Daikin DR80TC Quick Start Manual

■
Standard Features
• Compatible with Daikin One+ smart thermostat
and other Daikin communicating equipment
• Heavy-duty stainless-steel dual-diameter,
tubular heat exchanger
• Two-stage gas valve provides quiet,
economical heating
• Durable Silicon Nitride igniter
• Quiet two-speed draft inducer
• Self-diagnostic control board with constant memory
fault code history output to a dual 7-segment display
• Color-coded low-voltage terminals with provisions
for electronic air cleaner and humidifier
• Efficient and quiet variable-speed
airflow system gently ramps up or down
according to heating or cooling demand
• Multiple continuous fan speed options
offer quiet air circulation
• Auto-Comfort and enhanced dehumidification
modes available
• California Low NO x emissions-compliant
models available
• Can no longer be installed in California's
South Coast Air Quality Management District
(SCAQMD) on or after October 1, 2019
• AHRI Certified; ETL Listed
SS-DR80TC_ DD80TC
DR80TC / DD80TC
■
■
Cabinet Features
• Multi-position installation:
DR80TC: Upflow, horizontal left or right.
DD80TC: Downflow, horizontal left or right.
Convenient left or right connection for gas
and electrical service
• Cabinet air leakage (Q
• Heavy-gauge steel cabinet with
durable baked-enamel finish
• Fully insulated heat exchanger
and blower section
* Complete warranty details available from your local dealer or at
www.daikincomfort.com. To receive the Lifetime Heat Exchanger Limited
Warranty (good for as long as you own your home), the 12-Year Unit Replacement
Limited Warranty and the 12-Year Parts Limited Warranty, online registration must be
completed within 60 days of installation. Additional requirements for annual maintenance
are required for the Unit Replacement Limited Warranty. Online registration and some
of the additional requirements are not required in Florida, California, or Québec.
The duration of warranty coverage in Texas and Florida differs in some cases. Other
limitations and exclusions apply; refer to complete warranty details for a full list of
limitations and exclusions.
www.daikincomfort.com
Two-Stage, Variable Speed
ECM Gas Furnace
80% AFUE
Heating Input: 60,000 -100,000 BTU/h
Contents
Nomenclature.............................................2
Product Specifications ................................3
Dimensions .................................................5
Airflow Data ................................................7
Wiring Diagram ....................................... 10
Accessories ...............................................11
) ≤ 2%
Leak
12/24
