Hard disk drive

Support up to three SATA ports.
•
3.5",25.4mm.
•
Capacity and models are listed on AVLC.
•

Optical disk drive

Support one SATA 5.25" standard ODD.
•
Support DVD-ROM, DVD-SuperMulti, BD-combo, BD-rewrite.
•
Maximum ODD depth to 185mm with bezel.
•
Models are listed on AVLC.
•

Graphics card

No mechanical retriction to support dual slot, full length graphics cards in the single PCIe X16 slot.
•
Please make sure there is no component conflict with PCIe card. Especially VGA card, we may have
•
double width card support.
Audio
Realtek ALC662VD.
•
Rear IO: 3 jack.
•
Front IO: 1*Microphone-in, 1*head phone jack.
•

Serial ATA controller

SATA * 6 (different color to identify SATA 6Gb/s and SATA 3Gb/s).
•
1 * SATA 6 Gb/s and 5 * SATA 3Gb/s .
•
HDD : AHCI/Native IDE is required.
•
ODD: Support BD/SuperMulti/DVD ROM.
•
LAN
Giga Lan, Intel 82579V co-lay with Realtek LAN 8111E.
•
SUPER IO
Support PECI 3.0 and detect VRD/CPU/System temperature.
•
ITE 8772E or other solution proposed by MB vender.
•
Extension slot
1 * PCIE x16 (PCIE V3.0)
•
3 * PCIE x1 (PCIE V2.0)
•
USB2.0
Rear IO : * 4 ports.
•
Internal Header: *4 ports (2 * USB2.0 H5X2 Header).
•
All ports should meet USB IF spec and support 1A current over drive.
•
