MENEGOTTI CONCRETE MIXER 400L Technical Manual

Rental w/chassis hd

Advertisement

Quick Links

MENEGOTTI TECHNICAL MANUAL
CONCRETE MIXER 400L
RENTAL W/CHASSIS HD
QR-Code:
Point your cell phone or tablet camera
to access the updated version of
Technical
Catalogs online, or click the link below
to access the website.
www.mgtamerica.com
Attention:
Before operate Menegotti equipament, read this
technical manual, itself will inform and instruct the
operator about the operation.
By the way, you avoid possible working accidents
and early maintenance on at the equipment.
Manuals and Parts

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CONCRETE MIXER 400L and is the answer not in the manual?

Questions and answers

Summary of Contents for MENEGOTTI CONCRETE MIXER 400L

  • Page 1 Catalogs online, or click the link below to access the website. www.mgtamerica.com Attention: Before operate Menegotti equipament, read this technical manual, itself will inform and instruct the operator about the operation. By the way, you avoid possible working accidents and early maintenance on at the equipment.
  • Page 2 (operation) and the satisfactory working is consequence of yours regular Equipment Lubrication work carefully. Transport, Lifting and Towing Wiring Diagram Menegotti is preparaded to offer you all technical assistance, and attend all Equipment Operation your needs about replacement parts. Equipment Maintenance Parts List Product Warranty Welcome, you are part of the huge Menegotti “customers family”.
  • Page 3: Safety Information

    • Before using this equipment, carefully read this manual and follow the Manufacturer’s instructions, such as how to reduce the risk of accidents in operation; • It is expressly prohibited to remove or alter any safety device or characteristic, should this occur MENEGOTTI will not be held responsible; • Use the equipment according to the instructions in this manual;...
  • Page 4: Technical Specifications

    • Avoid contact with hot surfaces; • Before performing any activity or maintenance, first let the engine cool down; • Avoid contact with rotating parts. Technical Specifications SPECIFICATIONS CONCRETE MIXER 400L Total Drum Volume 14 CuFt Output Capacity (Mixed) 11 CuFt...
  • Page 5: Main Parts

    Main Parts Equipment supplied without Electric Engine The engine installation, electrical appliances and their installations and grounding must be made in accordance with current standards in the POS. DESCRIPTION region and accompanied by a responsible qualified function. In the absence of such standards, should be carried out according to Drum international standards, doubts when installing contact the authorized Steel Yoke...
  • Page 6: Operation Conditions

    • For use of an extension electric, we recommend the table: doubts when the installation please contact your authorized service. CONCRETE MIXER 400L Extension electric 0 to 66ft 66 to 99ft...
  • Page 7 Equipment Lubrication • Keep machine rotating parts lubricated, such as: bushings, bearings, and bearing supports; • Lubricate the equipment at the beginning of operation, applying grease to all lubrication points; • Lubrication of the pinion/rack gear assembly is not recommended due to the fact that aggregates such as sand, cement and gravel dust, among others, can adhere to the lubricating agent, causing the mixture to become extremely abrasive, thus resulting in premature wear;...
  • Page 8 Greasing the Wheel Hubs 1- Using the plier for dust cap and the hammer, remove the dust cap from 3- Using the grease gun, attach the tip to the grease, and then start pumping the wheel hub. grease into the wheel hub until it looks like the picture below. Note: If you do not have the plier, you can use a flathead screwdriver.
  • Page 9 Transport, Lifting and Towing • It has yoke just to raise a few centimeters of soil and carry through the movement of the wheels; • They should be used by tilting, with the drum facing down, while maintaining the flatness of the mixer; Lifting point.
  • Page 10: Equipment Operation

    Equipment Operation • Position the mixer on a flat, firm surface, so that facilitates the process of loading and unloading; • Turn the switch that is attached to the engine enclosure; • tilting the drum to the desired angle. This movement should be done by turning the steering wheel and at the same time stepping on the pedal, unlocking the swivel rocker;...
  • Page 11: Equipment Maintenance

    Equipment Maintenance Rack Gear Replacement • Remove the damaged rack gear screws (07), and replace them according to assembly recommendations; • Use two Ø 5 mm pins (C) to adjust the gap between teeth, necessary for the perfect running of the pinion and rack gear; •...
  • Page 12: Parts List

    Parts List Engine Box 1.21 POS. DESCRIPTION QTY. CODE DRAWING 1.03 1.01 Rubber Door Latch 24030255 4122581 1.02 Stop Rubber 24030222 4122072 1.03 1.04 1.05 1.03 Flat Washer 5/16" 21030252 1.07 1.16 1.06 1.08 1.04 Hex. Bolt 5/16"X3/4" 21010268 1.05 Spring Washer 5/16" 21030112 1.06 Self Locking Hex Nut 5/16"...
  • Page 13 Steel Yoke POS. DESCRIPTION QTY. CODE DRAWING 2.14 2.20 2.01 Flat Washer DN26 30100079 4122006 2.02 Bearing 30210 22020608 2.11 2.12 2.03 Bearing 30209 22020607 2.11 2.24 2.09 2.04 Cotter Pin 3/16"X1.1/2" 21050106 2.10 2.08 2.05 Steel Yoke 11 CuFt 400L HD 32460057 3106049 2.20 2.18...
  • Page 14 Drum POS. DESCRIPTION QTY. CODE DRAWING 3.01 Drum 400L HD (11CuFt) 34600038 2107004 3.02 Segmented Crown Rack Gear 31180004 2124011 3.03 Hex Bolt 3/8"X2.1/4" 21013824 3.01 3.04 Flat Washer 3/8" 12 21030230 3.05 Hex Nut 3/8" 21021059 3.06 Drum Washer 30100070 4107003 3.02 3.07 Sealing Washer...
  • Page 15 Rack Gear Protection 4.06 4.05 4.07 4.05 4.01 4.02 4.03 4.02 4.04 POS. DESCRIPTION QTY. CODE DRAWING 4.01 Screw M5x25mm 21011022 4.04 4.02 Hex Bolt M6x16mm 21012986 4.01 4.03 4.03 Hex Nut M6 21021104 4.08 4.03 4.04 Hex Nut 1/4" 21021004 4.08 4.03...
  • Page 16 KIT 02 - Large Column Assembly 5.08 POS. DESCRIPTION QTY. CODE DRAWING 5.20 5.03 Grease Fititng 1/8" Straight 24040101 5.05 5.04 Retaining Ring E-54 21060146 5.15 5.05 Shaft with Gear Z-11 HD 31020461 4114087 5.03 5.04 5.06 Steering Wheel 400L HD 31200017 3122170 5.09 5.07 Hex Bolt 1/2"x2"...
  • Page 17 Chassis 5.26 5.25 5.31 5.24 5.02 5.30 5.22 5.03 5.29 5.24 5.18 5.11 5.27 5.13 5.28 5.13 5.08 5.05 5.20 5.15 5.01 5.03 5.04 5.07 5.09 5.32 5.37 5.19 5.06 5.12...
  • Page 18 Chassis POS. DESCRIPTION QTY. CODE DRAWING POS. DESCRIPTION QTY. CODE DRAWING 5.01 Chassis 400L HD 32105151 2105151 5.26 Hex Nut 3/8" 21020117 5.02 Bearing Support 31140055 3116001 5.27 Hex Bolt 3/8" x 2" 21010241 5.03 Grease Fitting 1/8" Straight 24040101 5.28 Hex Bolt 5/16”X2”...
  • Page 19 This warranty is limited to the repair, replacement of parts or assembly of outside that specified, broken or crushed casing due to negligence during parts in which, through examination by a Menegotti Authorized Technical transporting /or storage, coupling or energizing outside specifications and Assistant with prior authorization from the Factory, any manufacturing general defects from improper use and/or incorrect installation.
  • Page 20 Solid values, sustainable future. Unit • Unidad Menmaq Unit • Unidad Mentec Unit • Unidad Menfer Unit • Unidad MNA United States...
