- Page 1 OPERATION MANUAL MAGNETIC FIELD METER GAUSSMETER MP-1000 2024-06 List-Magnetik Dipl.-Ing. Heinrich List GmbH D-70771 Leinfelden-Echterdingen Max-Lang-Str. 56/2 Fon: + 49 (711) 903631-0 Internet: https://www.list-magnetik.com E-mail: info@list-magnetik.de...
-
Page 2: Table Of Contents
- Reset the Device – Reload Factory Calibration ......8 Applicable Measuring probes ......... 9 Important Notes / Fault analysis ........ 10 Battery Replacement ........... 10 Checking with Calibration Standard ......11 Technical Data MP-1000 ..........12 List-Magnetik GmbH EN MP-1000 2024-06.doc... -
Page 3: Introduction
20,000 A/cm, switchable in Gauss. Applications of the MP-1000 are the test for residual magnetism, the meas- urement of magnetic fields of all kinds, as well as the localization of stray fields for crack detection. -
Page 4: Warnings And Hazard Information
EASURING DUMMY AFETY NSTRUCTION If you are using the MP-1000 with a special measuring dummy instead of a probe for the measurement in a magnetizing system, be sure to observe the following safety instructions: The complete measuring unit with MP-1000, measuring... -
Page 5: Quick Start
The last measured value appears briefly on the display when in peak mode, otherwise 0 or the Earth’s magnetic field strength value. That’s all, now you are ready to take the first measurement in the last selected mode (DC/AC/Peak). The factory setting is DC. List-Magnetik GmbH EN MP-1000 2024-06.doc... -
Page 6: Operation
To activate the other functions dc - Ac - P1 - P2 - un - rES briefly release the button and then press the button again within 5 seconds. List-Magnetik GmbH EN MP-1000 2024-06.doc... -
Page 7: Menu Functions
Then release the button immediately. dc flashes. Now press the red button again to confirm the change. In DC fields, the north polarity is displayed without sign, the south polarity with a minus sign. List-Magnetik GmbH EN MP-1000 2024-06.doc... -
Page 8: Ac - Select Alternating Field Range
When measuring AC fields in peak memory mode, the peak value and not the effective value will be saved if the AC field is sinusoidal. List-Magnetik GmbH EN MP-1000 2024-06.doc... -
Page 9: Un - Change The Measuring Unit (A/Cm - G, Gauss)
In order to perform the reset, press and hold the red button until rES is displayed. Then release the button immediately. rES flashes. Press the red button again to reset the device. List-Magnetik GmbH EN MP-1000 2024-06.doc... -
Page 10: Applicable Measuring Probes
Measuring range 0 – 20.000 A/cm The probe cable is pluggable at both ends, at the display unit and the probe, which is particularly service-friendly, as the cable can simply be replaced if it becomes faulty. List-Magnetik GmbH EN MP-1000 2024-06.doc... -
Page 11: Important Notes / Fault Analysis
The batteries must be replaced as soon as the BAT symbol flashes on the display when the device is switched on. The device switches itself off automatically at an in- sufficient battery voltage. Please use only leak-proof batteries. List-Magnetik GmbH EN MP-1000 2024-06.doc... -
Page 12: Checking With Calibration Standard
If the value is within tolerance, the instrument and probe are working properly. If there is a discrepancy, the entire package of instrument, probe, and calibration standard should be returned to the manufacturer for inspection and recalibration. List-Magnetik GmbH EN MP-1000 2024-06.doc... -
Page 13: Technical Data Mp-1000
Power supply: 2x 1.5 V AA Mignon Operating time: approx. 35 h Dimensions: 105 x 65 x 26 mm Weight: 137 g with batteries Warranty: 12 months on the device, 3 months on the probe List-Magnetik GmbH EN MP-1000 2024-06.doc... - Page 14 (Permeability and Ferrite content) We provide expert advice and design metrology solutions tailored to your specific needs. Fast calibration and repair service List-Magnetik Dipl.-Ing. Heinrich List GmbH D-70771 Leinfelden-Echterdingen Max-Lang-Str. 56/2 Fon: + 49 (711) 903631-0 Internet: https://www.list-magnetik.com E-mail: info@list-magnetik.de...
