SMITH MACHINE
ALL9
INSTALLATION MANUAL
IMPORTANT: Read all instructions carefully before using this product. Retain this owner's manual
for future reference. The specifications of this product may vary from his photo, subject to change
without notice.
INSTALLATION MANUAL
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for snode ALL9
Summary of Contents for snode ALL9
- Page 1 SMITH MACHINE ALL9 INSTALLATION MANUAL IMPORTANT: Read all instructions carefully before using this product. Retain this owner’s manual for future reference. The specifications of this product may vary from his photo, subject to change without notice. INSTALLATION MANUAL...
- Page 2 ASSEMBLY CAUTION Please carefully read the following information before installation Assembling requires at least two people Do not tighten all screws before assembly is complete Ensure that all accessories are complete. If not, please contact us via email support@snodesport.com If you are missing any parts, or otherwise have any warranty issues, please contact us first.
- Page 3 TABLE OF CONTENT PARTS LIST ASSEMBLY INSTRUCTION 6-17...
- Page 4 Part List Left Rear Post Tube Right Rear Post Tube Rear Connecting Tube Left Base Frame 1 PC 1 PC 2 PCS 1 PC Left Top Frame Right Top Frame4 PCS Base Connecting Plate Top Connecting Plate 1 PC 4 PCS 4 PCS Middle Post Tube Plates Holder Tube...
- Page 5 Part List Left Dip Bar Pulley Connecting Plate Smith Safety Rod Safety Rod Locking Nut 1 PC 4 PCS 22 PCS 22 PCS Smith Bar Guide Rod Smith Bar Set Linear Bearing Lock Catch 2 PCS 1 PC 2 PCS 2 PCS Shock Pad Protect Sleeve...
- Page 6 Part List M10*25 Hexagon Bolt M8*15 Hexagon Bolt M10*25 Hex Bolt M6*15 Cross Screw 3 PCS 8 PCS 6 PCS 16 PCS M10*65 Hexagon Bolt M10*45 Hexagon Bolt M10*90 Hexagon Bolt M10 Lock nut 4 PCS 18 PCS 2 PCS 98 PCS M10*100 Hexagon Bolt Washer Φ10...
- Page 7 Part List Hex Nut M16 Squat Attachment Hexagon Bolt M10*80 Weight Stack Guide Rod 2 PCS 1 PC 2 PCS 4 PCS Damping Pad Big Foam Foam Tube Cap Top Weight Stack 4 PCS 2 PCS 2 PCS 2 PCS Weight Stack Weight Stack Pulley Set Adjustment Rod...
- Page 8 Part List Washer Φ6 Spring Bolt Long Ball Pin Pulley Φ70 16 PCS 1 PC 1 PC 2 PCS Rear Protect Cover...
- Page 9 ASSEMBLY INSTRUCTION STEP: 1 Left Rear Post Tube Right Rear Post Tube Rear Connecting Tube M10*20 Hexagon Bolt 1 PC 1 PC 2 PCS 20 PCS Washer Φ10 20 PCS...
- Page 10 ASSEMBLY INSTRUCTION STEP: 2 Weight Stack Guide Rod M10*25 Hex Bolt Washer Φ10 Left Base Frame 4 PCS 4 PCS 14 PCS 1 PC Right Base Frame M10*20 Hexagon Bolt Landmine Bracket Landmine Attachment 1 PC 8 PCS 1 PC 1 PC M10*25 Hexagon Bolt M10*100 Hexagon Bolt...
- Page 11 ASSEMBLY INSTRUCTION STEP: 3 Shock Pad Weight Stack Top Weight Stack Adjustment Rod 4 PCS 22 PCS 2 PCS 2 PCS Shock Pad Weight Stack Top Weight Stack Adjustment Rod 2 PCS 2 PCS 2 PCS 2 PCS Weight Stack Connecting Weight Stack Guide Rod Right Top Frame Left Top Frame...
- Page 12 ASSEMBLY INSTRUCTION STEP: 4 Base Connecting Plate Sleeve Φ16*50 M10*75 Hexagon Bolt M10 Lock nut Tighten all the screws 4 PCS 30 PCS 30 PCS before step 5 8 PCS Washer Φ10 Middle Post Tube 60 PCS 2 PCS...
- Page 13 ASSEMBLY INSTRUCTION STEP: 5 Smith Safety Rod Safety Rod Locking Nut Plates Holder Tube Protect Sleeve 22 PCS 22 PCS 4 PCS 4 PCS...
- Page 14 ASSEMBLY INSTRUCTION STEP: 6 Hex Nut M16 Bottom U Shape Plate Damping Pad Left Safety Hook 2 PCS 2 PCS 4 PCS 2 PCS Linear Bearing Smith Bar Guide Rod M10*85 Hexagon Bolt Top U shape Plate 2 PCS 2 PCS 8 PCS 2 PCS M10 Lock nut...
- Page 15 ASSEMBLY INSTRUCTION STEP: 7 Smith Bar Set M8*15 Hexagon Bolt Washer Φ8 1 PC 8 PCS 8 PCS...
- Page 16 ASSEMBLY INSTRUCTION STEP: 8 Pull-up Frame Sleeve Φ16*50 M10*75 Hexagon Bolt Hexagon Bolt M10*80 1 PC 2 PCS 2 PCS 2 PCS M10 Lock nut Washer Φ10 Double Pulley Right Pulley Sliding Sleeve 8 PCS 18 PCS 2 PCS 1 PC Right Pulley Sliding Sleeve M10*90 Hexagon Bolt Front Post Tube...
- Page 17 ASSEMBLY INSTRUCTION STEP: 9 Hanging Block Cable A 300mm Pulley Φ95 M10*45 Hexagon Bolt 2 PCS 2 PCS 4 PCS 4 PCS M10*25 Hex Bolt Washer Φ10 M10 Lock nut 2 PCS 12 PCS 6 PCS...
- Page 18 ASSEMBLY INSTRUCTION STEP: 10 Cable C 4200mm Cable B 7410mm Pulley Connecting Plate Pulley Φ95 2 PCS 2 PCS 4 PCS 22 PCS Pulley Φ70 M10*45 Hexagon Bolt M10*75 Hexagon Bolt M10*65 Hexagon Bolt 2 PCS 12 PCS 22 PCS 2 PCS Washer Φ10 M10 Lock nut...
- Page 19 ASSEMBLY INSTRUCTION STEP: 11 Weight Stack Cover Cover Layering Plate Top Cover Fixing Plate Bottom Cover Fixing Plate 2 PCS 4 PCS 2 PCS 2 PCS M6*15 Cross Screw Washer Φ6 M10*20 Hexagon Bolt Washer Φ10 16 PCS 16 PCS 4 PCS 12 PCS Rear Protect Cover...
- Page 20 ASSEMBLY INSTRUCTION STEP: 12 Cable Handle Lock Catch Left Long Safety Catch Right Long Safety Catch 2 PCS 2 PCS 1 PC 1 PC Left Dip Bar Right Dip Bar Right Short Safety Catch Hanging Block 1 PC 1 PC 1 PC Big Foam Foam Tube Cap...
- Page 21 Before exercise, it is better to do stretching exercises. Warm muscles stretch more easily, so the first 5 ~ 10 min- utes to warm up. Then in accordance with the following methods to stop and do stretching exercises - do five times, each leg 10 seconds every time or more.
- Page 22 PARTS REQUEST SNODE GROUP, Inc. EMAIL THIS FORM WITH YOUR RECEIPT OF PURCHASE TO support@snodesport.com NAME: ADDRESS: CITY: STATE: ZIP: TELEPHONE: (Day) (Night) MODEL#: PURCHASE DATE: PLACE OF PURCHASE: PART # DESCRIPTION “YOUR ORDER WILL BE PROCESSED WITHIN 3 BUSINESS DAYS”...
