- Page 1 Manual MP-810A, 810T...
- Page 2 OPERATION MANUAL MAGNETIC FIELD METER MP-810A / MP-810T Revision number 1.000.0 and up 2024-02 List-Magnetik Dipl.-Ing. Heinrich List GmbH D-70771 Leinfelden-Echterdingen Max-Lang-Str. 56/2 Fon: + 49 (711) 903631-0 Fax: + 49 (711) 903631-10 Internet: https://www.list-magnetik.com E-mail: info@list-magnetik.de...
-
Page 3: Table Of Contents
2.2 Warnings and hazard information ..........3 Axial / transversal measurement probes ....4 3.1 Checking with calibration standard..........4 3.1.1 MP-810A with Axial field probe ................4 3.1.2 MP-810T with Transversal field probe ..............4 Measurement display ..........5 Operating the device with the red button .... -
Page 4: Introduction
The measuring ranges and the different units A/cm, Gauss/Oersted, (Milli-)Tesla meet all requirements. The MP-810 is available with either a fixed axial probe (MP-810A) or a fixed transversal probe (MP-810T). The axial field probe measures the field in the direction of the probe axis at a precise distance of 2.0 mm. -
Page 5: Warnings And Hazard Information
ARNINGS AND HAZARD INFORMATION List-Magnetik expressly points out that the MP-810 magnetic field meter must be used may only be used for its intended purpose, the measurement of magnetic fields. Any other use is inadmissible and involves incalculable risks for the instrument and the operator. and the operator. -
Page 6: Axial / Transversal Measurement Probes
Place the probe in the center of the ring on the top of the calibration standard with the N (North Pole) mark facing up. Position the probe until the maximum value is displayed. Then compare the displayed value to the value of the calibration standard. List-Magnetik Dipl.-Ing. Heinrich List GmbH EN MP-810 2024-02.doc... -
Page 7: Measurement Display
After 10 seconds of inactivity without pressing any key, the device always returns to the measurement display. In the delivery state, English is preselected as the language. List-Magnetik Dipl.-Ing. Heinrich List GmbH EN MP-810 2024-02.doc... -
Page 8: Menu Functions
The probe must not be in a magnetic field. After zeroing, a reading of ± 0.2 will usually appear due to the influence of the earth's magnetic field when the probe is moved. List-Magnetik Dipl.-Ing. Heinrich List GmbH EN MP-810 2024-02.doc... -
Page 9: Probe Mode (Dc/Ac/Peak)
6.3.1 Enable direct field (DC) measurement. For DC fields, the north polarity is indicated by an N and the south polarity is indicated by an S to the left of the reading. List-Magnetik Dipl.-Ing. Heinrich List GmbH EN MP-810 2024-02.doc... -
Page 10: Peak Value Mesurement
The measured value is only updated if it is higher than the previous maximum value. The polarity is irrelevant. To reset the peak value, select Reset Peak, a menu item that only appears in Peak mode. List-Magnetik Dipl.-Ing. Heinrich List GmbH EN MP-810 2024-02.doc... -
Page 11: Memory
The function can be repeated and then de- letes the second to last value, the third to last value and so on. Deletion is only possible for values of the current memory batch (here: batch 2). List-Magnetik Dipl.-Ing. Heinrich List GmbH EN MP-810 2024-02.doc... -
Page 12: Disable Memory
(here: 15) are displayed in the bottom line in a slightly smaller size. To view and manage the memory batch in detail, press the red button long. To jump to the next memory batch, press the red button briefly. List-Magnetik Dipl.-Ing. Heinrich List GmbH EN MP-810 2024-02.doc... - Page 13 A displayed Count 15 (13) means that there are two crossed-out but not yet optimized (and so finally deleted) values in the batch. Only the 13 values that are active are taken into account in the statistics (see chapter: Optimize). List-Magnetik Dipl.-Ing. Heinrich List GmbH EN MP-810 2024-02.doc...
- Page 14 A deleted value can be reactivated by pressing and holding the key again. The crossed-out value is only finally deleted by Optimize. To exit the function, please wait until the display returns to the menu after a few seconds. List-Magnetik Dipl.-Ing. Heinrich List GmbH EN MP-810 2024-02.doc...
- Page 15 If the memory was last active, it remains active and is filled again from the next measurement. 6.4.3.6 Delete The memory batch is deleted. The batch number (here number 2) can be reused later by creating a new memory batch. List-Magnetik Dipl.-Ing. Heinrich List GmbH EN MP-810 2024-02.doc...
-
Page 16: New Memory Batch
If the maximum 9 batches have already been created, this menu item is not displayed. 6.4.5 ELETE ALL BATCHES All memory batches are deleted. The storage is switched off. The next memory batch that is newly created is again assigned the number 1. List-Magnetik Dipl.-Ing. Heinrich List GmbH EN MP-810 2024-02.doc... -
Page 17: Settings
English, German, French, Italian, Spanish, Hungarian, Polish and Dutch are available on the device. 6.5.2 The unit is set to A/cm by default. If the unit is changed, the new unit will remain in effect even after the instrument is turned off. List-Magnetik Dipl.-Ing. Heinrich List GmbH EN MP-810 2024-02.doc... -
Page 18: Switch-Off Time
/ off = the device is always switched on). Off should only be selected in special cases, as this can greatly increase the power consumption. The active switch-off time is displayed with an asterisk ( ) after the entry. List-Magnetik Dipl.-Ing. Heinrich List GmbH EN MP-810 2024-02.doc... -
Page 19: Beep Volume
The contrast of the display font can be set on a scale from 0 (low contrast, dark) to 4 (high contrast, bright). The active contrast is displayed with an asterisk ( ) behind the entry. List-Magnetik Dipl.-Ing. Heinrich List GmbH EN MP-810 2024-02.doc... -
Page 20: System
• Date and time. The values cannot be changed in the device itself, but they can be changed via the List-Magnetik apps for Windows, Android and iOS. • Battery voltage: If the value is below 1.2 volt, you should change the battery. -
Page 21: Battery Replacement
NiMH battery. The output voltage of 1.2V is too low. Voltage fluctuations may even alter the memory in the device. We have had good experience with rechargeable Li-ion batteries that can be charged via USB cable and have an output power of 1.5V. List-Magnetik Dipl.-Ing. Heinrich List GmbH EN MP-810 2024-02.doc... -
Page 22: Technical Data
Google Play Store, Apple App Store, List- Magnetik website Power supply: 1x 1.5V AA Mignon Operating time: approx. 50 hours Dimensions: Ø 28 x 140 mm Weight: 73 g with battery List-Magnetik Dipl.-Ing. Heinrich List GmbH EN MP-810 2024-02.doc... -
Page 23: Available Applications
9.1.1 ONNECT FOR INDOWS On www.list-magnetik.com, in the category Applications, you may obtain the free of charge data transfer application Lima Connect, to transfer measurement data to your PC. With Lima Connect, you can measure online or read the device’s memory, you can evaluate the data statistically or visualize as chart. -
Page 24: Lima Connect App For Android And Ios
With the Lima Connect app you can manage projects and assign the measuring points on a photo. The measurement results can be statistically evaluated and graphically displayed. The app for Android, iOS and Windows is free of charge. Android List-Magnetik Dipl.-Ing. Heinrich List GmbH EN MP-810 2024-02.doc... - Page 25 First of all, please try, if the connection between TOP-CHECK and your PC via Bluetooth works without software installation, by plugging in the Bluetooth receiver. If this does not work immediately, please install the driver software available on https://www.list-magnetik.com in the category Download.
- Page 26 (Permeability and Ferrite content) We provide expert advice and design metrology solutions tailored to your specific needs. Fast calibration and repair service List-Magnetik Dipl.-Ing. Heinrich List GmbH D-70771 Leinfelden-Echterdingen Max-Lang-Str. 56/2 Fon: + 49 (711) 903631-0 Fax: + 49 (711) 903631-10 Internet: https://www.list-magnetik.com...
