INSTALLATION INSTRUCTIONS
4SCU23LX
This is a safety alert symbol and should never be ignored. When you see this symbol on labels or in manuals, be alert to
the potential for personal injury or death.
Installation and servicing of air conditioning equipment
can be hazardous due to internal refrigerant pressure
and live electrical components. Only trained and
qualified service personnel should install or service
this equipment. Installation and service performed by
unqualified persons can result in property damage,
personal injury, or death.
Sharp metal edges can cause injury. When installing
the unit, use care to avoid sharp edges.
IMPORTANT
The Clean Air Act of 1990 bans the intentional venting
of refrigerant (CFCs, HCFCs and HFCs) as of July
1, 1992. Approved methods of recovery, recycling or
reclaiming must be followed. Fines and/or incarceration
may be levied for noncompliance.
Manufactured By
Allied Air Enterprises LLC
A Lennox International, Inc. Company
215 Metropolitan Drive
West Columbia, SC 29170
508296-01
This manual must be left with the homeowner for future reference.
WARNING
WARNING
Variable Capacity Air Conditioner
Table of Contents
General ........................................................................2
Installation ...................................................................2
Refrigerant Piping ........................................................4
Electrical - Circuit Sizing and Wire Routing ...............14
Outdoor Unitary Control.............................................19
Unit Operation ...........................................................20
Start-Up .....................................................................20
Homeowner Information ............................................22
Professional Maintenance .........................................23
Start-Up and Performance Checklist .........................25
To prevent serious injury or death:
1. Lock-out/tag-out before performing maintenance.
2. If system power is required (e.g., smoke detector
maintenance), disable power to blower, remove
fan belt where applicable, and ensure all
controllers and thermostats are set to the "OFF"
position before performing maintenance.
3. Always keep hands, hair, clothing, jewelry, tools,
etc. away from moving parts.damage, personal
injury, or death.
*P508296-01*
Issue 2231
WARNING
(P) 508296-01
Page 1 of 25
