ASSEMBLY INSTRUCTION
PACIFICA SOFA
SKU : 350480
x1
x2
10min
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the PACIFICA 350480 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Living Spaces PACIFICA 350480

  • Page 1 ASSEMBLY INSTRUCTION PACIFICA SOFA SKU : 350480 10min...
  • Page 2 Part’s List Image Description Quantity(pcs/set) COMPONENTS SKU Part List Number SOFA 350480-A LEGS 350480-B 350480 BACK 350480-C CUSHION SEAT CUSHION 350480-D Hardware List Image COMPONENTS SKU Description Quantity(pcs/set) Part List Number Bolt 350480-1(4) (M6x30mm ) 350480 Allen key 350480-2(2) (Lg4 ) Hardware Bag: 350480 THE HARDWARE IS LOCATED THE PACKING ITEMS NOTE : MUST TIGHTEN SCREWS PERIODIACLLY.WITH USE SCREW MAY BECOME LOOSE CHECK TIGHINESS...
  • Page 3 Detail view Step1: Install the two extra legs (B) to the sofa (A). Assemble the two legs (B) securely with the Bolt accessories (1). (1)=4pcs...
  • Page 4 Step2: Place three sofa cushions (C) and one sofa cushion (D) on the sofa. That's it ! You've finished assembling your item. Thank you!
