- Page 1 Quick Start Guide Sniffer High Split...
- Page 2 Firmware, DSP, and Cal Information Immediately after the Power button is pressed, the following two screens will momentary be displayed 1stScreen: Top Left: Device Serial Number Top Right: DSP Release Number Main screen: Firmware Release Number In this example: Device Serial number: 01070002 DSP Release number: 03 Firmware Release Number: 011 2nd Screen:...
- Page 3 Extend Antennas for Correct Frequency Band Band 1: 138MHz •Very Important to fully extend Metal antennas to detect lower level High split signals •Rotate antennas vertically to help find the peak leak level Band 2: 612MHz •Pull out side antennas which are tuned for 612 MHz •Try slowly rotating to vertical to find the peak leak level...
- Page 4 Display Distance Setting •1, 10, 30, 75, or 150 feet. This represents the approx. distance from the Sniffer to the source of the leak. It compensates for the QAM Marker ID over-the-air loss caused by the distance. Measurement levels shown •F1, F2, or F3 is used to indicate the represent the equivalent levels at ten feet.
-
Page 5: Keypad Controls
•Pressing this button will switch the S-HS to measure the Press the Dist. button and then immediately cycle through the ComSonics M3 pressure tester. distance values by using the trigger. •This scales the values of the leak to represent a BAND measurement taken a ten feet. - Page 6 S-HS Trigger Trigger •The trigger has multi-purpose functionality. •It is in the form of a rocker arm that can be pressed either at the top or bottom. •The trigger is used to lower or raise the warble alert volume up and down if pressed without selecting any other buttons first.
