MENEGOTTI TECHNICAL MANUAL
WHEELBARROW MIXER
5 CuFt
QR-Code:
Point your mobile phone camera to
access the updated online version of
Technical
Catalogs, or click on the link below to
access the website.
www.mgtamerica.com
Attention:
Before operate Menegotti equipment, read this
Technical Manual , itself will inform and instruct the
operator about the operation.
By the way, you avoid possible working accidents and
early maintenance on at the equipment.
Manuals
Parts
and
Advertisement
Table of Contents
Related Manuals for MENEGOTTI 5 CuFt
Summary of Contents for MENEGOTTI 5 CuFt
- Page 1 Catalogs, or click on the link below to access the website. www.mgtamerica.com Attention: Before operate Menegotti equipment, read this Technical Manual , itself will inform and instruct the operator about the operation. By the way, you avoid possible working accidents and...
- Page 2 Product Warranty Warranty Term Welcome, you are now a part of the great Menegotti "client family". MENEGOTTI After Sales and Technical Assistance departments. Caution: For best convenience, keep this manual in a appropriate place...
-
Page 3: Safety Informations
• Before using this equipment, carefully, read this manual and follow the Manufacturer's information, such as, how to reduce the risk of accidents in operation. • It is expressly prohibited to remove or alter any safety device or feature, if it occurs Menegotti will not be held responsible. • Use the equipment according to the instructions on this manual. -
Page 4: Main Components
• Maintain a limited area exclusive for working with the equipment, always keeping this place clean, without obstructions and with proper illumination. • The operator must be trained or qualified to operate this equipment. • Do not use clothing that is too loose and which might get caught in the machine. •... -
Page 5: Technical Specifications
Technical Specifications WHEELBARROW MIXER Drum capacity 5.0 CuFt Final mixture return 2.3 CuFt Cycles/hour quantity 15 Cycles Mix capacity 2.83 CuFt Hour production 42.4 ft³/h Drum rotation 30 Rpm (60Hz) / 28 Rpm (50Hz) Single-Phase 1/2CV 115/230V Electric motor UL Certification / CE compliant Transmission V-Belt 3L -230 Net weight with motor... -
Page 6: Equipment Cleaning
Working and Operating Conditions • Attentively read this instruction manual; • Can be used inside or outside; • The introduction of any object in the drum, as it is on, can cause serious accidents; • Any not proper use may consist on a threat to the operator and people nearby physical integrity;... -
Page 7: Equipment Grounding
• The grounding must be done in accordance with the country standards and accompanied by a technically qualified person. In the absence of these standards, it must be carried out according to international standards. Doubts regarding installation contact Menegotti Authorized Service. - Page 8 Lubrication • Keep machine rotating parts lubricated, such as: pinion, gear ring, bushings, and bearings (with the help of the grease fittings installed in the machine); • Lubricate the equipment at the beginning of operation, applying grease to all lubrication points; •...
- Page 9 Leveling Adjustment and Transportation • Do not exceed 5 degrees of inclination relative to ground level. • The equipment has handlebar to raise a few inches from the ground and transport through the wheels;...
-
Page 10: Working Operation
Working Operation • Place the concrete mixer on a plain and firm surface in a way to make easier the loading and unloading processes. • Connect the switch which is in the motor protection box remembering to follow recommendations for the extension. •... -
Page 11: Assembly Procedures
Assembly Procedures 2 - Assemble the rear chassis using 04 washers, 1 - Assemble the center and front chassis Check List 02 nuts and 02 bolts 3/8"x4.1/2” supplied with using 04 flat washers, 02 nuts, and 02 bolts Item Qty. the equipment. - Page 12 6 - Assemble the axle in the chassis with hook “U” fasten with flat washers 4 - Put the drum down. Fit the motor box into the chassis. Check the gear rack and pinion coupling. If there is no coupling, rotate the chassis until it and nuts 3/8", using the marks to assist the centralizing process.
-
Page 13: Exploded View / Spare Parts
Exploded View / Spare Parts... - Page 14 POS. DESCRIPTION QTY. CODE DRAWING POS. DESCRIPTION QTY. CODE DRAWING Central Chassis Assembly 33110209 3110209 28 Pulley Engine 31090265 4122374 Front Chassis Assembly 33112195 3112195 29 Single-phase Engine 1/2CV 60Hz 115/230V 23014623 Rear Chassis Assembly 33112192 3112192 30 Hexagonal Screw M8x20 21012931 Bearing 30205 22020603...
-
Page 15: Product Warranty
Also not repairs by a person or workshop not authorized by Menegotti. The product covered is any assembly of the parts by any party other than the factory freight charges, including the technical assistant or factory, are borne by the itself or Technical Assistant, application outside the specification,...
