- Page 1 Make life full of hope USER GUIDE LiFePO4 Battery System for Households LiFePO4 Battery System for Households Low voltage energy storage lithium battery pack 358-010343-00A...
-
Page 2: Table Of Contents
Contents 1 ABOUT THIS MANUAL ..................1.1 Purpose ....................1.2 Scope ....................1.3 Safety Instructions .................. 1.4 Can be Connected in Parallel ..............2 INTRODUCTION ....................2.1 Features....................2.2 Product Overview ................... 2.3 Specifications ..................2.4 Recommended Settings ................3. INSTALLATION ....................3.1 Unpacking and Inspection .............. -
Page 3: About This Manual
LiFePO4 Battery System for Households LiFePO4 Battery System for Households 1 ABOUT THIS MANUAL 2. INTRODUCTION The battery system main using solar power system for family house. It also have a with to controller the 1.1 Purpose battery easily and protect our Household application timely. This manual describes the introduction, installation, operation and emergency situations of the battery bank. -
Page 4: Specifications
LiFePO4 Battery System for Households LiFePO4 Battery System for Households 2.3 Specifications Model FLS48100 Number of Battery Modules Capacity 5.3kWh 10.6kWh 15.9kWh 21.2kWh 26.6kWh 31.9kWh 37.2kWh 42.5kWh LIN K0 LIN K1 Make life full of hope POS+ NEG- Battery Type... -
Page 5: Installation Procedure
LiFePO4 Battery System for Households LiFePO4 Battery System for Households 3. Installation Procedure Step 4: Drill holes according to the position marked on the installation hole position cardboard (note: the hole diameter is 10mm, and the drilling depth is 60mm) 3.1 Setup Script Step 1: Open the packaging wooden box and remove the accessories (accessory box, base, casters 4PCS);... -
Page 6: Tools
LiFePO4 Battery System for Households LiFePO4 Battery System for Households The battery packaging layer is fixed between the layers using hexagonal screws (at the handle) Make life full of hope Wall ≥300mm ≥300mm 90° 90° Ground Ground 3.2 Tools 3.4 Installation Environment Electric drill 3.3 Floor Installation with Base Installation Location Requirements... -
Page 7: Product Size Information
Make life full of hope Castor x4 Base Lock wall components 180mm Grounding wire x1 Plastic expansion nail x4 CAN/485 com line 1417mm FLS48100-M 180mm Series connection soft Lock wall components Series communication line x1 copper busbar 157.5mm 119mm 631mm 4. -
Page 8: Operation
LiFePO4 Battery System for Households LiFePO4 Battery System for Households 5. OPERATION Main Circuit Once the batteries are connected well, close the breaker to the ON block, press On/Off button to enable the output of the battery pack. Make life full of hope 5.1 Switch On / Off... -
Page 9: On / Off Or Soc Led (Mode Or Soc)
LiFePO4 Battery System for Households LiFePO4 Battery System for Households 5.3 ON / OFF or SOC Led (Mode or SOC) 6.1 BMS Information Page ON /OFF BATTERY MODE REMARK Thebasicinformationwillbedisplayedinturnafterpoweron. GREEN LED RED LED LED1 LED2 LED3 LED4 POWER OFF POWER ON STANDBY SOC <10%(DEFAULT ): LED1 FLASH... -
Page 10: Fault Code Table
LiFePO4 Battery System for Households LiFePO4 Battery System for Households 6.2 Fault Code Table 6.3 DIP switch SW1-SW4 Description DIP switch SW1-SW4 Description ① DIP switch SW5 Description② Sw1 SW2 SW3 SW4 Remarks means ID=0,communication address is0x00/0x10③ Remarks means ID=1,communication address is0x01④ means connect 120Ω... -
Page 11: Emergency Situations
LiFePO4 Battery System for Households LiFePO4 Battery System for Households 7. EMERGENCY SITUATIONS Felicity cannot guarantee battery absolute safety. 7.1 Fire In case of fires, make sure that the following equipment is available near the system. • SCBA (self-contained breathing apparatus) and protective gear in compliance with the Directive on Personal Protective Equipment 89/686/EEC.
