MENEGOTTI TECHNICAL MANUAL
REVERSIBLE PLATE COMPACTOR
MPR 2500
QR-Code:
Point your cell phone or tablet camera
to access the updated version of
Technical
Catalogs online, or click the link below
to access the website.
www.sites.google.com/view/menegotti-engenharia-docs
Attention:
Before operate Menegotti equipament, read this
Technical Manual , itself will inform and instruct the
operator about the operation.
By the way, you avoid possible working accidents
and early maintenance on at the equipment.
Manuals
and
Parts
Advertisement
Table of Contents
Related Manuals for MENEGOTTI MPR 2500
Summary of Contents for MENEGOTTI MPR 2500
- Page 1 Catalogs online, or click the link below to access the website. www.sites.google.com/view/menegotti-engenharia-docs Attention: Before operate Menegotti equipament, read this Technical Manual , itself will inform and instruct the operator about the operation. By the way, you avoid possible working accidents...
-
Page 2: Table Of Contents
Equipment Transport carefully. Preventive Maintenance Maintenance Chart Menegotti is preparaded to offer you all technical assistance, and attend Quantities Chart all your needs about replacement parts. Product Warranty Warranty Term Welcome, you are part of the huge Menegotti “customers familiy”. -
Page 3: Menegotti Group
The Product The Vibratory Reversible Plate MPR 2500 is a compaction machine, able to work quickly by applying consecutive impacts to the ground surface to level the uneven ground surface, uniformizing it so that the space between the particles shrinks, and to increase the dry density of the soil that has its moisture removed by the compaction process. -
Page 4: General Care
General Care • The compacting plate shall be inspected at least once per shift for verification of visible damage. In the event of their existence, immediately stop the operation and inform the person responsible; • Perform PREVENTIVE maintenance according to the specifications in this instruction manual. This action will increase the life of the machine and ensure your warranty right;... -
Page 5: General Vision Of The Equipment
General Vision of the Equipment Number Part Reversion Gear Box Cable Guide Bar Cable Height Adjust Engine Eccentric Gear Box Base Plate Console Protective Cage Uplifting Shoulder Strap Guide Bar Clip Accelerator Reversion Guide Bar... -
Page 6: Starting The Equipment
Starting the Equipment 1.1. SET THE POWER BUTTON • Turn from “OFF” to the "ON" position. 1.2. OPEN THE FUEL TAP • Move the fuel tap lever to the indicated position on the image at the side. 1.3. SET THE CHOKER •... - Page 7 1.4. SET THE ACCELERATOR • Move the accelerator lever to the indicated position (minimum or ¼) on the image below. ACCELERATOR MINIMUM OR 1/4 FORWARD 1.5. PULL THE RECOIL STARTER • Slowly pull the recoil starter lever until you notice a resistance and then pull it a little harder and quickly for about 5 times. This will make the fuel flow to the carburetor;...
-
Page 8: Operating The Equipment
1.7. INSTRUCTIONS FOR DAILY OPERATIONS • If the engine is still warm, you don’t need to be using the choker over the following starts during your daily operations; • When lifting or transporting the machine, always close the fuel tap. This procedure will help on the cleaning and lifetime of your carburetor; •... -
Page 9: Turning Off The Equipment
Turning Off the Equipment 3.1. TURNING OFF THE EQUIPMENT | ENGINE STALLING METHOD • Move the throttle lever to the minimum speed; • Move the fuel tap to the left to close; • Wait for the engine of the machine to shut down by itself due to lack of fuel; •... -
Page 10: Equipment Transport
Equipment Transport • Attach the Guide Bar to the “Guide Bar Clip”; • Lift the machine through the uplifting shoulder strap. Uplifting Shoulder Strap Guide Bar Clip Preventive Maintenance 5.1. ENGINE OIL LEVEL • Remove the engine oil level indicator and check the oil level. •... -
Page 11: Changing Engine Oil
5.2. CHANGING ENGINE OIL • Place a container on the back edge of the engine console; • Remove the oil drainage bolt; • Drain the oil while the engine is hot (just turned off) to ensure fast and complete drainage; •... -
Page 12: Oil Replacement
5.3.2 V-BELT REPLACEMENT SECOND PART | LEVELLING CONSOLE AND V-BELT TENSION • The belt tension is regulated by the console height (RUBBER SHOCK ABSORBERS) fixing screws; Back • Use a bubble level and a wrench to screw the RUBBER SHOCK ABSORBERS BOLTS and tight the V-BELT and letting the console aligned at rear back edges and consoles sides;... - Page 13 5.5 ECCENTRIC GEAR BOX OIL EXCHANGE • Due to the complexity in performing the oil change of the eccentric box, we recommend that this operation should carried out by an authorized technical assistance; • Contact us to find an authorized technical assistance. 5.6.
-
Page 14: Maintenance Table
Maintenance Table MAINTENANCE PERIOD PART TASK • Change the engine oil After the first 20 hours of operation Engine • Tighten all accessible screws and nuts • Clean air filter and observe possible damage. After every 8 hours of operation/Daily Air Filter Replace it if necessary •... -
Page 15: Product Warranty
The product freight charges, including the technical assistant or factory, nature, such as floods, gales, fire, landslides or due to transportation. are borne by the consumer. Menegotti has a wide network of Technical Assistants throughout the country. Removal or any alteration to the series numbers originally placed on the... - Page 16 Solid values, sustainable future. Unit • Unidad Menmaq Unit • Unidad Mentec Unit • Unidad Menfer Unit • Unidad MNA United States...
