Goodman TSTATG2100 Owner's Manual

Goodman TSTATG2100 Owner's Manual

Heat pump non-programmable, use with most heat pumps systems: 1/2-heat, 1-cool, control up to 2-heat & 1-cool, battery or system powered, auxiliary heat indicator, fahrenheit or celsius
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner 's Manual
Owner 's Manual
Model
TSTATG2100
Use with most
Use with most
Heat Pump systems:
Heat Pump systems:
1-Heat, 1-Cool
1-Heat, 1-Cool
2-Heat, 1-Cool
2-Heat, 1-Cool
Air Conditionin g & Heatin g
Heat Pump
Heat Pump
Non-Programmable
Non-Programmable
Di
ital Th ermostat
Di
ital Th ermostat
g
g
Control up to 2-Heat & 1-Cool
Battery or System Powered
Auxiliary Heat Indicator
Fahrenheit or Celsius

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TSTATG2100 and is the answer not in the manual?

Questions and answers

Related Manuals for Goodman TSTATG2100

Summary of Contents for Goodman TSTATG2100

  • Page 1 Owner ’s Manual Owner ’s Manual Heat Pump Model Heat Pump TSTATG2100 Non-Programmable Non-Programmable Use with most Use with most ital Th ermostat ital Th ermostat Heat Pump systems: Heat Pump systems: 1-Heat, 1-Cool 1-Heat, 1-Cool 2-Heat, 1-Cool 2-Heat, 1-Cool Control up to 2-Heat &...

  • Page 2: Table Of Contents

    OWNER'S MANUAL TSTATG2100 Contents Page # Safety Warnings Front Panel Display Normal Operation Aux Heat Fahrenheit or Celsius Preparation Remove Old Thermostat Battery Replacement Wire Connections Test Operation Troubleshooting Warranty Page 2...

  • Page 3: Safety Warnings

    OWNER'S MANUAL TSTATG2100 Safety Warnings P/N TSTATG2100 CAUTION Follow Installation Instructions carefully. DISCONNECT POWER TO THE HEATER - AIR CONDITIONER BEFORE REMOVING THE OLD THERMOSTAT AND INSTALLING WARNING THE NEW THERMOSTAT. CAUTION The two Alkaline “AA” batteries must be replaced at least once every 12 months to ensure proper operation.

  • Page 4: Front Panel

    OWNER'S MANUAL TSTATG2100 Front Panel DISPLAY MODE SWITCH Cool, Off or Heat BATTERY DOOR COMFORT HEAT AUX. HEAT AUX HEAT EMERG’CY NORMAL SWITCH LOCKOUT Emergency Normal AUTO Lockout COOLER & WARMER FAN SWITCH On or Auto BUTTONS Page 4...

  • Page 5: Display

    OWNER'S MANUAL TSTATG2100 Display SET TEMP HEAT COOL BATTERY Heat and Cool indicators. In normal operation, Heat or Cool appears, depending on the Mode Switch position. When heat or cool is energized, the Heat or Cool indicator will flash. Current room or set temperature.

  • Page 6: Normal Operation

    OWNER'S MANUAL TSTATG2100 Normal Operation MODE SWITCH Cool, Off or Heat COMFORT HEAT AUX. HEAT EMERG’CY NORMAL LOCKOUT AUTO FAN SWITCH COOLER & WARMER On or Auto BUTTONS Operation Select Cool or Heat with the Mode Switch. Normally leave the fan switched to Auto.

  • Page 7: Aux Heat

    OWNER'S MANUAL TSTATG2100 Aux Heat COMFORT HEAT AUX. HEAT EMERG’CY NORMAL LOCKOUT AUX HEAT AUTO SWITCH Emergency - Disables all compressor functions* and energizes only Aux Heat to satisfy the heat demand. Normal - Aux Heat is allowed to run, if necessary, along with the heat pump to satisfy the heat demand.

  • Page 8: Fahrenheit Or Celsius

    OWNER'S MANUAL TSTATG2100 Fahrenheit or Celsius MODE SWITCH Cool, Off or Heat COMFORT HEAT AUX. HEAT EMERG’CY NORMAL LOCKOUT AUTO COOLER & WARMER BUTTONS Operation Select Off with the Mode Switch. Press and hold the COOLER and WARMER buttons at the same time until the temperature is displayed in degrees Celsius.

  • Page 9: Preparation

    OWNER'S MANUAL TSTATG2100 Preparation Proper installation of the thermostat will be accomplished by following these step by step instructions. If you are unsure about any of these steps, call a qualified technician for assistance. These tools will be required: Flat Blade...

  • Page 10: Remove Old Thermostat

    OWNER'S MANUAL TSTATG2100 Remove & Replace Old Thermostat Remove the cover of the old thermostat. If it does not come off easily check for screws. Loosen the screws holding the thermostat base or subbase to the wall, and lift away.

  • Page 11: Battery Replacement

    OWNER'S MANUAL TSTATG2100 Battery Replacement The batteries are easily accessible from the battery slot located on the front of the thermostat (fig. 1). To open the battery slot, press down on the battery cover (fig. 1) and pull out (fig. 2).

  • Page 12: Wire Connections

    OWNER'S MANUAL TSTATG2100 Wire Connections If the terminal designations on your old thermostat do not match those on the new thermostat, refer to the chart below or the wiring diagrams that follow. Install on the Wire from the new thermostat...

  • Page 13: Sample Wiring Diagrams

    OWNER'S MANUAL TSTATG2100 Sample Wiring Diagrams 4 Wire, 1 Stage Cooling, 1 Stage Heat-Heat Pump with O reversing valve. Residential Heat Pumps, split systems & package units, with no auxiliary heat. Common wire optional 4 Conductor 18 to 22 gauge unshielded cable from the thermostat to the equipment.
  • Page 14 OWNER'S MANUAL TSTATG2100 Sample Wiring Diagrams 5 Wire, 1 Stage Cooling, 2 Stage Heat-Heat Pump with O reversing valve. Residential Heat Pumps, split systems & package units, with auxiliary heat. Common wire optional 5 Conductor 18 to 22 gauge unshielded cable from the thermostat to the equipment.
  • Page 15 OWNER'S MANUAL TSTATG2100 Sample Wiring Diagrams 4 Wire, 1 Stage Cooling, 1 Stage Heat-Heat Pump with B reversing valve. Residential Heat Pumps, split systems & package units, with no auxiliary heat. Common wire optional 4 Conductor 18 to 22 gauge unshielded cable from the thermostat to the equipment.
  • Page 16 OWNER'S MANUAL TSTATG2100 Sample Wiring Diagrams 5 Wire, 1 Stage Cooling, 2 Stage Heat-Heat Pump with B reversing valve. Residential Heat Pumps, split systems & package units, with auxiliary heat. Common wire optional 5 Conductor 18 to 22 gauge unshielded cable from the thermostat to the equipment.

  • Page 17: Test Operation

    OWNER'S MANUAL TSTATG2100 Test Operation Turn on the power to the Heat Pump. On the thermostat, slide the Mode Switch to HEAT. Press the COOLER or WARMER button until the set temperature is 10 degrees above room temperature. The HVAC unit should energize in the heating mode.
  • Page 18 OWNER'S MANUAL TSTATG2100 Test Operation On the thermostat, slide the Mode Switch to COOL. Press the COOLER or WARMER button until the set temperature is 10 degrees below room temperature. The HVAC unit should energize in the cooling mode (Page 6).

  • Page 19: Troubleshooting

    OWNER'S MANUAL TSTATG2100 Trouble Shooting SYMPTOM: The slide switches on the thermostat are very difficult to move. CAUSE: The backplate of the thermostat is screwed too tightly into a wall that is not perfectly flat. REMEDY: Loosen the screws holding the thermostat into the wall.
  • Page 20 FOR HOME OR OFFICE USE 4Z95 Air Conditionin g & Heatin g Goodman Manufacturing Company, L.P ., reserves the right to discontinue, or change at any time, specifications or designs without notice or without incurring obligations. Copyright © 2009 • Goodman Manufacturing Company, L.P .
  • Page 21 No warranty applies to, and no warranty is offered by Goodman on, Goodman is not responsible for: any thermostat ordered over the Internet.
