Wall mounted air conditioner inverter type
Hide thumbs Also See for UTG-09CH:

Advertisement

Quick Links

User's Manual
Οδηγίες Χρήσης
ΚΛΙΜΑΤΙΣΤΙΚΟ ΤΟΙΧΟΥ ΤΥΠΟΥ INVERTER
WALL MOUNTED AIR CONDITIONER INVERTER TYPE
MODELS/ΜΟΝΤΕΛΑ
UTG-09CH
KTN/KTG21-18R32
UTG-12CH
KTN/KTG21-24R32
UTG-18CH
UTG-24CH
Thank you for purchasing our product.
• Before using this product, be sure to read this Instruction Manual to ensure proper usage. Please
keep this manual for later reference.
• Improper use of this product may result in a malfunction, failure, unexpected accident, or create
a potential hazard.
Ευχαριστούμε που επιλέξατε το κλιματιστικό TOYOTOMI.
Για τη σωστή του χρήση παρακαλούμε διαβάστε το εγχειρίδιο χρήσης προσεκτικά, πριν θέσετε
τη μονάδα σε λειτουργία και κρατήστε το σε καλή κατάσταση για μελλοντική αναφορά.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UTG-09CH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Toyotomi UTG-09CH

  • Page 1 • Improper use of this product may result in a malfunction, failure, unexpected accident, or create a potential hazard. Ευχαριστούμε που επιλέξατε το κλιματιστικό TOYOTOMI. Για τη σωστή του χρήση παρακαλούμε διαβάστε το εγχειρίδιο χρήσης προσεκτικά, πριν θέσετε τη μονάδα σε λειτουργία και κρατήστε το σε καλή κατάσταση για μελλοντική αναφορά.
  • Page 2 Contents Safety precautions ..............4 Parts name ................10 Installation notice ..............10 Installation of outdoor unit ............17 Test and operation ..............21 Confi guration of connection pipe ..........22 Specialist’s Manual ..............23 This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible...
  • Page 3 Appliance filled with flammable gas R32. Before use the appliance, read the owner’s manual first. Before install the appliance, read the installation manual first. Before repair the appliance, read the service manual first. The Refrigerant To realize the function of the air conditioner unit, a special refrigerant circulates in the system.
  • Page 4: Operation And Maintenance

    Precautions WARNING Operation and Maintenance This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory ormental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 5 Precautions WARNING Maintenance must be performed by qualified professionals. Otherwise, it may cause personal injury or damage. Do not repair air conditioner by yourself. It may cause electric shock or damage. Please contact dealer when you need to repair air conditioner. Do not extend fingers or objects into air inlet or air outlet.
  • Page 6 Precautions WARNING Installation must be performed by qualified professionals. Otherwise, it may cause personal injury or damage. Must follow the electric safety regulations when installing the unit. According to the local safety regulations, use qualified power supply circuit and circuit break. Do install the circuit break.
  • Page 7 Precautions WARNING Do not put through the power before finishing installation. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. The temperature of refrigerant circuit will be high, please keep the interconnection cable away from the copper tube.
  • Page 8 Precautions WARNING For the air conditioner with plug ,the plug should be reachable after finishing installation For the air conditioner without plug, an circuit break must be installed in the line. If you need to relocate the air conditioner to another place, only the qualified person can perform the work.
  • Page 9 Precautions WARNING The air conditioner is not allowed to use in a room that has running fire (such as fire source, working coal gas ware, operating heater). It is not allowed to drill hole or burn the connection pipe. The air conditioner must be installed in a room that is larger than the minimum room area.
  • Page 10 Parts name Outdoor Unit air inlet air outlet NOTE Actual product may be different from above graphics, please refer to actual product. Installation notice...
  • Page 11: Tools For Installation

    Tools for installation 1 Level meter 2 Screw driver 3 Impact drill 4 Drill head 5 Pipe expander 6 Torque wrench 7 Open-end wrench 8 Pipe cutter 9 Leakage detector 10 Vacuum pump 11 Pressure meter 12 Universal meter 13 Inner hexagon spanner 14 Measuring tape Note: Please contact the local agent for installation.
  • Page 12: Requirements For Electric Connection

    5. Be sure to cut off the power supply before proceeding any work related to electricity and safety. 6. Do not put through the power before finishing installation. 7. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
  • Page 13 5m, 7.5m, 8m. 2.Min. length of connection pipe is 3m. 3.Max. length of connection pipe capacity capacity 5000Btu/h 24000Btu/h (1465W) (7032W) 7000Btu/h 28000Btu/h (2051W) (8204W) 9000Btu/h 36000Btu/h (2637W) (10548W) 12000Btu/h 42000Btu/h (3516W) (12306W) 18000Btu/h 48000Btu/h (5274W) (14064W) After the length of connection pipe is prolonged for 10m at the basis of standard length, you should add 5ml of refrigerant oil for each additional 5m Additional refrigerant charging amount additional refrigerant charging amount per meter...
  • Page 14: Configuration Of Connection Pipe

    Configuration of connection pipe Sheet 2. Additional refrigerant charging amount for R32 Diameter of connection pipe mm Indoor unit throttle Outdoor unit throttle Cooling only, cooling and Cooling only Liquid pipe Gas pipe cooling and heating heating (g / m) Note: The additional refrigerant charging amount in Sheet 2 is recommended value, not compulsory.
  • Page 15: Safety Operation Of Flammable Refrigerant

    Safety operation of flammable refrigerant Qualification requirement for installation and maintenance man All the work men who are engaging in the refrigeration system should bear the valid certification awarded by the authoritative organization and the qualification for dealing with the refrigeration system recognized by this industry. If it needs other technician to maintain and repair the appliance, they should be supervised by the person who bears the qualification for using the flammable refrigerant.
  • Page 16 Welding • If you should cut or weld the refrigerant system pipes in the process of maintaining, please follow the steps as below: a. Shut down the unit and cut power supply b. Eliminate the refrigerant c. Vacuuming d. Clean it with N2 gas e.
  • Page 17: Installation Of Outdoor Unit

    Installation of outdoor unit (select it according to the actual installation situation) 1. Select installation location according to the house structure. 2. Fix the support of outdoor unit on the selected location with expansion screws. installing the outdoor unit. Make sure the support can withstand at least four times of the unit weight.
  • Page 18 Installation of outdoor unit Step four: connect indoor and outdoor pipes 1. Remove the screw on the right han- 3. Pretightening the union nut with dle of outdoor unit and then remove hand. the handle. pipe joint handle screw union nut NOTE When there're multiple cables cross-hole...
  • Page 19 2. Fix the power connection wire and signal control wire with wire clip (only for cooling and heating unit). Note: Step six: neaten the pipes 1. The pipes should be placed along the wall, bent reasonably and hidden possibly. Min. semidiameter of bending the pipe is 10cm.
  • Page 20: Vacuum Pumping

    Vacuum pumping Use vacuum pump 1. Remove the valve caps on the liquid valve and gas liquid valve piezometer valve and the nut of refri- gas valve gerant charging vent. refrigerant charging 2. Connect the charging hose valve cap vent of piezometer to the refri- gerant charging vent of gas nut of refrigerant...
  • Page 21: Check After Installation

    Check after installation Check according to the following requirement after finishing installation. Items to be checked Possible malfunction Has the unit been installed rmly? The unit may drop, shake or emit noise. Have you done the refrigerant leakage It may cause insuf cient cooling test? (heating) capacity.
  • Page 22: Pipe Expanding Method

    Pipe expanding method Note: Improper pipe expanding is the main cause of refrigerant leakage. Please expand the pipe according to the following steps: A: Cut the pipe E: Expand the port the distance of indoor unit and hard outdoor unit. mold expander pipe...
  • Page 23 Safety prec ons for installing and reloca ng the unit To ensure safety, please be mindful of the following pr ons. WARNING 1. When installing or reloca ng the unit, be sure to keep the refrigerant circuit free from air or substances other than the speci ed refrigerant.
  • Page 24 Περιεχόμενα Μέτρα πρόληψης ............... 26 Ονομασίες μερών ..............33 Διάγραμμα διαστάσεων εγκατάστασης ........33 Εγκατάσταση εξωτερικής μονάδας ..........41 Έλεγχος μετά την εγκατάσταση ..........45 Μέθοδος εκχείλωσης των σωληνώσεων ........46 Οδηγίες ασφαλείας για τον εγκαταστάτη ........47 Η συσκευή αυτή δεν προορίζεται για χρήση από άτομα (περιλαμβα- νομένων...
  • Page 32 9Κ , 18Κ , 24K -15°C~50°C.
  • Page 36 Ηλεκτρική Ασφάλεια Διαμόρφωση των ψυκτικών σωληνώσεων 1. Σταθερό μήκος ψυκτικών σωληνώσεων: 5 μέτρα, 7,5 μέτρα, 8 μέτρα. 2. Ελάχιστο μήκος ψυκτικών σωληνώσεων: Για τη μονάδα με ψυκτικό σωλήνα σύνδεσης 5 μέτρα, δεν υπάρχει περιορισμός για το ελάχιστο μήκος του σω- λήνα...
  • Page 37 Μέγιστο μήκος των ψυκτικών σωληνώσεων Μέγιστο μήκος των ψυκτι- Απόδοση Ψύξης κών σωληνώσεων (m) 5000Btu/h (1465W) 7000Btu/h (2051W) 9000Btu/h (2637W) 12000Btu/h (3516W) 18000Btu/h (5274W) 24000Btu/h (7032W) 28000Btu/h (8204W) 36000Btu/h (10548W) 42000Btu/h (12306W) 48000Btu/h (14064W) 4. Απαιτούμενο ψυκτικό υγρό και ψυκτικό λάδι έπειτα από την ολοκλήρω- ση...
  • Page 38 Πίνακας συμπλήρωσης ψυκτικού υγρού Τύπος Διάμετρος Ψυκτικών σωλη- εσωτερικής Τύπος εξωτερικής μονάδας νώσεων (χιλιοστά) μονάδας Μόνο ψύξη, Γραμμή Γραμμή Ψύξη και Ψύξη και Μόνο ψύξη υγρού αερίου Θέρμανση Θέρμανση (g / m) (χιλιοστά) (χιλιοστά) (g / m) (g / m) 1/4'' 3/8'' ή...
  • Page 39 Πίνακας Α – Ελάχιστες διαστάσεις χώρου ( m Ποσότητα Τοποθέτηση Τοποθέτηση Τοποθέτηση Τοποθέτηση συμπλήρω- στο παράθυ- στο πάτωμα στον τοίχο στο ταβάνι σης (kg) ρο ≤1.2 14.5 16.8 19.3 24.8 27.8 11.2 34.3 12.4 37.8 13.6 41.5 45.4 16.3 49.4 17.8 53,6 19.3...
  • Page 40 Συγκόλληση Εάν χρειαστεί να κόψετε ή να συγκολλήσετε τους σωλήνες ψυκτικού συστήματος κατά την διαδικασία συντήρησης, παρακαλούμε ακολουθείστε τα κάτωθι βήματα: α. Τερματίστε τη λειτουργία της συσκευής και διακόψτε την παροχή ρεύματος. β. Εκκενώστε το ψυκτικό υγρό. γ. Δείτε διαδικασία κενού των σωληνώσεων δ.
  • Page 41 2300W 6000W ~8000W,...
  • Page 42 (N . m) 30~40 9Κ , 12Κ , 18Κ N(1) L(3) 24Κ N(1) 2 L(3) Το διάγραμμα πλακέτας καλωδίωσης είναι μόνο για αναφορά. Παρακαλούμε ανατρέξτε στο πραγματικό.
  • Page 47 Οδηγίες Ασφαλείας για την εγκατάσταση και απεγκατάσταση της μονάδας 30-40 Ampere),...
  • Page 48 RED: 2014/53/EU WiFi: : 18dBm : 2412MHz - 2472MHz Certi cate of compliance CE TOYOTOMI CO., LTD declares that this product complies with the general requirements pursuant to the following European Directives: LVD: 2014/35/EU EMC: 2014/30/EU RoHS: (EU)2015/863 ERP: 2011/65/EU...
  • Page 49 NOTES...
  • Page 50 NOTES...
  • Page 51 NOTES...
