Cosmo COS-12MWDSS User Manual

24 in. built-in microwave drawer
Hide thumbs Also See for COS-12MWDSS:

Advertisement

Quick Links

Download this manual
MICROWAVE DRAWER
COS-12MWDSS
COS-12MWDBK
OPEN
SETUP
MELT
POPCORN
DEFROST
WEIGHT
CLOSE
CLOCK
SOFTEN
BEVERAGE
DEFROST
KITCHEN TIMER
TIME
24 in. BUILT-IN MICROWAVE DRAWER
USER MANUAL
IMPORTANT:
START
1 1
2
3
4
5
POWER
POWER
+30SEC.
STOP
6
7
8
9
0
TIME COOK
CANCEL
READ AND SAVE THESE INSTRUCTIONS.
FOR RESIDENTIAL USE ONLY.
INSTALLER:
PLEASE LEAVE THESE INSTRUCTIONS WITH THIS
UNIT FOR THE OWNER.
OWNER:
PLEASE RETAIN THESE INSTRUCTIONS FOR FUTURE
REFERENCE.
COS-12MWDSS-NH
COS-12MWDBK-NH
OPEN
SETUP
MELT
POPCORN
DEFROST
WEIGHT
CLOCK
SOFTEN
BEVERAGE
DEFROST
CLOSE
KITCHEN TIMER
TIME
START
11
2
3
4
5
P P O O W W E E R R
+30SEC.
STOP
6
7
8
9
0
TIME COOK
CANCEL
Rev. 25.03

Advertisement

loading
Need help?

Need help?

Do you have a question about the COS-12MWDSS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cosmo COS-12MWDSS

Summary of Contents for Cosmo COS-12MWDSS

  • Page 1 MICROWAVE DRAWER COS-12MWDSS COS-12MWDSS-NH COS-12MWDBK-NH COS-12MWDBK START START OPEN OPEN SETUP MELT POPCORN DEFROST POWER POWER SETUP MELT POPCORN DEFROST P P O O W W E E R R +30SEC. +30SEC. WEIGHT WEIGHT STOP STOP CLOCK SOFTEN BEVERAGE DEFROST...
  • Page 2 COSMO Appliances are designed according to the strictest safety and performance standard for the North American market. We follow the most advanced manufacturing philosophy.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS MICROWAVE DRAWER SAFETY ..................4 Important Safety Instructions ..................5 PRODUCT OVERVIEW ....................9 Microwave Drawer Layout ....................9 Control Panel ........................10 OPERATION ........................11 Power on ........................... 11 Setting the clock ......................11 Setting the kitchen timer ....................11 Microwave cooking ......................

  • Page 4: Microwave Drawer Safety

    MICROWAVE DRAWER SAFETY READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol.

  • Page 5: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS If the information in this manual is not followed exactly, a fire or WARNING electrical shock may result that could cause property damage, personal injury or death. • Read all instructions before using • HOT CONTENTS CAN CAUSE SEVERE the microwave oven.
  • Page 6 IMPORTANT SAFETY INSTRUCTIONS • To reduce the risk of fire in the oven • Liquids, such as water, coffee, or cavity: tea are able to be overheated beyond the boiling point without Do not overcook food. appearing to be boiling. Visible Carefully attend the bubbling or boiling when the microwave oven when paper,...

  • Page 7: Radio Interference

    PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY • • Use care when cleaning the vent- Do not operate the oven if it is hood filter. Corrosive cleaning damaged. It is particularly agents, such as lye-based oven important that the oven door close cleaners, may damage the filter.

  • Page 8: Grounding Instructions

    GROUNDING INSTRUCTIONS For all cord connected appliances: The microwave oven must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. The microwave oven is equipped with a cord having a grounding wire with a grounding plug.

  • Page 9: Product Overview

    E. Drawer Window B. Rating Plate F. Drawer Guide C. Microwave Oven Cavity G. Vent D. Drawer Handle H. Mounting Flange (COS-12MWDSS, COS-12MWDBK only) ACCESSORIES Defrosting Rack • Only to be used in defrosting function. • Do not use for cooking.

  • Page 10: Control Panel

    CONTROL PANEL 1. OPEN 7. TIME DEFROST 2. SETUP 8. NUMBER KEYS 3. AUTO MENU 9. POWER 4. WEIGHT DEFROST 10. START/ +30SEC. 5. CLOSE 11. TIME COOK 6. CLOCK/KITCHEN TIMER 12. STOP/C NCEL...

  • Page 11: Operation

    OPERATION Power On 1. When the microwave oven is plugged into an outlet, buzzer sounds once. Screen displays "WELCOME". Then the oven turns into standby mode. The screen displays "00:00". 2. In standby mode, the screen will display the current time if the clock has been set.

  • Page 12: Microwave Cooking

    Microwave Cooking 11 power levels are available. Level Power 100% 50% 40% 20% 10% Display PL100 PL90 PL80 PL70 PL60 PL50 PL40 PL30 PL20 PL10 PL00 1. Press TIME COOK once, “00:00” will display. Press number keys to enter the cooking time. The maximum cooking time is “99:99”.

  • Page 13: Defrost By Weight

    Defrost by Weight 1. Press DEFROST WEIGHT once. "WEIGHT DEFROST" will display. 2. Press numeber keys to input the weight of the food. The input weight should be between 0.1-6.0 lbs. 3. Press START/+30SEC. to start defrosting. 4. Once defrosting has finished, the buzzer will sound five times and “FINISH” will display.

  • Page 14: Auto Menu--Melt

    Auto Menu--Melt 1. Press MELT once, The screen displays "BUTTER". "AUTO MENU" indicator will light. 2. Continue to press MELT , "BUTTER", "CHOCOLA", "CHEESE" or "MARSHMA" will display in order. 3. Press START/+30SEC. to confirm the selection. 4. Press MELT to select the weight. "OZ" will light except butter menu. 5.

  • Page 15: Silent Mode

    Menu Display Weight 1(STICH) Butter BUTTER 2(STICHS) 3(STICHS) Ice cream/ Frozen juice ICE-CRE Cream Cheese CHEESE Silent mode To activate the silent mode: 1. Press "SETUP " once, the screen displays "BUZ OFF". 2. Press START/+30SEC.. The oven will turn to standby mode. Buzzer is turned off.

  • Page 16: Inquiring Function

    Inquiring Function 1. If the clock has been set, the current time will display for three seconds by pressing CLOCK/KITCHEN TIMER in the cooking state. 2. In the microwave cooking state, press POWER to inquire the power level. It will display for three seconds. In defrosting state and auto menu, the power level cannot be inquired.

  • Page 17: Microwave Drawer Care

    MICROWAVE DRAWER CARE GENERAL CLEANING To avoid damage to the microwave drawer caused by arcing due to soil buildup, keep cavity, drawer, microwave inlet cover, and area where the drawer touches the frame clean. Always follow label instructions on cleaning products. Clean with mild soap, water, and a soft cloth or sponge or as indicated below.
  • Page 18 Microwave Drawer Guides • Remove the food crumbs from the microwave drawer guides. Wipe with a soft dry cloth in order to keep the microwave drawer opening and closing smoothly. Waveguide Cover • Keep the waveguide cover located on the inside top of the microwave drawer area clean to assure good microwave performance.

  • Page 19: Troubleshooting

    TROUBLESHOOTING First try the solutions suggested here that may help you avoid a service call. If you need further assistance or more recommendations, refer to the limited warranty page or the contact information at the end of this manual. If you experience Recommended Solutions Microwave drawer Check the following:...
  • Page 20 If you experience Recommended Solutions Unevenly cooked • Turn over or stir food midway through the cooking. food • Completely defrost food before cooking. • Use appropriate cooking time and power level. • Use microwave-safe cookware only. Overcooked food • Use appropriate cooking time and power level.

  • Page 21: Limited Warranty

    LIMITED WARRANTY WARRANTY AND SERVICE TO RECEIVE WARRANTY SERVICE, YOUR PRODUCT MUST BE REGISTERED. TO REGISTER AND REVIEW FULL WARRANTY DETAILS, VISIT: WWW.COSMOAPPLIANCES.COM/WARRANTY SCAN TO REGISTER CUSTOMER SUPPORT TO CHAT WITH US LIVE FOR ASSISTANCE, VISIT: WWW.COSMOAPPLIANCES.COM/CHAT SCAN TO CHAT...
  • Page 22 IMPORTANT Do Not Return This Product To The Store If you have a problem with this product, please contact COSMO Customer Support at +1 (888) 784-3108 DATED PROOF OF PURCHASE, MODEL #, AND SERIAL # REQUIRED FOR WARRANTY SERVICE. IMPORTANT Ne pas Réexpédier ce Produit au Magasin...
  • Page 23 MEMO...
  • Page 24 APPLIANCES Cosmo is constantly making efforts to improve the quality and performance of our products, so we may make changes to our appliances without updating this manual. Electronic version of this manual is available at: www.cosmoappliances.com...

This manual is also suitable for:

Cos-12mwdbkCos-12mwdss-nhCos-12mwdbk-nh
