Acer LCD Monitor Quick Start Guide (QSG)
Important safety instructions
Please read the following instructions carefully.
1.
To clean the LCD monitor screen:
• Turn off the LCD monitor and unplug the power cord.
• Spray a non-solvent cleaning solution onto a rag and clean the screen gently.
2.
Do not place the LCD monitor near a window. Exposing the monitor to rain, moisture or sunlight can severely damage it.
3.
Do not apply pressure to the LCD screen. Excessive pressure may cause permanent damage to the display.
4.
Do not remove the cover or attempt to service this unit yourself. An authorized technician should perform servicing of any
nature.
5.
Store the LCD monitor in a room with a temperature of -20° to 60°C (-4° to140°F). Storing the LCD monitor outside this
range may result in permanent damage.
6.
Immediately unplug your monitor and call an authorized technician if any of the following circumstances occur:
• Monitor-to-PC signal cable is frayed or damaged.
• Liquid spills onto the LCD monitor or the monitor is exposed to rain.
• The LCD monitor or case is damaged.
Connecting your monitor to a computer
1.
Turn off your computer and unplug your computer's power cord.
2.
Connect the signal cable to the DP (optional) and/or HDMI (optional) input socket of the monitor, and the DP (optional)
and/or HDMI (optional) output socket of the graphics card on the computer.
3.
Insert the monitor power cable into the power port at the back of the monitor.
4.
Plug the power cords of your computer and your monitor into a nearby electrical outlet.
Note: Audio output is only for audio output model. Please check user manual for more instruction.
Adaptive SYNC:
It can allow a Adaptive SYNC supported graphics source to dynamically adjust display refresh rate based on typical content
frame rates for power efficient, virtually stutter free and low-latency display update.
External controls
1
2
3 4
5
1
Power button
Turns the monitor on/off. Blue indicates power on. Amber indicates standby/power saving mode.
a.
/
/
2
b.
a.
/
/
3
b.
a.
/
4
b.
c.
a.
/
5
d.
Press to view Main page.Press again to enter next function in the Function Menu.
Press this button to select the desired item when in OSD menu.
Press to view Main page. Press again to enter Input select function.
Press this button to select the desired item when in OSD menu.
Press to view Main page. Press again to enter Brightness function.
When the OSD menu is active, this button will act as the exit key (exit OSD menu).
When OSD Lock push 3 seconds Lock function is disabled.
Press to view Main page. Press again to enter Modes function.
Press to enter a selection in the OSD.
