Part’s List Image Description Quantity(pcs/set) COMPONENTS SKU Part List Number 350489-A LEGS 350489 350491-B 350491 TABLE TOP Hardware List Image COMPONENTS SKU Description Quantity(pcs/set) Part List Number Bolt 350489-1(4) (M6x20mm ) 350489-2(4) (M6 ) Washer 350489-4(4) 350489 (M6x13x1mm ) Allen key 350489-4(1) (Lg4 ) 350489-5(1)
Page 3
Detail view Step1: Please assemble the two half-round legs (A) together. Tighten two legs (A) with accessories Bolt (1) - Washer (3) - Eru (2). (1)=4pcs (2)=4pcs (3)=4pcs...
Page 4
Step2: Assemble the two half-round table tops (B) together. Tighten table top (B) with Bolts (2) - Nuts (3). (2)=4pcs (3)=4pcs Step3: Install the table legs to the table top. Tighten with Bolts (1) - Washers (4). (1)=8pcs (4)=8pcs That's it ! You've finished assembling your item.
