- Page 1 Manual MP-4000...
- Page 2 OPERATION MANUAL MAGNETIC FIELD METER MP-4000 Firmware-Version 491 and up 2023-12 List-Magnetik Dipl.-Ing. Heinrich List GmbH D-70771 Leinfelden-Echterdingen Max-Lang-Str. 56/2 Fon: + 49 (711) 903631-0 Fax: + 49 (711) 903631-10 Internet: https://www.list-magnetik.com E-mail: info@list-magnetik.de...
-
Page 3: Table Of Contents
Applications for Windows, Android, iOS ...... 24 Lima Connect for Windows .....................24 Lima Connect for Android and iOS ..................24 Checking MP-4000 with Calibration Standard ..... 26 Important Instructions ..........27 Preserve stored Measurements when changing the battery ............27 Changing the probe .......................27 List-Magnetik GmbH EN MP-4000 2023-12.doc... -
Page 4: Introduction
Alternating field waveforms up to 20 kHz frequency can also be displayed and stored. The pulse curves generated in this way can be displayed and stored in the MP-4000 as a graph, providing an accurate picture of the pulse curve of a magnetic field. -
Page 5: Warnings And Hazards
ARNINGS AND AZARDS List-Magnetik expressly states that the magnetic field meter MP-4000 may only be used for its intended purpose: the measurement of magnetic fields. Any use not in accordance with the intended purpose is not permitted and involves incalculable risks for the instrument and the operator. -
Page 6: Quick Start Guide
UIDE • First connect the probe cable to the probe and the instrument. • Turn on the MP-4000 with the red power button. • The probe will be recognized by the instrument and the model will be automatically displayed in the upper left corner of the status bar. -
Page 7: Display Structure
The status bar shows the title of the current menu position and the battery status. The statistics area displays statistics for a series of measurements. If no memory batch is active, the List-Magnetik logo is displayed here. In the center is the measurement display with the current measurement and addi- tional information about it. -
Page 8: Navigation
This section allows you to set the language, unit of measure, and other measurement and display parameters, as well as power management settings. Info and System Turn off the unit, view hardware and software status, or perform a factory reset. List-Magnetik GmbH EN MP-4000 2023-12.doc... -
Page 9: Measurement
The color of the reading is black. If limits are set, the reading will be red if it is below the lower limit and blue if it is above the upper limit. List-Magnetik GmbH EN MP-4000 2023-12.doc... - Page 10 When the floppy disk icon is displayed in normal color like the other buttons, you can tap it to save a measurement. If the floppy disk icon is not visible, no memory batch is active. List-Magnetik GmbH EN MP-4000 2023-12.doc...
- Page 11 Range 2 also above 3,000 A/cm). Special Function Scan Measurement SCAN See separate chapter " Special Measurement Methods ". The jump to the scan measurement is only possible if the peak value measurement / PEAK is switched off. List-Magnetik GmbH EN MP-4000 2023-12.doc...
-
Page 12: Memory Management
"M". A maximum of 10,000 measurements can be stored in the M memory batches. If you have not created or activated a memory batch, the floppy disk icon will not be visible during the measurement. List-Magnetik GmbH EN MP-4000 2023-12.doc... - Page 13 The additional text entered will be displayed. You can view the individual values by clicking on the navigation icon of the data log. Select a memory batch for immediate use Delete the currently displayed memory batch List-Magnetik GmbH EN MP-4000 2023-12.doc...
-
Page 14: Special Measurement Methods
The trigger measurement processes pulse field measurements at an enormous speed of less than 0.1 msec. The measured values generated in this way can be displayed in the MP-4000 as a graph and give an accurate picture of the pulse progression of a magnetic field. - Page 15 You can enter a short text that will be displayed later when scrolling below the statistics. You can create as many trigger batches as you like. The batches are given a unique free number and a prefixed "T". List-Magnetik GmbH EN MP-4000 2023-12.doc...
-
Page 16: Scan
The measurement is shown graphically on the display. In the statistics display, the count, minimum, maximum and average values are calculated and displayed. To stop scanning, press the STOP button. Actions Overview of the action area in the scan measurement display. List-Magnetik GmbH EN MP-4000 2023-12.doc... - Page 17 You can create as many scan memories as you like. The memory batches are given a unique free number and a prefixed “S” Browse through the saved scans. The statistics, short text, and graphical progress curve are displayed Delete the currently displayed scan List-Magnetik GmbH EN MP-4000 2023-12.doc...
-
Page 18: Data Log
The trash can icon deletes the entire series of measurements. The memory batch remains active, however, so that further measurements will be written to this memory batch. If an individual reading is inactive, it can be permanently deleted by clicking the scissors icon. List-Magnetik GmbH EN MP-4000 2023-12.doc... -
Page 19: Setup
You can set the automatic shutdown time: 5 minutes, 10 minutes, 30 minutes or "never off" if you do not want the device to turn off automatically. The power save mode switches the brightness back to 10% after 1 minute. List-Magnetik GmbH EN MP-4000 2023-12.doc... -
Page 20: Probe Settings
As long as you are in peak or trigger measurement, selecting the range is not possible. Normally, MP-4000 works in auto-range mode, which automatically switches between the two measuring ranges 1 (below 3,000 A/cm) and 2 (above 3,000 A/cm). -
Page 21: Mode (Selection Dc-Ac)
Upper limit value exceeded: measured value red Falling below the lower limit: measured value blue The color change occurs both in the measurement display and in the data log. List-Magnetik GmbH EN MP-4000 2023-12.doc... -
Page 22: Info And System
TIME Date and time can be set manually or via the PC application Lima Connect. When setting manually, please note the notation xxxx-xx-xx (with hyphens) for the date and xx:xx:xx (with colons) for the time. List-Magnetik GmbH EN MP-4000 2023-12.doc... -
Page 23: Delete Memory
Battery voltage must be above 2.8V. Below 2.8V, the unit will automatically shut down. ROBE Probe and device are independently configured. The probe can be plugged into another MP-4000. The probe data includes the serial number and firmware version of the probe and the configuration. List-Magnetik GmbH EN MP-4000 2023-12.doc... -
Page 24: Technical Data
3x 1.5 V AA Mignon. External power supply can be connected via USB-C Operating time: approx. 25 hours with battery, unlimited with external power supply Dimensions: 150 x 85 x 35 mm Weight: 320 g with batteries List-Magnetik GmbH EN MP-4000 2023-12.doc... -
Page 25: Measuring Probes
5 degrees Hall Sensor distance: 0.5 mm Probe thickness: 0.9 mm Total length of the probe: 125 mm Length of the probe handle: 52 mm Width of the probe reed: 4.6 mm List-Magnetik GmbH EN MP-4000 2023-12.doc... -
Page 26: Applications For Windows, Android, Ios
INDOWS The free Lima Connect application for data transfer to the PC can be downloaded from the Applications section at www.list-magnetik.com. With Lima Connect you can connect to a Windows PC using Bluetooth Low Energy (BLE) technology, take online measurements or read out the device's memory, statistically evaluate the data and display it as a graph. - Page 27 Android List-Magnetik GmbH EN MP-4000 2023-12.doc...
-
Page 28: Checking Mp-4000 With Calibration Standard
In the slot for the transversal probe, it can even be damaged. Instead, you can obtain a calibration standard with positioning point, which unfortu- nately works less accurately, but does not damage the probe. List-Magnetik GmbH EN MP-4000 2023-12.doc... -
Page 29: Important Instructions
HANGING THE PROBE To replace the measuring probe, switch off the device beforehand. Connect the desired measuring probe to the probe cable, then switch the device on again. List-Magnetik GmbH EN MP-4000 2023-12.doc... - Page 30 (Permeability and Ferrite content) We provide expert advice and design metrology solutions tailored to your specific needs. Fast calibration and repair service List-Magnetik Dipl.-Ing. Heinrich List GmbH D-70771 Leinfelden-Echterdingen Max-Lang-Str. 56/2 Fon: + 49 (711) 903631-0 Fax: + 49 (711) 903631-10 Internet: https://www.list-magnetik.com...
