508256-01
INSTALLATION INSTRUCTION &
SERVICE INFORMATION
4DHV2 and DWH2 Series Units
SINGLE-ZONE MINI-SPLIT SYSTEM
(115V and 208/230V)
508256-01 01/2022
THIS MANUAL MUST BE LEFT WITH THE OWNER
FOR FUTURE REFERENCE
Improper installation, adjustment, alteration, ser vice
or maintenance can cause property damage, personal
injury or loss of life.
Installation and service must be performed by a licensed
professional HVAC installer (or equivalent) or a service
agency.
In order to avoid injury, take proper precaution when
lifting heavy objects.
General
Refer to the Technical Specifications for more product
information. These instructions are intended as a general
guide and do not supersede local or national codes in any
way. Authorities having jurisdiction should be consulted
before installation.
This wall-mounted indoor unit is matched with an outdoor
heat pump unit to create a mini-split system that uses
HFC-410A refrigerant.
Use of Mini-Split System During
Construction
Allied Air does not recommend the use of its mini-split
systems during any phase of construction. Very low return
air temperatures, harmful vapors and operation of the unit
with clogged or misplaced filters will damage the system.
However, mini-split systems may be used for cooling of
buildings under construction, if the following conditions
are met:
Air filter must be installed in the system and must be
maintained during construction.
Air filter must be replaced upon construction
completion.
The indoor wall unit assembly must be thoroughly
cleaned following final construction clean-up.
All mini-split operating conditions must be verified
according to these installation instructions.
Issue 2204
WARNING
CAUTION
Page 1 of 21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4DHV2 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Lennox 4DHV2 Series

  • Page 1: Table Of Contents

    INSTALLATION INSTRUCTION & SERVICE INFORMATION Table of Contents 4DHV2 and DWH2 Series Units General ................1 Use of Mini-Split System During Construction ..1 SINGLE-ZONE MINI-SPLIT SYSTEM Included Parts ...............2 (115V and 208/230V) Model Number Identification ........3 508256-01 01/2022 Typical System Components ........4 THIS MANUAL MUST BE LEFT WITH THE OWNER System Dimensions .............4 FOR FUTURE REFERENCE...
  • Page 2: Included Parts

    Included Parts The assembled indoor unit will include the following items: Table 1. Included Parts Parts Figure Quantity Parts Figure Quantity Installation instruction, Wireless controller 1 ea. user guide and warranty Mounting plate Wireless control holder (shipped attached to the with 2 mounting screws back of the indoor unit) Mounting plate securing...
  • Page 3: Model Number Identification

    Model Number Identification OUTDOOR SINGLE ZONE HEAT PUMP UNITS 4 D HV 2 S 09 S - 1 P Refrigerant Type Voltage 4 = HFC-410A L = 115V-1 phase-60Hz P = 208/230V-1 phase-60Hz Series Type Minor Design Sequence D = Ductless 1 = 1st Revision Unit Type Refrigerant Circuits...
  • Page 4: Typical System Components

    Typical System Components 1 (25) DRAIN HOLE (bottom of unit) 12-1/2 12-1/8 (318) (308) 13-5/8 (346) 1-1/4 (32) TOP VIEW 32-1/8 (816) 21-7/8 (556) 2-3/8 (60) 3-3/4 (95) 20-1/8 (511) 31-3/4 (806) 13 (330) 2-3/4 (70) FRONT VIEW SIDE VIEW Figure 3.
  • Page 5: Indoor Units

    Indoor Units 20-3/4 (527) 18K Indoor unit outline 23-3/4 (603) 24K BUBBLE LEVEL 12-1/2 (318) 18K 13-3/8 (340) 24K inch LIQUID inch RECOMMAND 38-1/4 (972) 18K 1-7/8 (48) 18K 42-5/8 (1083) 24K 2-1/8 (54) 24K Left rear side Right rear side refrigerant pipe inlet refrigerant pipe inlet 2-1/2 (64) diameter 18K...
  • Page 6: Multiple Outdoor Units

    Multiple Outdoor Units Height of Wall (C) Unit Height (A) CLEARANCE NOTES FOR MULTIPLE UNITS: If the height of the wall (C) is less than or equal to the height of the smallest unit (A), the distance from the unit to the wall (B) must be a minimum of 10 inches (254 mm). If 1/2 the height of the unit (A) is less than the height of the wall (C), the distance from the unit to the wall (B) must be a minimum of 12 inches (305 mm).
  • Page 7: Indoor Unit Installation

    2. Determine the best exit location for utility bundle (line Indoor Unit Installation set, condensate line and wiring). See the following section concerning wall sleeve installation instructions. CAUTION 3. Position the wall mounting plate on the wall so that, when installed, the unit will be at least 6 inches (152 In order to avoid injury, take proper precaution when mm) from the ceiling and 5 inches (127 mm) from the lifting heavy objects.
  • Page 8: Installation Of Indoor Unit On Wall Mounting Plate

    HOOKS AT TOP OF MOUNTING INSIDE TEMPORARY BRACKET SPACER (To facilitate OUTSIDE Typical connections) installation procedure shown. Figure 14. Secure Unit to Wall Mounting Plate Figure 12. Boring Hole for Wall Sleeve Indoor Unit Condensate Piping Connections IMPORTANT Make sure that drain piping is properly routed and USE SUITABLE TOOL TO CUT PVC FOR WALL insulated to prevent both leaks and condensation.
  • Page 9: Outdoor Unit Installation

    CORRECT Make sure there are no kinks or dent in drain hose to ensure proper drainage. Figure 15. Condensate Line Outdoor Unit Installation Installing Drain Connector and Seal Condensate formed during the heating and defrost processes must be drained from heat pump units. Drain holes are provided in the base of the units to ensure proper drainage.
  • Page 10: Placement Considerations

    Placement Considerations Protective canopy Consider the following when positioning the unit: Protective canopy • In coastal areas or other places with salty atmosphere of sulfate gas, corrosion may shorten the life of the unit. In coastal areas, the coil should be cleaned with 24 in potable water several times per year to avoid corrosive 610 mm...
  • Page 11: Buried Refrigerant Pipe Protection

    • The unit base should be elevated above the depth of Buried Refrigerant Pipe Protection average snows as illustrated in “Figure 21. Outdoor • All refrigerant lines must be insulated regardless of if Unit on Brackets above Snow Line” on page 11. it is buried.
  • Page 12: Refrigerant Piping Connections

    Securing Outdoor Unit to Hanging Brackets Table 3. Flaring Pipe If the outdoor unit is installed on field-provided wall Flare Dimension mounting brackets, use lag bolts or equivalent to secure A (mm) Pipe Diameter Flare Shape the outdoor unit to the bracket. Minimum rear clearance can be reduced to 6 inches (152 mm) when mounted on 1/4”...
  • Page 13 TORQUE WRENCH CANT ON THE OUTSIDE OF THE FLARE BACKUP TO INDOOR WRENCH UNIT MALE FLARE CONNECTION TO OUTDOOR UNIT Figure 29. Tighten Flare Nut Table 5. Flare Nut Torque Recommendations Figure 28. Making Connections No torque wrench available Outside (Male to Female Connection) Recommended Finger tighten and use an...
  • Page 14: Leak Test And Evacuation

    Table 6. Line Set Guide Each system size has a line set length and vertical elevation parameters. Maximum Line Set Diameters (in.) Maximum Elevation Elevation Outdoor Maximum Line Additional Refrigerant for System Size Outdoor Unit BELOW Unit ABOVE Set Length - Feet greater than 25 Foot Line Set (KBtu) Indoor Unit - Feet...
  • Page 15: Outdoor Unit

    Indoor Unit CAUTION • Indoor unit is powered by the outdoor unit. All terminal connections must be made as illustrated • Communication, power and ground wiring - Use one in the following diagrams. Improperly connected wiring stranded 3-conductor with ground wire. could damage unit or cause communication errors •...
  • Page 16 115VAC Indoor Unit 208/230V Indoor Unit Terminal Block 115VAC Outdoor Unit Terminal Block 208/230V Outdoor Unit Terminal Block Terminal Block From Power From Power Suppl y Suppl y 18 and 24K unit has five terminal sets. Outdoor Unit Indoor Unit Outdoor Unit Indoor Unit Figure 32.
  • Page 17: Unit Start-Up

    Unit Start-Up Table 9. Indoor Display Alert and Status Codes and Outdoor Unit LED IMPORTANT Outdoor Unit Indoor Unit Main Control Display Unit Error Codes Board Units should be energized 24 hours before unit start-up to prevent compressor damage as a result of slugging. MWCB Outdoor coil temperature sensor 1.
  • Page 18: Double-Check Line Set Connections

    3. Let each function run for 5 minutes, and perform the Ambient Temperature is Below 60ºF (16ºC) following checks: After installation, confirm that all electrical wiring is installed in accordance with local and national regulations, Table 10. Test Run Checklist and according to the installation instruction.
  • Page 19: Indoor Unit Wiring Diagrams

    Indoor Unit Wiring Diagrams Figure 34. DWH2 09K,12K, and 18K - 115V and 208/230VAC Indoor Unit Wiring Diagram 16022000C27182 Figure 35. DWH2 24K 208/230VAC Indoor Unit Wiring Diagram 508256-01 Issue 2204 Page 19 of 21...
  • Page 20: Outdoor Unit Wiring Diagrams

    Outdoor Unit Wiring Diagrams Figure 36. 4DHV2 9K and 12K - 115VAC Outdoor Unit Wiring Diagram Figure 37. 4DHV2 09K, 12K and 18K - 208/230VAC Outdoor Unit Wiring Diagram 508256-01 Issue 2204 Page 20 of 21...
  • Page 21 Figure 38. 4DHV2 24K - 208/230VAC Outdoor Unit Wiring Diagram 508256-01 Issue 2204 Page 21 of 21...
