Wireless Bridge
USER MANUAL
Model: CPE454GSW
Tips:
Thank you for ordering and using CPE454GSW wireless bridge, please
read the manual carefully before use. If there are any problems during the
use, please contact us in time.
Customer Service Email: support@ueevii.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CPE454GSW and is the answer not in the manual?

Questions and answers

Related Manuals for UeeVii CPE454GSW

Summary of Contents for UeeVii CPE454GSW

  • Page 1 Wireless Bridge USER MANUAL Model: CPE454GSW Tips: Thank you for ordering and using CPE454GSW wireless bridge, please read the manual carefully before use. If there are any problems during the use, please contact us in time. Customer Service Email: support@ueevii.com...

  • Page 2: Table Of Contents

    Contents 01-05 1. Product Overview 1.1 Introduction 1.2 Highlights 1.3 Specifications 1.4 Package List 1.5 Interface Details 1.6 LED Indicator Details 06-09 2. Quick Start 2.1 PoE Power Supply 2.2 Point to Point Paring Step 2.3 Point to Multi-point Paring Step 2.4 Installation 09-10 3.

  • Page 3: Product Overview

    1. Product Overview 1.1 Introduction UeeVii CPE454GSW is a long-distance 5.8G wireless transmission device. It uses wireless communication technology to transmit network data using air as a medium to perform long-distance point-to-point or point-to-multi point interconnection. The working data link layer realizes the interconnection of local area networks.

  • Page 4: Specifications

    1.3 Specifications Brand UeeVii Model CPE454GSW Flash 8MByte DRAM DDR3 128MByte 1000/100/10Mbps LAN *1 Interface 1000/100/10Mbps LAN *1 (All support PoE power supply) 11ac: 1.3 Gbps Max 11n: 600Mbps, 433Mbps, 144.4Mbps, 130M, 115.6M, 86.7M, 57.8M, 43.3M, 28.9M, 14.4M, Data rate 72.2M, 65M, 57.8M, 43.3M, 28.9M, 21.7M...

  • Page 5: Package List

    1.4 Package List 2 x CPE454GSW Gigabit Wireless Bridge 2 x Gigabit 24V PoE Adapter 2 x Cat 5e Network Cables 2 x Metal Hoop 1 x User Manual 1.5 Interface Details 1000Mbps LAN 2 Reset Button Digital display 1000Mbps LAN 1...

  • Page 6: Led Indicator Details

    ( Not Support IEEE802.3af/at), 1000Mbps RJ45 port. Support data transmission and IEEE 802.3af/at LAN2 48V POE power supply, 1000Mbps RJ45 port. 12V/1A 5521 DC 1.6 LED Indicator Details WLAN SIG1-SIG4--Signal Light LAN2 LAN1 Power Indicator Transmitter A Mode Receiver B Mode support@ueevii.com...
  • Page 7 The data connection is successful, the LED light is LAN1/LAN2 on,otherwise, it is not bright. Power indicator, the LED is on after the power is connected The digital tube displays paired numbers and Digital Tube letters, 0~9, A~F. support@ueevii.com...

  • Page 8: Quick Start

    2. Quick Start 2.1 PoE Power Supply The CPE454GSW wireless bridge adopts a PoE power supply, which is easy to install and manage while saving costs. 1. According to the requirements, prepare a long enough network cable (Recommended within 20 meters, must Cat 5e or up) to connect the wireless bridge and the PoE power supply.

  • Page 9: Point To Point Paring Step

    4. Wait for 2-5 minutes to complete the pairing. When the number of the digital tube is solid and the signal light on the side turns on, it means the pairing is successful. 5. Finally connect other devices(Router, PC, Switch) and install them to the target location. support@ueevii.com...

  • Page 10: Point To Multi-Point Paring Step

    1. Place the CPE in the selected position with the front of the bridge facing the same direction and secure the CPE using ties,Note: Bracket not included (suggest using UeeVii Universal Bracket, ASIN: B09Y56M6Z9). 2. Please prepare a long network cable to connect the PoE port of the PoE adapter and the LAN port of the CPE.Recommended to use CAT 5e (or...

  • Page 11: Application

    60-degree signal range of the main bridge. The antenna polarization direction is horizontal 60°/vertical 60°. 3. Application 3.1 Point-to-point extended network WiFi range Computer Phone Computer Master Bridge Slave Bridge ALDS Router Router support@ueevii.com...

  • Page 12: Point-To-Point Extended Of Surveillance Cameras Range

    PoE Switch 3.3 Point to multi-point extended surveillance cameras rang Slave Bridge Master Bridge Monitor Camera 1 60° DVR/NVR Camera 2 PoE Switch Camera 3 3.4 Point-to-point extended surveillance multi-cameras range Monitor DVR/NVR PoE Switch Slave Bridge Master Bridge support@ueevii.com...

  • Page 13: Wifi Function

    192.168.255.208 5GCPE_5G132 qlinkcpe123456132 192.168.255.109 192.168.255.209 5GCPE_5G136 qlinkcpe123456136 192.168.255.110 192.168.255.210 5GCPE_5G140 qlinkcpe123456140 192.168.255.111 192.168.255.211 5GCPE_5G149 qlinkcpe123456149 192.168.255.112 192.168.255.212 5GCPE_5G153 qlinkcpe123456153 192.168.255.113 192.168.255.213 5GCPE_5G157 qlinkcpe123456157 192.168.255.114 192.168.255.214 5GCPE_5G161 qlinkcpe123456161 192.168.255.115 192.168.255.215 5GCPE_5G165 qlinkcpe123456165 (PS:In this chart,SSIDs and Passwords are the default.) support@ueevii.com...

  • Page 14: Computer Access

    Ethernet cable. POE Adapter 5.2 How to Change Your IP Address on Windows 1. Modify your computer's IP address,make your computer's IP and the bridge's IP address be on the same network segment(LAN)so that you can access them. support@ueevii.com...
  • Page 15 3. On the login screen, the default user name and login password of the wireless bridge is "admin", just entry password login. Note: "admin" is not the password of the WiFi SSID, it is just the password for WEB access. 4. Log in successful, go to setting. support@ueevii.com...

  • Page 16: How To Change Your Ip Address On Mac

    5.3 How to Change Your IP Address on Mac 1. Click the Apple icon in the upper-left corner of the screen, and select “System Preferences”. 2. Click “Network”. support@ueevii.com...
  • Page 17 3. Click your current bridge’s WiFi on the left and then click “Advanced” in the lower-right corner of the window. 4. Click the “TCP/IP tab”. support@ueevii.com...
  • Page 18 5. Click the drop-down box next to Configure IPv6 (or lPv4) and select “Manually”. 6. Enter the IP address you want to use 192.168.255.6; Router 192.168.255.1, and click “OK”. support@ueevii.com...

  • Page 19: Advanced Settings

    Note： The new pairing method is in the “6.4 Modify WiFi SSID and Password” section.Both the master bridge and the slave bridge must turn off the digital_on/off switch before modifying the parameters. support@ueevii.com...
  • Page 20 A-Master Bridge “Digital_on/off” switch is off B-Slave Bridge “Digital_on/off” switch is off support@ueevii.com...

  • Page 21: Modify Ip Address

    LAN. For example, your network segment is 10.10.10.xxx (1) After the master bridge turns off the digital on/off switch, you can set the new IP address of the master bridge to 10.10.10.56 support@ueevii.com...
  • Page 22 IP address of the slave bridge to 10.10.10.66 Note: After you modify it successfully, the IPv4 address of the computer also needs to be modified to 10.10.10.6, and then re-enter 10.10.10.56 to access the master bridge and 10.10.10.66 to access the slave bridge. support@ueevii.com...

  • Page 23: Modify System Info

    Here you can set the name of the device, the new login name and password of the device, and the system time zone. 6.4 Modify WiFi SSID & Password Note: Only the master bridge enables WiFi, and the slave bridge does not enable WiFi by default. support@ueevii.com...
  • Page 24 (1) Connect the master bridge to the computer, and make sure to turn off the “Digital _on/off” switch, then modify the new WiFi SSID and Password in the “General” settings, apply and remember. support@ueevii.com...

  • Page 25: Slave Bridge Side Broadcasts Wifi

    WiFi.It is recommended to reset the new router or AP, set it to automatically obtain the network, and set a new new router or AP, set it to automatically obtain the network, and set a new support@ueevii.com...
  • Page 26 SSID and password. Method 2: We can turn on the guest WiFi of the slave bridge and set a password. Please refer to the following steps: (1) On the slave bridge's interface,path: Advanced Settings>Wireless 5Ghz>Bridge>Wireless Operation Mode, choose "AP-Client+AP" mode. support@ueevii.com...
  • Page 27 AP?" button to turn on the guest WiFi,set a new Guest SSID, Authentication Method and WPA Pre-Shared Key, apply them. Open your phone's WiFi list to see the latest Guest WiFi settings, enter the password to connect and test. support@ueevii.com...

  • Page 28: Wireless Mode

    6.6 Wireless Mode 6.7 Privacy--Hidden WiFi SSID Find "Hide SSID" in the "General" column and click the button to start hiding the SSID. support@ueevii.com...

  • Page 29: Trouble Shooting

    2. Input wrong password Wrong 2. Re-input the password 3. Too much cookie Password 3. Clear cookie, run arp-d to 4. WiFi password is clear MAC table confused with the WEB 4. WEB access user name access password and password is "admin" support@ueevii.com...
  • Page 30 2. Running time over 7days, 1. Static electricity Device always reboot it 2. Running time too long dead 3. After lightning, device POE 3. Lightning stroke port broken or unstable better to deploy lightning conductor support@ueevii.com...

  • Page 31: After-Sales Service

    If there are any problems during the use, please contact us in time; B. The installation of this device requires some network knowledge. If you can't install it, please let us know or contact a professional. Tech Service Email: support@ueevii.com Website: https://www.ueevii.com FaceBook: https://www.facebook.com/Ueevii FB Group: https://www.facebook.com/groups/8869731233069487 YouTube channel: http://www.youtube.com/channel/UCvcFqnEd44EJWDrBlb7wxWQ...
