Bobtot ET29 Manual

Safety Instructions

1. Avoid dropping.
2. Do not disassemble.
3. Avoid extreme temperatures.
4. Use original or certified cables.
5. Do not use any corrosive cleaner/oil to clean.
6. Do not use the device outdoors during thunderstorms.
7. Do not expose batteries to high heat as direct sun light, fire and Etc.

What's in the box

Buttons Overview

Button Function

Button	Function	Operation
	Power on/off	Long press
	BT/AUX/USB/Memory card switch mode	Short press
	Increase the volume	Short press
	Next track	Long press
	Decrease the volume	Short press
	Previous track	Long press
	Play/Pause	Short press
	Disconnect BT	Long press
	Indoor /Outdoor mode	Short press
	KTV mode( Medium ECHO ) Karaoke mode ( Much ECHO ) Vocal mode ( No ECHO )	Short press
	Light on/off	Double click

How to use the speaker

Wireless Pairing

1. Short press until you hear prompt sound, which means that speaker enters BT pairing mode.
2. Find "Bobtot ET29 " speaker on the BT list of your phone or tablet, and click to connect.
3. It's successfully connected to your smart device if you hear prompt sound.

AUX/USB/Memory card mode

Plug 3.5mm audio cable & USB flash drive & memory card to the speaker and your audio source device. It will automatically play and make sure other source are disconnected.

Charging (USB Type-C)

1. When the battery is low, you will hear the prompt sound " low battery ", then please charge it.
2. Plug the USB cable to adapter (or computer's USB port) and Type-C insert to the speaker to charge the speaker, the red indicator light will be on when charging, the indicator light will be off when fully charged.

How to use the Microphone

NOTE:
When you use the Microphone, short press " " button on speaker to choose the ECHO effect
if you need much ECHO, pls choose Karaoke mode.
if you need medium ECHO, pls choose KTV mode.
if you don't need the ECHO, pls choose Vocal mode.

Specifications

BT version	5.3
Range	33ft/10m
Audio output	60W
Play time (varies by volume level and content)	Up to 20 hours
Charging time	4 - 6 hours
Battery	7.4 V/ 4400 mAh
Microphone Battery	3.7 V/ 1200 mAh
Waterproof rating	IPX7
Input	DC 5V
Driver (full range)	2 x 3"
Impedance	4Ω
Frequency response	60 Hz-18 KHz
Size	250x104x104mm/9.8x4.09 x4.09 in
Weight	1630g/3.59 lb

Reset Your Device

If the speaker does not work properly, you may reset it by inserting needle to Reset hole for approximately 1 second until the speaker powers off, and then powers on again.
