Summary of Contents for Hypontech HES-3000 Series

Page 2 HES-3000/3680/4000/5000/6000 Series Single-Phase Hybrid Inverters USER MANUAL V1.00...
Page 3: Table Of Contents
CATALOGUE INTRODUCTION ....................5 1.1 OPERATION MODES INTRODUCTION ................. 5 1.2 SYSMBOLS ON THE LABEL....................6 SAFETY AND WARNINGS .................. 7 UNPACKING ......................9 3.1 Scope of Delivery ......................9 3.2 Product Overview ......................9 INSTALLING ....................... 11 4.1 Installation Requirement ....................11 4.2 Mounting Location ......................
Page 4 TROUBLE SHOOTING ................... 33 SYSTEM MAINTENANCE ................38 RESTARTS ....................... 39...
Page 5: Introduction
1.1.1 Self-consumption mode In this mode, the Hypontech hybrid inverter maximizes the use of self-generated power to meet local load demand. The system will intelligently allocate power to ensure that the home fully utilizes self-generated power, thus reducing electricity costs.
Page 6: Sysmbols On The Label
1.2 SYSMBOLS ON THE LABEL DANGER, WARNING AND RECYCLABLE AND REUSABLE CAUTION HIGH VOLTAGE AVOID DAMP AND MOISTURE AVOID CONTACT HIGH TEMPERATURE SHIPMENT STACK LIMIT: 7 AVOID CONTACT DO NOT DISPOSE WITH CE MARKS HOUSEHOLD WASTE PROCEED OPERATIONS AFTER 5 MINUTES BREAKABLE ITEM DISCHARGE PLACE UPWARDS...
Page 7: Safety And Warnings
2. SAFETY AND WARNINGS All persons who are responsible for mounting, installation, commissioning, maintenance, tests, and service of HYPONTECH inverter products must be suitably trained and qualified for corresponding operations. They MUST be experienced and have knowledge of operation safety and professional methods.
Page 8 - The inverter should be protected from heavy vibrations and shocks during transportation. 10. Compatible Battery Models please refer to the corresponding , which is Hypontech Compatible Battery List available in printed form inside Documents pack, or an online manual on HYPONTECH website at https://www.hypon.com/xiazai. HES-3000/3680/4000/5000/6000 USER MANUAL 8...
Page 9: Unpacking
3. UNPACKING 3.1 Scope of Delivery Please inspect and check for completeness in the scope of delivery. Confirm with purchase order. 3.2 Product Overview The total size of HES-3000/3680/4000/5000/6000 is 455(width) ×365(height) ×182(depth) mm. It has 2 pairs of PV input terminals,1 Battery input terminals and 2 communication ports.
Page 10 Battery Terminal (s) Connected with Battery Panel COM1: Wi-Fi/LAN Alternative distant communication method COM2: DRED/CT/BMS DRED ,CT and BMS BACK-UP Terminal Connected with BACK-UP AC Terminal Connected with AC Grid Secondary PE Terminal For Grounding Protection HES-3000/3680/4000/5000/6000 USER MANUAL 10...
Page 11: Installing
4. INSTALLING 4.1 Installation Requirement Please install the inverter(s) in places that can avoid inadvertent contact. Installation method, location and surface must be fitting for the inverter’s weight and dimensions. Please install the inverter in an accessible location for operation, future maintenance and service.
Page 12: Mounting Location
4.2 Mounting Location DO NOT mount the inverter near any inflammable materials. DO NOT mount the inverter near any explosive materials. DO NOT mount the inverter on tilting surface over 15° backwards. Please mount the inverter on a vertical wall surface. DO NOT mount the inverter on any surfaces tilting forward or to either sides.
Page 13: Mounting
4.3 Mounting Use the mounting bracket as a template and mark the drill holes. Drill 2 holes using a 10mm bit to 70mm depth. Fix the mounting bracket with the screws and expansion bolts packed in mounting accessories. Attach the inverter to the mounting bracket. Use M5 screws (T25 screwdriver, torque 2.5 Nm) to attach the heat sink fins to the mounting bracket.
Page 14: Cable Specification
Information on grounding components: Object Description Housing M5 terminal lug with protective conductor M5×13 pan head screw PE Conductor cross-section: 10mm² 4.5 Cable Specification HES-3000/3680/4000/5000/6000 USER MANUAL 14...
Page 15: Commissioning
5. COMMISSIONING 5.1 Safety Instructions Measure the frequency and voltage of grid connection and make sure they follow the inverter’s grid connection specifications. An external circuit-breaker on the AC side (or a fuse) at 1.25*AC rated current is strongly recommended. Reliability of all earth connections must be tested and valid.
Page 16: Ac Wire Assembly And Connection
5.3 AC Wire Assembly and Connection 5.3.1 AC Commissioning 5.3.2 AC Breaker Types Please install an individual 2-stage miniature circuit breaker according to the following specifications. Model Maximum output current（A） AC Breaker Rated current（A） HES-3000 14.3 HES-3680 17.6 HES-4000 19.1 HES-5000 23.9 HES-6000...
Page 17: Battery Wire Assembly And Connection
5.5 Battery Wire Assembly and Connection Make sure there is an external DC breaker (≥150A) connected for battery without build-in DC breaker. Make sure battery breaker is off and battery nominal voltage is less than 480V before connecting battery to inverter and make sure inverter is totally isolated from PV and AC power.
Page 18: Communication
6. COMMUNICATION 6.1 System monitoring via Datalogger - RS485/Wi-Fi/LAN (Optional) 6.1.1 Wi-Fi / LAN Datalogger Installation 6.1.2 RS485 / CT / DRED / BMS Connection HES-3000/3680/4000/5000/6000 USER MANUAL 18...
Page 19 19 HES-3000/3680/4000/5000/6000 USER MANUAL...
Page 20 6.1.3 System Connection Diagrams HES-3000/3680/4000/5000/6000 USER MANUAL 20...
Page 21: Auto Test (Only For Italian Market)
6.2 Auto Test (ONLY for Italian Market) Auto-Test The default setting of this function is disabled which can only be available in Italy safety, Short press the button until first Line of LCD displays “Auto Test”, and long press (>2s) the button to start this function. First line of LCD displays “Auto Testing”...
Page 22: Start Up And Operation
7. START UP AND OPERATION 7.1 Safety Check Before Start Up Please check before switching on any voltage resources connected to the inverter and closing inverter’s DC switch: 1. Grid Voltage: Check the grid voltage at point of connection at the inverter complies with permitted range of the inverter.
Page 23 12. Grounding Resistance: Check if the grounding resistance of PV and Battery strings >1MOhm using a multimeter. After all installation and checks, close the AC circuit-breaker, then the DC switch and DC Breaker of battery. The inverter will start to operate when DC input voltage and grid conditions meet the requirements of inverter startup.
Page 24: Inverter Led Indicators
7.2 Inverter LED Indicators When the inverter operates, LED symbols on display have the following meanings: HES-3000/3680/4000/5000/6000 USER MANUAL 24...
Page 25: Display And Control Logics
7.3 Display and Control Logics When inverter starts up and operates, there is a control button beside LCD Display of the inverter. Please follow the logics listed below. 25 HES-3000/3680/4000/5000/6000 USER MANUAL...
Page 26 HES-3000/3680/4000/5000/6000 USER MANUAL 26...
Page 27: Disconnecting From Voltage Sources
8. DISCONNECTING FROM VOLTAGE SOURCES Before proceeding any operations on inverter, please disconnect the inverter from all voltage resources as described in this manual. Following these steps in described sequence are mandatory. Disconnect all miniature circuit-breaker and switch off to prevent from unintentional reconnections.
Page 28: Set Up Monitoring System
9. SET UP MONITORING SYSTEM 9.1 Scan the QR code to download the HYPON.Cloud APP. 9.2 Connect the Inverter to HYPON.Cloud. Connect the Inverter to the network using HYPON.Cloud APP. Please refer to the HYPON.Cloud User Manual to set up monitoring system. Product information is subject to change without notice.
Page 29: Technical Parameters
10. TECHNICAL PARAMETERS （ 29 HES-3000/3680/4000/5000/6000 USER MANUAL...
Page 30 ± （ HES-3000/3680/4000/5000/6000 USER MANUAL 30...
Page 31 The power quality modes can be enabled or disabled via our monitoring APP or Web. Please refer to the “Safety Parameter Setting User Manual” on our website at https://www.hypontech.com/xiazai, or contact our servicer for more information. Only an authorized person can modify the power quality response mode.
Page 32 Please access the monitoring platform on www.hyponportal.com/signin HES-3000/3680/4000/5000/6000 USER MANUAL 32...
Page 33: Troubleshooting
If an external indication of earth fault alarm is required, please connect PV System to inverter monitoring app/portal. The monitoring platform will send email notification in the event of an Earth Fault. Please refer to Sector 6.1 and HYPONTECH WI-FI STICK GUIDE on how to setup your inverter communication function.
Page 34 Disconnect the inverter from the utility grid and the PV array, and reconnect it after LED turns off. If the fault persists, measure the phase to phase voltage and The difference between INV phase to zero and zero to ground voltage with a multimeter to A faulty grid relay voltage and output voltage ensure that the voltage is normal and the zero to ground voltage...
Page 35 ⒈If it happens occasionally, it belongs to the short-time abnormality of the power grid, the inverter will return to normal operation after detecting that the power grid is normal, and there is no need to deal with it. Utility grid inverter detected grid voltage ⒉If it cannot be recovered for a long time, please confirm: disconnected...
Page 36 ⒊If it cannot be recovered for a long time, please confirm: ①whether the AC circuit breaker is disconnected ②whether the AC terminal is in good connection ③whether the power supply line is normal ④ whether the safety regulation settings are normal DC component of the current exceeds 1A in Disconnect the inverter from the utility grid and the PV array, and...
Page 37 Check the connection of DRM device. If the DRM device is DRM S0 Error DRM switch S0 fault connected normally while this fault occurs, please contact the service. Check the connection of BMS cable with storage inverter. If the Battery BMS communication Communication BMS cable is connected normally while this fault occurs, please interrupted...
Page 38: System Maintenance
12. SYSTEM MAINTENANCE For the inverter’s long-term performance, it is suggested to maintain your inverter regularly: NOTICE： HEAT SINK MIGHT INDUCE INJURY When the inverter is operating, the heat sink might exceed 60℃ • Please disconnect all electrical cables and connections. Wait for the inverter to cool down completely.
Page 39 13. RESTARTS When reconnecting the inverter for electrical power supply, please follow the commissioning procedures and safety instructions as described in Section 6 when applicable (e.g. DC Wires need to be reassembled). Please run safety checks as described in Section 7 before closing the DC Switch and starting up again.
