TL880LT Dual Path Controller
TL880LEB Dual Path Controller
TL880LEC Dual Path Controller
TL880LEAT-LAT N Dual Path Controller
TL880LEAT-PE Dual Path Controller
WARNING: This manual contains information on limitations regarding product use and function and
information on the limitations as to liability of the manufacturer. The entire manual should be carefully
read.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Johnson Controls DSC TL880LT
Summary of Contents for Johnson Controls DSC TL880LT
- Page 1 TL880LT Dual Path Controller TL880LEB Dual Path Controller TL880LEC Dual Path Controller TL880LEAT-LAT N Dual Path Controller TL880LEAT-PE Dual Path Controller WARNING: This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. The entire manual should be carefully read.
-
Page 2: Table Of Contents
Introduction Features Communicator ratings Communicator compatibility UL Installation Requirements Installation Tools and supplies required Step 1: Enable module Step 2: Connecting the module Step 3: Verify installer code to activate Alarm.com module Step 4: Perform dual-path test (module registration) Step 5: Allow module to auto-program Panel settings Troubleshooting Module status information... -
Page 3: Note To Installers
Warning: Installer Please Read Carefully Note to installers The warnings on this page contain vital information. As the only individual in contact with system users, it is the installer’s responsibility to bring each item in this warning to the attention of all users of this system. System failures This system has been carefully designed to be as effective as possible. -
Page 4: Safety Information
Smoke detectors Smoke detectors that are a part of this system may not properly alert occupants of a fire for a number of reasons, some of which follow. The smoke detectors may have been improperly installed or positioned. Smoke may not be able to reach the smoke detectors, such as when the fire is in a chimney, walls or roofs, or on the other side of closed doors. -
Page 5: Introduction
This equipment must be installed and used within an environment that provides the pollution degree max 2 and over-voltages category II NONHAZARDOUS LOCATIONS, indoor only. The equipment is designed to be installed, serviced and/or repaired by Skilled Persons only; (skilled person is defined as a person having the appropriate technical training and experience necessary to be aware of hazards to which that person may be exposed in performing a task and of measures to minimize the risks to that person or other persons). -
Page 6: Communicator Ratings
Programmable labels. SIA and Contact ID (CID) formats supported. Signal strength and trouble display LEDs. Subscriber Identity Module (SIM) card included with communicator. Supervision heartbeats over Ethernet path or over the Cellular path, when the Ethernet path is known to be in a trouble condition. -
Page 7: Ul Installation Requirements
Products or components of products, which perform communications functions only shall comply with the requirements applicable to communications equipment as specified in UL60950-1, Information Technology Equipment - Safety - Part 1: General Requirements. Such components include, but are not limited to: hubs; routers;... -
Page 8: Installation
Installation NSTALLATION Follow these guidelines during installation. Before affixing the communicator to a wall, verify the LTE signal level at the installation location. On a keypad, press and hold the 5 key for 2 seconds to view the LTE signal level. An installation location with a sustained signal level of two or more bars is recommended. -
Page 9: Step 1: Enable Module
Installation Mounted in Alarm Controller Cabinet PCL-422 TX+ TX- +12V Controller Board +12V A Red wire on alarm controller PCLink2 Header B Antenna access ports C Ethernet cable D Quad cables (100' / 30m maximum) E Red wire on PCL-422 PCLink Header LTE Controller Board power terminals. -
Page 10: Step 3: Verify Installer Code To Activate Alarm.com Module
Installation The maximum cable length permitted for the power connection is 100ft/30m. Connect the GND terminal on the module to the GND terminal on the PCL-422 Connect the +12V terminal on the module to the +12V terminal on the PCL-422 3: Connect the PC-Link cable Note: To ensure correct orientation, refer to items A and D in the wiring diagrams for the proper position of the red wire on the PC-link cable. -
Page 11: Step 5: Allow Module To Auto-Program
Installation The panel indicates when the test has completed by activating the siren output on medium volume for 2 seconds followed by full volume for 2 seconds. However, if the test was initiated via the [3] or [4] key, or through the Interactive Services menu, the siren will not sound. - Page 12 Installation Section Option Description 311 [001] Partition 1 Call Direction - Alarm/Restore 311 [002] Partition 1 Call Direction - Tamper/Restore 311 [003] Partition 1 Call Direction - Opening/Closing 312 [001] Partition 2 Call Direction - Alarm/Restore 312 [002] Partition 2 Call Direction - Tamper/Restore 312 [003] Partition 2 Call Direction - Opening/Closing 313 [001]...
- Page 13 Installation Section Option Value Description Daylights saving time must be disabled to ensure panel time is accurate. Set according to Enables Duress Code changes from dealer's Alarm.com Alarm.com. setting Realtime clock must be disabled to ensure panel time is accurate. Swinger Shutdown for maintenance signals Swinger Shutdown must be set to 010 to ensure trouble...
-
Page 14: Troubleshooting
Troubleshooting ROUBLESHOOTING Module status information Module status information for verifying and troubleshooting the module connection status or errors can be found through the Interactive Services menus. To access these, press [*][8][Installer Code][851]. See the following table for potential module states. Status Description Idle... -
Page 15: Led Functions
Troubleshooting Status LEDs L1 L2 L3 L4 L5 LED functions Function General & Cellular Error LED. Flashes 1 to 8 times in an 8-second interval to indicate specific error. See section “LED L1 (red)” for errors and common fixes. Broadband Errors & Panel Communication. Flashes 2 to 8 times in an 8-second interval to indicate a specific error on the broadband path. - Page 16 Troubleshooting Number of Error and solution flashes The module is registered on the LTE network but cannot connect with Alarm.com. Power down the module, wait one minute, restore power and perform a communications test. Verify signal strength and try a different location for the module/antenna. If the problem persists, contact Alarm.com Technical Support.
-
Page 17: Various Module States (Modes)
Troubleshooting LED L5 (yellow) LED L5 indicates Z-Wave state and errors. See the table below for more information. Number of flashes Device status or error Successfully added/removed node (last 60 seconds) Delete Mode Add node attempt failed (last 60 seconds) because device already in network Add Mode Replicate Mode Learn Mode Error (lasts 60 seconds) -
Page 18: Walking The Customer Through New User Setup On The Web
Troubleshooting the radio has 3 out of 5 bars or 13/31 and is connected to the network. Radio: 123__ 13 Connected Guidelines for optimal wireless signal strength: Install the module above ground level, as high up as possible within the structure. Install the module near or adjacent to an exterior-facing wall of the structure. -
Page 19: Interactive Service Menu
Interactive Service Menu NTERACTIVE ERVICE Interactive menus The “Interactive Services” menu can be used to access information about the module, install or remove Z- Wave devices and configure or troubleshoot other interactive features. The menu will time out after 20 minutes. Refer to the following tables for the menu options. Installer programming Press [*][8][Installer Code][851] to enter Interactive Services menu. - Page 20 Interactive Service Menu Menu Description --SN See Installer Programming section ---SIM card See Installer Programming section ---Version See Installer Programming section ---Advanced - Network See Installer Programming section --Z-Wave Setup See Installer Programming section ---Number of Z-Wave Devices See Installer Programming section ---Add Z-Wave Device See Installer Programming section ---Remove Z-Wave Device...
-
Page 21: Limited Warranty
until a valid purchase order is received from the Customer and a Limited Warranty Return Merchandise Authorisation number (RMA) is issued by DSC's Customer Service. Digital Security Controls warrants the original purchaser that for a Digital Security Controls’s liability for failure to repair the product period of twelve months from the date of purchase, the product shall be under this warranty after a reasonable number of attempts will be free of defects in materials and workmanship under normal use. - Page 22 Software and any related Hardware) and Digital Security Controls, a Software Product Transfer - You may transfer all of Your rights division of Tyco Safety Products Canada Ltd. (“DSC”), the under this EULA only as part of a permanent sale or transfer of the manufacturer of the integrated security systems and the developer of HARDWARE, provided You retain no copies, You transfer all of the the software and any related products or components...
-
Page 23: Regulatory Information
EXPRESSED OR IMPLIED (INCLUDING ALL IMPLIED - Connect the equipment into an outlet on a circuit different from that to WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A which the receiver is connected. PARTICULAR PURPOSE) AND OF ALL OTHER OBLIGATIONS - Consult the dealer or experienced radio/television technician for help. OR LIABILITIES ON THE PART OF DSC. - Page 24 communication line security level P1 when used alone or as P2-P3 when used in conjunction with the integrated dialer in the compatible panels HS2128/HS2064/HS2032/HS2016. The TL880LEB/TL880LEC can be used in commercial burglary applications up to Security Level IV. For ULC Listed installations refer also to ULC Installation Guide P/N 29002157.
- Page 25 © 2021 Johnson Controls. All rights reserved. JOHNSON CONTROLS, TYCO and DSC are trademarks of Johnson Controls. Tech Support: 1-800-387-3630 (Canada & U.S.) or 905-760-3000 www.dsc.com The trademarks, logos, and service marks displayed on this document are registered in the United States and/or other countries. Any misuse of the trademarks is strictly prohibited and Tyco will aggressively enforce its intellectual property rights to the fullest extent of the law, including pursuit of criminal prosecution wherever necessary.
