DD80TN / DR80TN
Gas Furnace
CATEGORY I
These furnaces comply with requirements embod-
ied in the American National Standard / National
Standard of Canada ANSI Z21.47·CSA-2.3 Gas Fired
Central Furnaces.
ATTENTION INSTALLING PERSONNEL
As a professional installer you have an obligation to know
the product better than the customer. This includes all safety
precautions and related items.
Prior to actual installation, thoroughly familiarize yourself
with this Instruction Manual. Pay special attention to all safe-
ty warnings. Often during installation or repair it is possible
to place yourself in a position which is more hazardous than
when the unit is in operation.
Remember, it is your responsibility to install the product
safely and to know it well enough to be able to instruct a
customer in its safe use.
Safety is a matter of common sense...a matter of thinking
before acting. Most dealers have a list of specific good safe-
ty practices...follow them.
The precautions listed in this Installation Manual are intend-
ed as supplemental to existing practices. However, if there is
a direct conflict between existing practices and the content of
this manual, the precautions listed herein take precedence.
This furnace may be paired with a cooling unit that uses
R-32 refrigerant. If the refrigeration unit paired with this
furnace does not use R-32, the R-32 function in the furnace
control board needs to be turned off. Please see the
electrical and the R-32 sections for more details.
Refrigerant systems other than 410A or R32 may require
an additional mitigation control board. Refer to the
installation manual of the indoor evaporator coil to
determine installation requirements for that supplier's
refrigerant detection system.
Our continuing commitment to quality products may mean a change in specifications without notice.
© 2024
IOD-2036B
12/2024
Installer:
Affix all manuals
adjacent to the unit.
WARNING
19001 Kermier Rd., Waller, TX 77484
ONLY PERSONNEL THAT HAVE BEEN TRAINED TO INSTALL,
ADJUST, SERVICE, MAINTENANCE OR REPAIR
(HEREINAFTER, "SERVICE") THE EQUIPMENT SPECIFIED IN
THIS MANUAL SHOULD SERVICE THE EQUIPMENT.
THIS EQUIPMENT IS NOT INTENDED FOR USE BY
PERSONS (INCLUDING CHILDREN) WITH REDUCED
PHYSICAL, SENSORY OR MENTAL CAPABILITIES, OR LACK
OF EXPERIENCE AND KNOWLEDGE, UNLESS THEY HAVE
BEEN GIVEN SUPERVISION OR INSTRUCTION CONCERNING
USE OF THE APPLIANCE BY A PERSON RESPONSIBLE FOR
THEIR SAFETY.
CHILDREN SHOULD BE SUPERVISED TO ENSURE THAT
THEY DO NOT PLAY WITH THE EQUIPMENT.
THE MANUFACTURER WILL NOT BE RESPONSIBLE FOR
ANY INJURY OR PROPERTY DAMAGE ARISING FROM
IMPROPER SUPERVISION, SERVICE OR SERVICE
PROCEDURES. IF YOU SERVICE THIS UNIT, YOU ASSUME
RESPONSIBILITY FOR ANY INJURY OR PROPERTY
DAMAGE WHICH MAY RESULT. IN ADDITION, IN
JURISDICTIONS THAT REQUIRE ONE OR MORE LICENSES
TO SERVICE THE EQUIPMENT SPECIFIED IN THIS
MANUAL, ONLY LICENSED PERSONNEL SHOULD SERVICE
THE EQUIPMENT. IMPROPER SUPERVISION, INSTALLATION,
ADJUSTMENT, SERVICING, MAINTENANCE OR REPAIR OF
THE EQUIPMENT SPECIFIED IN THIS MANUAL, OR
ATTEMPTING TO INSTALL, ADJUST, SERVICE OR REPAIR
THE EQUIPMENT SPECIFIED IN THIS MANUAL WITHOUT
PROPER SUPERVISION OR TRAINING MAY RESULT IN
PRODUCT DAMAGE, PROPERTY DAMAGE, PERSONAL
INJURY OR DEATH.
DO NOT BYPASS SAFETY DEVICES.
AS A SAFETY PRECAUTION.
*NOTE: Please contact your distributor or our website for the
applicable Specification Sheet referred to in this manual.
80% HEX
wwww.daikincomfort.com
INSTALLATION INSTRUCTIONS
WARNING
WARNING
RECOGNIZE THIS SYMBOL
DO NOT LIFT
PRODUCT USING
HEAT EXCHANGER
