLANET WSG-404 is shown below. Port Indication Power Reset LAN 1 LAN 2 LAN 3 LAN 4 Console Printed on 12V DC RESET Console Housing Interface Power Button RJ-45 RJ-45 RJ-45 RJ-45 RJ-45 RJ-11 POWER: The power adaptor plugs here.

  • Page 4: Connecting The Antennas

    The followings are instructions for setting up PLANET WSG-404. Refer to the illustration and follow the simple steps below to quickly install your Wireless Subscriber Gateway. Connecting the Antennas PLANET WSG-404 provides two antenna connectors on the rear of the unit for wireless subscribers. Installation Requirement Before installing PLANET WSG-404, make sure your network meets the following requirements.

  • Page 5: Hardware Connection And Installation

    Hardware Connection and Installation Physical Installation Physical connection of WSG-404 1. Ensure the WSG-404 and the Cable/DSL modem are powered OFF before commencing. Leave your Cable/DSL modem connected to its wall socket (phone line or cable input). 2. Use Ethernet cables to connect to the LAN1/LAN2 port on the rear panel.

  • Page 6: Getting Started

    To access the web management interface, connect the PC and WSG-404 in advance via the Private Port of WSG-404. Then, launch the web browser and enter the IP address of the gateway for that port in the address field then pres Enter. Default IP address of the default gateway of the Private Port is https://192.168.2.254...
  • Page 7 The administrator login page will appear. Enter default username “admin” & default password “admin” in the User Name and Password fields. Click Enter to login. After successfully logging into WSG-404, a web management interface with a welcome message will appear.

  • Page 8: Configuration Wizard

    Click System Configuration to the System Configuration screen and run the Configuration Wizard to help you complete the configuration. Configuration Wizard Click Run Wizard to begin the Configuration Wizard.
  • Page 9 After clicking Run Wizard, the Configuration Wizard will appear in a pop-up browser window. Click “Next” to begin.
  • Page 10 Step 1: Change Admin’s Password Enter a new password for the admin account and retype it in the verify password field (Twenty characters maximum and no spaces allowed). Click “Next” to continue.
  • Page 11 Step 2: Choose System’s Time Zone Select a proper time zone via the drop-down menu. Click “Next” to continue.
  • Page 12 Home Page: Enter the URL that users should be initially directed to when successfully authenticated to the network. NTP Server: Enter the URL of external time server for WSG-404 time synchronization or use the default server. DNS Server: Enter a DNS Server provided by your ISP. Contact the ISP if the DNS IP Address is unknown.
  • Page 13 Step 4: Select the Connection Type for WAN Port There are three types of WAN port to select from: Static IP Address, Dynamic IP Address and PPPoE Client. Select a proper Internet connection type. Click “Next” to continue.
  • Page 14 Step 4(Cont): Set Static IP Address Information Enter the IP Address, Subnet Mask and Default Gateway as the examples provided by the ISP. Click “Next” to continue.
  • Page 15 Step 4(Cont): Set PPPoE Client’s Information after selecting PPPoE Client Enter the Username and Password provided by the ISP. Click “Next” to continue.
  • Page 16 five options appeared in this window (Local User is selected for this setup example). Local User is an authentication method that uses the built-in user account database supported by WSG-404. Click “Next” to continue.
  • Page 17 Step 5(Cont.): Add User A new user can be added to the local user data base. To add a user here, enter the Username (e.g. test), Password (e.g. test) and MAC (optional) and assign a policy to this particular user (or use the default). Upon completing adding a user, more users can be added to this authentication method by clicking the ADD bottom.
  • Page 18 Step 6: Set Wireless Access-Point Connection SSID: Enter a SSID (Up to 32 characters) for the system. The default is WSG-404. SSID is a unique identifier used for the wireless users’ devices to associate with WSG-404. Transmission Mode: WSG-404 supports two transmission modes, 802.11b and 802.11(b+g).
  • Page 19 Restarting now. Please wait for a moment... If all the steps are done properly, PLANET WSG-404 can be further connected to the managed network to experience the controlled network access environment. Firstly, connect an end-user device to the network at PLANET WSG-404’s Public/Wireless LAN and set the end-user device to obtain an IP address automatically.

  • Page 20: User Login Page

    Login page appearing means PLANET WSG-404 has been installed and configured successfully. Now, you can browse the network or surf the Internet! After these steps, your WSG-404 is able to establish Internet connection. More machine configurations and information can be found in the user’s manual CD, please be sure to check the user’s manual for more understandings.
