We advise you to read this manual carefully, which contains all the instructions for maintaining the
appliance's aesthetic and functional qualities. For further information on the product: www.smeg.com
PRECAUTIONS
General safety instructions
Risk of personal injury
• WARNING: During use the
appliance and its accessible
parts become very hot. Keep
children well away from the
appliance.
• Protect your hands by wearing
oven gloves when moving food
inside the oven.
• Never try to put out a fire or
flames with water: Turn off the
appliance and smother the
34 - PRECAUTIONS
34
34
44
38
39
39
39
39
39
40
40
40
40
40
40
41
41
42
42
43
43
43
43
44
flames with a fire blanket or
other appropriate cover.
• This appliance may only be
used by children aged 8 years
and over, and by people of
reduced physical, sensory or
mental capacity, or lacking in
experience in the use of
electrical appliances, provided
that they are supervised or
have been given instructions on
the safe use of the appliance
and of the hazards associated
with it.
44
45
46
48
48
50
50
50
50
51
51
53
53
54
54
55
55
58
59
60
61
62
91477B325/A
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Smeg CX113GMBL
Summary of Contents for Smeg CX113GMBL
-
Page 1: Table Of Contents
Using the accessories Instructions for the installer We advise you to read this manual carefully, which contains all the instructions for maintaining the appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com PRECAUTIONS General safety instructions flames with a fire blanket or other appropriate cover. - Page 2 • Children must not play with the fire. DO NOT attempt to appliance. extinguish a fire with water. Turn • Keep children under the age of off the appliance and smother eight at a safe distance unless the flames, for example with a they are constantly supervised.
- Page 3 • DO NOT USE OR STORE appliance yourself or without FLAMMABLE MATERIALS IN the assistance of a qualified THE STORAGE technician. COMPARTMENT (IF • If the power cable becomes AVAILABLE) OR NEAR THE damaged, contact technical APPLIANCE. support immediately to arrange •...
- Page 4 slots. • If necessary, you can use the • Do not sit on the appliance. tray rack (supplied or sold • Racks and trays should be separately, depending on the inserted as far as they will go model) by placing it on the into the side guides.
-
Page 5: Installation
such as the hob pan support of the appliance are grids, flame-spreader crowns compatible. and burner caps in the • This appliance is not connected dishwasher. to a system for extracting • Never use the oven door to combustion products. It should lever the appliance into place be installed and connected in when fitting. -
Page 6: Appliance Purpose
check for any leaks with a cannot be used: soapy solution, never with a • in employee kitchens, shops, flame. offices and other working • Have the electrical connection environments. performed by authorised • in farms/farmhouses. technicians. • by guests in hotels, motels and •... -
Page 7: Information For European Control Bodies
• Deliver the packing materials to the Technical data on the appliance's power appropriate recycling centre. consumption in off/stand-by mode can be found at www.smeg.com under the page Plastic packaging corresponding to the product in question. Danger of suffocation Light sources •... -
Page 8: Description
DESCRIPTION General description 1 Cooking hob 2 Control panel 3 Auxiliary oven seal 4 Auxiliary oven light 5 Auxiliary oven door 6 Left multifunction oven door 7 Left multifunction oven light 8 Fan 9 Left multifunction oven seal 10 Right multifunction oven light 11 Storage compartment 12 Right multifunction oven door 13 Right multifunction oven seal... -
Page 9: Cooking Hob
Cooking hob AUX = Auxiliary Burner R = Rapid Burner SR = Semi-rapid Burner UR2 = Ultra Rapid Burner Control panel 4 5 6 1 Hob burner knobs 4 Left multifunction oven function/ temperature knob For lighting and adjusting the hob burners. Press It turns on the light inside the oven cavity or turns and turn the knobs anti-clockwise to on the round heating elements to a temperature... -
Page 10: Other Parts
using the temperature knob. Accessories Next to some of the knobs are indicator • Not all accessories are available on some lights, which come on to indicate that models. the oven is heating up. They turn off as • The accessories intended to come into soon as the set temperature is reached. -
Page 11: Using The Accessories
Using the accessories Keep the knob pressed in longer. Racks and trays In case of an accidental switching off, a safety device will be tripped, cutting off Racks and trays have to be inserted into the side the gas supply, even if the gas cock is guides until they come to a complete stop. -
Page 12: Using The Oven
necessary when using the appliance. STATIC Traditional cooking, ideal for preparing Using the oven a single dish. For example cooking roast meats, fatty meats, bread, pies. See General safety instructions. CIRCULAIRE + BOTTOM Allows you to quickly finish cooking Opening and closing the door of the food that is already cooked on the multifunction oven surface but not internally. -
Page 13: Digital Programmer
4. The symbol on the display indicates that When using the ECO function, avoid opening the door during cooking. the appliance is ready to start cooking. To change the time, hold down the Cooking (and preheating) times are increase key and decrease key longer with the ECO function and may depend on the amount of food in the... - Page 14 Programmed cooking It is not possible to set a programmed cooking time of more than 24 hours. Programmed cooking is the function which allows a cooking operation to be started at a set time and then ended After setting, hold the clock key after a specific length of time set by the down for 2 seconds to display the user.
-
Page 15: Cooking Advice
Selecting the buzzer the heat better. • The temperature and the cooking time The buzzer can have 3 tones. depend on the quality and consistency of 1. Hold down the increase and decrease the dough. keys at the same time. •... - Page 16 Weight Temp. Time Food Function Shelf (Kg) (°C) (minutes) Veal roast CIRCULAIRE 180 - 190 90 - 100 Pork loin CIRCULAIRE 180 - 190 70 - 80 Sausages FAN WITH GRILL Roast beef CIRCULAIRE 40 - 45 Roast rabbit CIRCULAIRE 180 - 190 70 - 80 Turkey breast...
-
Page 17: Cooking Information Table (Auxiliary Oven)
Cooking information table (auxiliary oven) Weight Temp. Time Food Function Shelf (Kg) (°C) (minutes) Sausages GRILL 13 - 15 surface 2 surface Pork chops GRILL Spare ribs GRILL Bacon GRILL Pork fillet GRILL Beef fillet GRILL The times indicated in the table do not include preheating times and are provided only as a guide. CLEANING AND MAINTENANCE Cleaning the appliance lukewarm water and non-abrasive detergent. -
Page 18: Knobs
residues with a wooden toothpick or a needle. 2. Grasp the door on both sides with both hands, lift it so that it forms an angle of around 30° and remove it. 3. To reassemble the door, put the hinges in the relevant slots in the oven, making sure Knobs that grooved sections A are resting... - Page 19 indicated by the arrows in order to release the strips at the right and left in order to the 4 pins from their housings on the door. achieve a perfect fit. Auxiliary oven door 1. Remove the internal glass panel by pulling the rear part gently upwards, following the 2.
-
Page 20: Cleaning The Oven Cavity
pins into their slots in the oven door by slide it out of the seats B at the back. applying slight pressure. • When cleaning is complete, repeat the above procedures to put the rack/tray support frames back in. Cleaning the roof of the oven (only for some models/cavities) Cleaning the oven cavity In order to keep your oven in the best possible... -
Page 21: Vapor Clean (On Some Models Only)
Vapor Clean (on some models only) 3. Use a non-scratch sponge with brass filaments on hard to remove deposits. 4. In case of grease residues use specific oven See General safety instructions. cleaning products. 5. Remove the residual water inside the oven. The Vapor Clean function is an assisted 6. -
Page 22: Installation
5. Replace the light bulb with one of the same Take care not to scratch the enamel of type (40 W). the oven cavity wall. 6. Refit the cover. Ensure the moulded part of the glass (A) is facing the door. 4. - Page 23 connector 1 of the appliance, placing the seal 2 (serigraphed on the hose itself). between them. Connection using a rubber hose Connection with a steel hose with bayonet complying with current standards is only fitting permitted if the hose can be inspected along its entire length.
- Page 24 Connection to LPG issue a certificate of conformity. Use a pressure regulator and make the connection on the gas cylinder following the guidelines set out in the standards in force. The supply pressure must comply with the values indicated in the “Burner and nozzle characteristics table”.
-
Page 25: Gas Types And Countries
Replacing nozzles Light the burner and turn it to the minimum position. Extract the gas cock knob and turn the adjustment screw next to the gas cock spindle (depending on the model) until the correct minimum flame is achieved. Refit the knob and verify that the burner flame is stable. -
Page 26: Burner And Nozzle Specifications Tables
Gas types 5 LPG G30/31 28-30/37 mbar G30/31 • • • • • • 30/30 mbar G30/31 • • • 6 LPG G30/31 37 mbar G30/31 • 7 Town Gas G110 8 mbar • • G110 It is possible to identify the available gas types based on the country the appliance is to be installed in. -
Page 27: Positioning
7 Town gas G110 – 8 mbar Rated heating capacity (kW) 1.75 Nozzle diameter (1/100 mm) Pre-chamber (printed on nozzle) (/8) (/2) (/3) 0190 Reduced flow rate (W) 1200 The nozzles where not provided are available at Authorised Service Centres. Positioning Appliance overall dimensions See General safety instructions. -
Page 28: Electrical Connection
Appliance dimensions 3. Align the slots of the upstand (B) with the screws (A). The upstand provided is an integral part of the product. It must be fastened to the appliance prior to installation. Mounting the plinth 636,5 636,5 1103 1103 Position of gas connection Position of electrical connection... -
Page 29: Instructions For The Installer
on all connections. DO NOT use naked The appliance can work in the following modes: flames to search for leaks. 220-240 V 1N~ • Turn on all the burners separately and at 3 x 6 mm ² then all together to make sure that the gas valve, burner and ignition are working three-core cable properly.
