Daikin DR96TC Manual

■
Standard Features
• Compatible with Daikin One+ smart thermostat
and other Daikin communicating equipment
• Heavy-duty stainless-steel tubular heat exchanger
• Stainless-steel secondary heat exchanger
• Two-stage gas valve provides quiet, economical heating
• Durable Silicon Nitride igniter
• Quiet two-speed induced draft blower
• Self-diagnostic control board with constant memory
fault code history output to a dual 7-segment display
• Color-coded low-voltage terminals with provi-
sions for electronic air cleaner and humidifier
• Efficient and quiet variable-speed airflow system gently
ramps up or down according to heating or cooling demand
• Multiple continuous fan speed options offer
quiet air circulation
• Auto-Comfort and enhanced dehumidification
modes available
• Can no longer be installed in California's
South Coast Air Quality Management District
(SCAQMD) on or after October 1, 2019
• AHRI Certified; ETL Listed
SS-DR96TC_DD96TC-R32
DR96TC / DD96TC
Heating Input: 40,000 -120,000 BTU/h
■
Cabinet Features
• Designed for multi-position installation:
DR96TC: Upflow, horizontal left or right
• Certified for direct vent (2-pipe) or non-direct vent (1-pipe)
• Easy-to-install top venting with optional side venting
• Convenient left or right connection
for gas and electrical service
• Cabinet air leakage (Q
• Heavy-gauge steel cabinet with durable finish
• Fully insulated heat exchanger and blower section
• Airtight solid bottom or side return with easy-cut tabs
for effortless removal in bottom air-inlet applications
* C o m p l e te wa r ra nt y d e ta i l s ava i l a b l e f ro m yo u r l o ca l d e a l e r o r at
www.daikincomfort.com. To receive the Lifetime Heat Exchanger Limited
Warranty (good for as long as you own your home), the 12-Year Unit Replacement Limited
Warranty and the 12-Year Parts Limited Warranty, online registration must be completed within
60 days of installation. Additional requirements for annual maintenance are required for the Unit
Replacement Limited Warranty. Online registration and some of the additional requirements are
not required in Florida, California, or Québec. The duration of warranty coverage in Texas and
Florida differs in some cases. Other limitations and exclusions apply; refer to complete warranty
details for a full list of limitations and exclusions.
www.daikincomfort.com
Two-Stage, Variable-Speed
Communicating
ECM Gas Furnace
Up to 96% AFUE
■
Contents
Nomenclature ........................................ 2
Product Specifications ........................... 3
Dimensions ............................................ 5
Airflow Data ........................................... 7
Wiring Diagram ...................................... 9
Accessories .......................................... 10
) ≤ 2%
Leak
12/24
